CADILLAC ESCALADE 2022 Service Manual
Manufacturer: CADILLAC, Model Year: 2022, Model line: ESCALADE, Model: CADILLAC ESCALADE 2022Pages: 508, PDF Size: 9.18 MB
Page 41 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
40 SEATS AND RESTRAINTS
Seats and Restraints
Head Restraints
Head Restraints . . . . . . . . . . . . . . . . . . . . 41
Front Seats
Power Seat Adjustment . . . . . . . . . . . 43
Reclining Seatbacks . . . . . . . . . . . . . . . 44
Lumbar Adjustment . . . . . . . . . . . . . . . 44
Massage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Memory Seats . . . . . . . . . . . . . . . . . . . . . . 46
Heated and Ventilated FrontSeats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Rear Seats
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Second Row Seats . . . . . . . . . . . . . . . . . 50
Heated Rear Seats . . . . . . . . . . . . . . . . . 55
Third Row Seats . . . . . . . . . . . . . . . . . . . 55
Seat Belts
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Buckle To Drive . . . . . . . . . . . . . . . . . . . . 59
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . 62
Seat Belt Use During Pregnancy . . . . . . . . . . . . . . . . . . . . . . . . . 65
Seat Belt Extender . . . . . . . . . . . . . . . . . 65
Safety System Check . . . . . . . . . . . . . . 65
Seat Belt Care . . . . . . . . . . . . . . . . . . . . . . 66 Replacing Seat Belt System Parts
after a Crash . . . . . . . . . . . . . . . . . . . . . . 66
Airbag System
Airbag System . . . . . . . . . . . . . . . . . . . . . 66
Where Are the Airbags? . . . . . . . . . . . 68
When Should an AirbagInflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
What Makes an Airbag Inflate? . . . 70
How Does an Airbag Restrain? . . . 71
What Will You See after an Airbag Inflates? . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Passenger Sensing System . . . . . . . . 72
Servicing the Airbag-Equipped Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Adding Equipment to the Airbag-Equipped Vehicle . . . . . . . . 76
Airbag System Check . . . . . . . . . . . . . . 77
Replacing Airbag System Parts after a Crash . . . . . . . . . . . . . . . . . . . . . . 77
Child Restraints
Older Children . . . . . . . . . . . . . . . . . . . . . 78
Infants and Young Children . . . . . . 79
Child Restraint Systems . . . . . . . . . . . 81
Where to Put the Restraint . . . . . . . 83
Lower Anchors and Tethers forChildren (LATCH System) . . . . . . . 85
Replacing LATCH System Parts
After a Crash . . . . . . . . . . . . . . . . . . . . . 92 Securing Child Restraints (With
the Seat Belt in the
Rear Seat) . . . . . . . . . . . . . . . . . . . . . . . . 92
Securing Child Restraints (With the Seat Belt in the Front
Passenger Seat) . . . . . . . . . . . . . . . . . . 95
Page 42 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
SEATS AND RESTRAINTS 41
Head Restraints
The vehicle’s front seats have
adjustable head restraints in the
outboard seating positions.
{Warning
With head restraints that are not
installed and adjusted properly,
there is a greater chance that
occupants will suffer a neck/spinal
injury in a crash. Do not drive until
the head restraints for all occupants
are installed and adjusted properly.
If your vehicle has rear head
restraints that fold down, always
return them to the full upright
position whenever an occupant is
seated in the seat.
Adjust the head restraint so that the
top of the restraint is at the same
height as the top of the occupant's
head. This position reduces the
chance of a neck injury in a crash.
Front Seats
The vehicle's front seats have
adjustable head restraints in the
outboard seating positions.
The height of the head restraint can
be adjusted.
To raise or lower the head restraint,
press the button located on the side of
the head restraint and pull up or push
the head restraint down, and release
the button. Pull and push on the head
restraint after the button is released
to make sure that it is locked in place.
The front seat outboard head
restraints are not removable.
Page 43 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
42 SEATS AND RESTRAINTS
Rear Seats
Second Row Seats
The vehicle’s second row seats have
head restraints in the outboard
seating positions that cannot be
adjusted.
The second row outboard head
restraints are not removable.
The second row outboard head
restraints are designed to be folded.
When folding the second row
seatbacks down, the head restraint
will automatically fold out of the way
as the seat is folded down.
The second row outboard head
restraints can be folded forward to
allow for better visibility when the
rear seat is unoccupied.
To fold the head restraint, press the
button on the side of the head
restraint.
The head restraint will fold forward
automatically.
When an occupant or child restraint is
in the seat, always return the head
restraint to the full upright position.
Push the head restraint up and
rearward until it locks into place. Push
and pull on the head restraint to make
sure that it is locked.
Third Row Seats
The vehicle’s third row seats have
head restraints in the outboard
seating positions that cannot be
adjusted up or down.
The third row outboard head
restraints are not removable.
The third row outboard head
restraints are designed to be folded.
When folding the third row seatbacks
down, the head restraint will
automatically fold out of the way as
the seat is folded down.
The head restraint can be folded
forward to allow for better visibility
when the rear seat is unoccupied.
Page 44 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
SEATS AND RESTRAINTS 43
To fold the head restraint, press the
button on the side of the head
restraint.
The head restraint will fold forward
automatically.
When an occupant or child restraint is
in the seat, always return the head
restraint to the full upright position.
Push the head restraint up and
rearward until it locks into place. Push
and pull on the head restraint to make
sure that it is locked.
Front Seats
Power Seat Adjustment
{Warning
You can lose control of the vehicle
if you try to adjust a driver seat
while the vehicle is moving. Adjust
the driver seat only when the
vehicle is not moving.
{Warning
The power seats will work with the
ignition off. Children could operate
the power seats and be injured.
Never leave children alone in the
vehicle.
To adjust the seat:
.Move the seat forward or rearward
by sliding the control forward or
rearward.
.Raise or lower the front part of the
seat cushion by moving the front of
the control up or down.
Page 45 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
44 SEATS AND RESTRAINTS
.Raise or lower the seat by moving
the rear of the control up or down.
Reclining Seatbacks
To recline the seatback:
.Tilt the top of the control rearward
to recline.
.Tilt the top of the control forward
to raise.
{Warning
Sitting in a reclined position when
the vehicle is in motion can be
dangerous. Even when buckled up,
the seat belts cannot do their job.
The shoulder belt will not be
against your body. Instead, it will be
in front of you. In a crash, you
could go into it, receiving neck or
other injuries.
The lap belt could go up over your
abdomen. The belt forces would be
there, not at your pelvic bones. This
could cause serious internal
injuries.
For proper protection when the
vehicle is in motion, have the
seatback upright. Then sit well back
in the seat and wear the seat belt
properly.
Do not have a seatback reclined if the
vehicle is moving.
Lumbar Adjustment
Page 46 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
SEATS AND RESTRAINTS 45
.Press and hold the front or rear of
the control to increase or decrease
lumbar support.
.If equipped, press and hold the top
or bottom of the control to raise or
lower lumbar support.
Uplevel Seat Adjustment
To adjust lumbar support, if equipped:
.Press and release or hold Feature
Select (1) to scroll to lumbar
support on the infotainment display.
.Press Forward (5) or Rearward (3) to
adjust lumbar forward or rearward.
.Press Up (2) or Down (4) to adjust
lumbar up or down.Bolster Support
To adjust bolster support, if equipped:
Press and release or hold Feature
Select (1) to scroll to bolster support
on the infotainment display. Press
Forward (5) or Rearward (3) to adjust
bolster support inward or outward.
Upper Shoulder Support
To adjust upper shoulder support,
if equipped:
.Press and release or hold Feature
Select (1) to scroll to upper shoulder
support on the infotainment display.
.Press Forward (5) or Rearward (3) to
adjust shoulder support forward or
rearward.
Massage
If equipped, the vehicle must be on to
use the massage feature.
To activate and adjust massage:
.Turn the Feature Select (1) to scroll
to massage on the infotainment
display.
.Press Up (2) or Down (4) to adjust
massage type.
.Press Forward (5) or Rearward (3) to
adjust the intensity.
.To turn massage off or to activate
massage at last massage type and
intensity settings, press the massage
On/Off Control (6).
Page 47 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
46 SEATS AND RESTRAINTS
The massage feature will turn off after
approximately 20 minutes. Press the
massage On/Off Control (6) to restart
the massage feature.
Memory Seats
Overview
If equipped, the memory seat feature
allows drivers to save their unique
driving positions and a shared exit
position. See“Saving Seating
Positions” later in this section. The
saved positions can be recalled
manually by all drivers. See “Manually
Recalling Seating Positions” later in
this section. Drivers with remote key
1 and 2 can also recall them automatically. See
“Auto Seat Entry
Memory Recall” or“Auto Seat Exit
Memory Recall” later in this section.
To enable automatic recalls, turn on
Seat Entry Memory and/or Seat Exit
Memory. See “Enable Automatic
Recalls” under“Vehicle
Personalization Settings” later in this
section. The memory recalls may be
cancelled at any time during the
recall. See “Cancel Memory Seating
Recalls” later in this section.
Identifying Driver Number
The vehicle identifies the current
driver by their remote key number
1–8. The current remote key number
may be identified by Driver
Information Center (DIC) welcome
message, “You are driver x for memory
recalls,” This message is displayed the
first few times the vehicle is turned on
when a different remote key is used.
For Seat Entry Memory to work
properly, save positions to the 1 or
2 memory button matching the driver
number of this welcome message. To
aid in identifying remote key IDs, it is
recommended to only carry one remote key when entering the vehicle.
Perform the following if the welcome
message is not displayed:
1. Move all remote keys away from the vehicle.
2. Start the vehicle with another remote key. A DIC welcome
message should display indicating
the driver number of the other
remote key. Turn the vehicle off
and remove the other remote key
from the vehicle.
3. Start the vehicle with the initial remote key. The DIC welcome
message should display the driver
number of the initial remote key.
Saving Seating Positions
Read these instructions completely
before saving memory positions.
To save preferred driving positions to
1 and 2: 1. Turn the vehicle on or to ACC/ ACCESSORY. A DIC welcome
message may indicate the driver
number of the current remote key.
See “Identifying Driver Number”
previously in this section.
Page 48 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
SEATS AND RESTRAINTS 47
2. Adjust all available memoryfeatures to the desired driving
position.
3. Press and release SET; a beep will sound.
4. Immediately upon releasing SET, press and hold memory button 1 or
2 matching the current Driver’s
remote key number until two beeps
sound. If too much time passes
between releasing SET and pressing
1 or 2, the two beeps will not
sound indicating memory position
were not saved. Repeat Steps 3 and
4 to try again.
5. Repeat Steps 1–4 for the other remote key 1 or 2 using the other 1
or 2 memory button.
It is recommended to save the
preferred driving positions to both
1 and 2 if you are the only driver.
To save the common exit seating
position to
Bthat is used by all
drivers for Manually Recalling Seating
Positions and Auto Seat Exit Memory
Recall features, repeat Steps 1–4 using
B, the exit button. Manually Recalling Seating
Positions
Press and hold 1, 2, or
Bbutton until
the recall is complete, to recall the
positions previously saved to that
button.
Manual Memory recall movement for
1, 2 or
Bbuttons may be initiated
and will complete to the saved
memory position if the vehicle is in or
out of P (Park).
Enable Automatic Recalls under
Vehicle Personalization Settings
.For Seat Entry Memory that begins
movement to the preferred driving
position of the 1 or 2 button when
the vehicle is turned on, select the
Settings menu, then Vehicle, then
Seating Position, then Seat Entry
Memory, and then Select ON or
OFF. See “Auto Seat Entry Memory
Recall” later in this section.
.For Seat Exit Memory that begins
movement to the preferred exit
position of the
Bbutton when the
vehicle is turned off and the driver
door is open or opened, select the
Settings menu, then Vehicle, then Seating Position, then Seat Exit
Memory, and then Select ON or
OFF. See
“Auto Seat Exit Memory
Recall” later in this section.
.SeeVehicle Personalization 0140 for
additional setting information.
Auto Seat Entry Memory Recall
Seat Entry Memory will automatically
begin movement to the seating
positions of the 1 or 2 button
corresponding to the driver’s remote
key number 1 or 2 detected by the
vehicle when:
.The vehicle is turned ON.
.Seating positions have been
previously saved to the same 1 or 2
button. See “Saving Seating
Positions” previously in this section.
.Seat Entry Memory is enabled. See
“Enable Automatic Recalls” under
“Vehicle Personalization Settings”
previously in this section.
.The shift lever is in P (Park).
Seat Entry Memory Recall will
continue if the vehicle is shifted out
of P (Park) prior to reaching the saved
memory position.
Page 49 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
48 SEATS AND RESTRAINTS
If the saved memory seat position
does not automatically recall, verify
the recall is enabled. See“Enable
Automatic Recalls” under“Vehicle
Personalization Settings” previously in
this section.
If the memory seat recalls to the
wrong position, the driver’s remote
key number 1 or 2 may not match the
memory button number positions
they were saved to. Try the other
remote key or try saving the positions
to the other 1 or 2 memory button.
See “Saving Seating Positions ”
previously in this section.
Automatic Seat Entry Memory recalls
are only available for driver’s remote
key numbers 1 and 2. Remote keys
3–8 will not provide Seat Entry
Memory recalls.
Auto Seat Exit Memory Recall
Seat Exit Memory will begin
movement to the seating position of
the
Bbutton when:
.The vehicle is turned off and the
driver door is open or opened
within a short time.
.A seating position has been
previously been saved to the
B
memory button. See “Saving Seating
Positions” previously in this section
.Seat Exit Memory is enabled. See
“Enable Automatic Recalls” under
“Vehicle Personalization Settings”
previously in this section.
.The shift lever is in P (Park).
Seat Exit Memory recall will continue
if the vehicle is shifted out of P (Park)
prior to reaching the saved memory
position.
Seat Exit Memory is not linked to the
driver’s remote key. The seating
position saved to
Bis used for all
drivers.
Cancel Memory Seating Recalls
.During any memory recall:
Press a power seat control
Press SET memory button
.During Manual memory recall:
Release 1, 2, or
Bmemory button
.During Auto Seat Entry Memory
Recall:
Turn vehicle off Press SET, 1, 2, or
Bmemory
buttons
.During Auto Seat Exit Memory
Recall:
Press SET, 1, 2, or
Bmemory
buttons
Obstructions
If something has blocked the seat
while recalling a memory position, the
recall may stop. Remove the
obstruction and try the recall again.
If the memory position still does not
recall, see your dealer.
Heated and Ventilated
Front Seats
{Warning
If temperature change or pain to
the skin cannot be felt, the seat
heater may cause burns. To reduce
the risk of burns, use care when
using the seat heater, especially for
long periods of time. Do not place
anything on the seat that insulates
against heat, such as a blanket, (Continued)
Page 50 of 508
Cadillac Escalade Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
15567102) - 2022 - CRC - 11/17/21
SEATS AND RESTRAINTS 49
Warning (Continued)
cushion, cover, or similar item. This
may cause the seat heater to
overheat. An overheated seat heater
may cause a burn or may damage
the seat.
Heated and Ventilated Seat ButtonsShown, Heated Seat Buttons Similar
If equipped, the buttons are located
on the door panel. To operate, the
engine must be running.
Press
Jorzto heat the driver or
passenger seat back and cushion. Press
Ior+to heat the driver or
passenger seat back.
Press
Cor{, if available, to ventilate
the driver or passenger seat.
A ventilated seat has a fan that pulls
or pushes air through the seat. The air
is not cooled.
When this feature is off, the heated
and ventilated seat symbols on the
buttons are white. When a heated seat
is turned on, the symbol turns red.
When a ventilated seat is turned on,
the symbol turns blue.
Press the button once for the highest
setting. With each press of the button,
the seat will change to the next lower
setting, and then to the off setting.
The indicator lights next to the
buttons indicate three for the highest
setting and one for the lowest. If the
heated seats are on high, the level
may automatically be lowered after
approximately 30 minutes.
The passenger seat may take longer to
heat up. Auto Heated and Ventilated Seats
When the vehicle is on, this feature
will automatically activate the heated
or ventilated seats at the level
required by the vehicle’s interior
temperature.
The active high, medium, low, or off
heated or ventilated seat level will be
indicated by the manual heated or
ventilated seat buttons on the door
panel. Use the manual heated or
ventilated seat buttons on the door
panel to turn auto heated or
ventilated seats off. If the passenger
seat is unoccupied, the auto heated or
ventilated seats feature will not
activate that seat. The auto heated or
ventilated seats feature can be
programmed to always be enabled
when the vehicle is on.
See
Vehicle Personalization 0140.
Remote Start Heated and Ventilated
Seats
During a remote start, the heated or
ventilated seats, if equipped, can be
turned on automatically. When it is
cold outside, the heated seats turn on,
and when it is hot outside the
