Black plate (4,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Every Engine Oil Change .
Change engine oil and filter. See Engine Oil on
page 7 ‑ 17 . An Emission Control Service..
Engine coolant level check. See Engine Coolant
on page 7 ‑ 29 ..
Windshield washer fluid level check. See
Windshield Washer Fluid on page 7 ‑ 39 ..
Tire inflation check. See Inflation - Tire Pressure
on page 7 ‑ 65 ..
Tire wear inspection. See Tire Inspection and
Rotation on page 7 ‑ 71 ..
Rotate tires. See Tire Inspection and Rotation on
page 7 ‑ 71 ..
Fluids visual leak check (or every 12 months,
whichever occurs first). A leak in any system must
be repaired and the fluid level checked. .
Engine air cleaner filter inspection. See Engine Air
Cleaner/Filter on page 7 ‑ 22 ..
Brake system inspection (or every 12 months,
whichever occurs first). .
Lubricate the front suspension, steering linkage,
and parking brake cable guides. Control arm ball
joints are maintenance ‐ free..
Steering and suspension inspection. Visual
inspection for damaged, loose, or missing parts or
signs of wear. .
Engine cooling system inspection. Visual
inspection of hoses, pipes, fittings, and clamps and
replacement, if needed. .
Windshield wiper blade inspection for wear,
cracking, or contamination and windshield and
wiper blade cleaning, if contaminated. See
Windshield, Backglass, and Wiper Blades
on
page 7 ‑ 105 . Worn or damaged wiper blade
replacement. See Windshield Wiper Blade
Replacement on page 7 ‑ 57 . .
Body hinges and latches, key lock cylinders, rear
compartment hinges, outer tailgate handle pivot
points, and folding seat hardware lubrication.
See Recommended Fluids and Lubricants on
page 8 ‑ 10
. More frequent lubrication may be
required when vehicle is exposed to a corrosive
environment. Applying silicone grease on
weatherstrips with a clean cloth makes them last
longer, seal better, and not stick or squeak. .
Restraint system component check. See Checking
the Restraint Systems on page 2 ‑ 91 . .
Automatic transmission fluid level check and
adding fluid, if needed. See Automatic
Transmission Fluid on page 7 ‑ 24 .
8-4

Black plate (9,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Ignition Transmission Lock Check While parked, and with the parking brake set, try to turn
the ignition to LOCK/OFF in each shift lever position. .
The ignition should turn to LOCK/OFF only when
the shift lever is in P (Park). .
The ignition key should come out only in
LOCK/OFF.
Contact your dealer if service is required.
Parking Brake and Automatic
Transmission P (Park) Mechanism
Check
{ WARNING: When you are doing this check, the vehicle could
begin to move. You or others could be injured and
property could be damaged. Make sure there is
room in front of the vehicle in case it begins to
roll. Be ready to apply the regular brake at once
should the vehicle begin to move. Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake. .
To check the parking brake's holding ability: With
the engine running and the transmission in
N (Neutral), slowly remove foot pressure from the
regular brake pedal. Do this until the vehicle is held
by the parking brake only. .
To check the P (Park) mechanism's holding ability:
With the engine running, shift to P (Park). Then
release the parking brake followed by the regular
brake.
Contact your dealer if service is required.
8-9

Black plate (10,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Recommended Fluids and
Lubricants Fluids and lubricants identified below by name, part
number, or specification can be obtained from your
dealer.
Usage Fluid/Lubricant
Engine Oil The engine requires a special engine
oil meeting GM Standard GM4718M.
Oils meeting this standard can be
identified as synthetic, and should
also be identified with the American
Petroleum Institute (API) Certified for
Gasoline Engines starburst symbol.
However, not all synthetic API oils
with the starburst symbol will meet
this GM standard. Look for and use
only oil that meets GM Standard
GM4718M. For the proper viscosity,
see Engine Oil on page 7 ‑ 17 . Usage Fluid/Lubricant
Engine Coolant 50/50 mixture of clean, drinkable
water and use only DEX-COOL ®
Coolant. See Engine Coolant on
page 7 ‑ 29
.
Hydraulic Brake
System DOT 3 Hydraulic Brake Fluid
(GM Part No. U.S. 12377967, in
Canada 89021320).
Windshield
Washer Optikleen ®
Washer Solvent.
Power Steering
System GM Power Steering Fluid
(GM Part No. U.S. 89021184, in
Canada 89021186).
Automatic
Transmission DEXRON ®
-VI Automatic Transmission
Fluid.
Key Lock
Cylinders Multi-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474).
8-10

Black plate (21,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
OnStar ®
If your vehicle is equipped with an active OnStar
system, that system may also record data in crash or
near crash ‐ like situations. The OnStar Terms and
Conditions provides information on data collection and
use and is available in the OnStar glove box kit, at
www.onstar.com (U.S.) or www.onstar.ca (Canada),
or by pressing the
Q button and speaking to an
advisor.
Navigation System If the vehicle has a navigation system, use of the
system may result in the storage of destinations,
addresses, telephone numbers, and other trip
information. Refer to the navigation system operating
manual for information on stored data and for deletion
instructions. Radio Frequency
Identification (RFID) RFID technology is used in some vehicles for functions
such as tire pressure monitoring and ignition system
security, as well as in connection with conveniences
such as key fobs for remote door locking/unlocking and
starting, and in-vehicle transmitters for garage door
openers. RFID technology in GM vehicles does not use
or record personal information or link with any other
GM system containing personal information.
Radio Frequency Statement This vehicle has systems that operate on a radio
frequency that comply with Part 15 of the Federal
Communications Commission (FCC) rules and with
Industry Canada Standards RSS ‐ 210/220/310.
Operation is subject to the following two conditions:
1. The device may not cause interference.
2. The device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modifications to any of these systems by
other than an authorized service facility could void
authorization to use this equipment.
9-21

Black plate (5,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . . . 4-41
DIC Operation and Displays . . . . . . . . . . . . . . . . . . . . . . 4-42
DIC Vehicle Customization . . . . . . . . . . . . . . . . . . . . . . . 4-58
DIC Warnings and Messages . . . . . . . . . . . . . . . . . . . . . 4-49
Driving
At Night . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-24
Before a Long Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Highway Hypnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Hill and Mountain Roads . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27
In Rain and on Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . 6-25
Loss of Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Off-Road . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-11
Recovery Hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-31
Rocking Your Vehicle to Get it Out . . . . . . . . . . . . . . . . 6-30
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-28
Driving for Better Fuel Economy . . . . . . . . . . . . . . . . . . . 1-25
Dual Automatic Climate Control System . . . . . . . . . . . 4-20
DVD
Rear Seat Entertainment System . . . . . . . . . . . 4-78, 4-87 E E85 Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-9
EDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-19
Electrical Equipment, Add-On . . . . . . . . . . . . . . . . . . . . 7-109
Electrical System
Center Instrument Panel Fuse Block . . . . . . . . . . . . . 7-112
Fuses and Circuit Breakers . . . . . . . . . . . . . . . . . . . . . . 7-110
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . 7-110
Power Windows and Other Power Options . . . . . . 7-110
Underhood Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . 7-113
Windshield Wiper Fuses . . . . . . . . . . . . . . . . . . . . . . . . .7-109
Electronic Immobilizer
PASS-Key ®
III+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
Electronic Immobilizer Operation
PASS-Key ®
III+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
Engine
Air Cleaner/Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-22
Check and Service Engine Soon Light . . . . . . . . . . . . 4-36
Compartment Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-16
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-29
Coolant Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . 4-35
i - 5

Black plate (8,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
IIgnition Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
Infants and Young Children, Restraints . . . . . . . . . . . . 2-52
Inflation - Tire Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-65
Instrument Panel
Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Instrument Panel Cluster . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
Integrated Trailer Brake Control System (ITBC) . . . . 6-42
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2
JJump Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-44
KKeyless Entry
Remote (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Keyless Entry System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
LLabeling, Tire Sidewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-60
Lamps
Back-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
Daytime Running (DRL) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Dome Lamp Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17 Lamps (cont.)
License Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-56
Malfunction Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36
Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Lap Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-47
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
LATCH System for Child Restraints . . . . . . . . . . . . . . . . 2-59
LED Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-41
Liftgate, Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Liftgate/Liftglass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Liftglass/Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Lighting
Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
Lights
Airbag Readiness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
Antilock Brake System (ABS) Warning . . . . . . . . . . . . 4-34
Brake System Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33
Charging System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
Exterior Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Front Fog Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
High/Low Beam Changer . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Highbeam On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
Lights On Reminder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
i - 8

Black plate (11,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
PASS-Key ®
III+ Electronic Immobilizer . . . . . . . . . . . . . 3-24
PASS-Key ®
III+ Electronic Immobilizer
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . 4-31
Passenger Sensing System . . . . . . . . . . . . . . . . . . . . . . . 2-84
Passing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
Perchlorate Materials Requirements, California . . . . . .7-5
Phone
Bluetooth ®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-68
Power
Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-110
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Lumbar Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Reclining Seatbacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Retained Accessory (RAP) . . . . . . . . . . . . . . . . . . . . . . . 3-28
Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Steering Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-38
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Power Assist Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Pregnancy, Using Safety Belts . . . . . . . . . . . . . . . . . . . . . 2-47
Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-19
Navigation System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
Radio Frequency Identification (RFID) . . . . . . . . . . . . 9-21
Problems with Route Guidance . . . . . . . . . . . . . . . . . . . . 5-58 Program
Courtesy Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11
Programmable Automatic Door Locks . . . . . . . . . . . . . 3-11
Proposition 65 Warning, California . . . . . . . . . . . . . . . . . . .7-5
R Radio Frequency
Identification (RFID) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-21
Radios
Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-108
Theft-Deterrent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-106
Reading Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Rear Air Conditioning and Heating System and
Electronic Climate Controls . . . . . . . . . . . . . . . . . . . . . . 4-26
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-50
Locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Rear Door Security Locks . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Rear Heated Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Rear Seat Armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
Rear Seat Audio (RSA) System . . . . . . . . . . . . . . . . . . 4-104
Rear Seat Entertainment System . . . . . . . . . . . . 4-78, 4-87
Rear Seat Audio (RSA) . . . . . . . . . . . . . . . . . . . . . . . . . .4-104
Rear Side Window Antenna . . . . . . . . . . . . . . . . . . . . . . 4-109
Rear Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
i - 11

Black plate (12,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Rear Vision Camera (RVC) . . . . . . . . . . . . . . . . . . . . . . . . 3-51
Rear Window Washer/Wiper . . . . . . . . . . . . . . . . . . . . . . . . .4-7
Rearview Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-43
Automatic Dimming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-43
Reclining Seatbacks, Power . . . . . . . . . . . . . . . . . . . . . . . . .2-8
Recommended Fluids and Lubricants . . . . . . . . . . . . . 8-10
Recovery Hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-31
Recreational Vehicle Towing . . . . . . . . . . . . . . . . . . . . . . . 6-38
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . .9-7
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . .3-4
Remote Vehicle Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
Removing the Flat Tire and Installing the
Spare Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-86
Removing the Spare Tire and Tools . . . . . . . . . . . . . . . . 7-81
Replacement Bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-56
Replacement Parts
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12
Reporting Safety Defects
Canadian Government . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
General Motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18
U.S. Government . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
Restraint System Check
Checking the Restraint Systems . . . . . . . . . . . . . . . . . . 2-91
Replacing Restraint System Parts After a
Crash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-92
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . 3-28 Ride Control Systems
Road Sensing Suspension . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Road Sensing Suspension . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Roadside Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-8
Rocking Your Vehicle to Get it Out . . . . . . . . . . . . . . . . . 6-30
Roof
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
Roof Rack System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-64
Running the Vehicle While Parked . . . . . . . . . . . . . . . . . 3-42
S Safety Belts
Care of . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-103
Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-48
How to Wear Safety Belts Properly . . . . . . . . . . . . . . . 2-30
Lap Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-47
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-39
Reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Safety Belts Are for Everyone . . . . . . . . . . . . . . . . . . . . 2-26
Use During Pregnancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-47
Safety Defects Reporting
Canadian Government . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
General Motors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18
U.S. Government . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-17
Safety Warnings and Symbols . . . . . . . . . . . . . . . . . . . . . . . . iv
Scheduled Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-3
Scheduling Appointments . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11
i - 12

Black plate (14,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Storage Areas (cont.)
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
Rear Seat Armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
Roof Rack System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-64
Stuck in Sand, Mud, Ice, or Snow . . . . . . . . . . . . . . . . . 6-30
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
System
Roof Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-64
System Needs Service, If . . . . . . . . . . . . . . . . . . . . . . . . . . 5-59
TTachometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Text Telephone (TTY) Users . . . . . . . . . . . . . . . . . . . . . . . . .9-6
Theft-Deterrent Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-106
Theft-Deterrent Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
Content Theft-Deterrent . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
PASS-Key ®
III+ Electronic Immobilizer . . . . . . . . . . . . 3-24
PASS-Key ®
III+ Electronic Immobilizer
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
Third Row Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Throttle, Adjustable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
Tilt Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-58
Aluminum or Chrome-Plated Wheels,
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-106
Buying New Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-73
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-78
Changing a Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-80
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-107
Different Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-75
High-Speed Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-66
If a Tire Goes Flat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-79
Inflation - Tire Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-65
Inspection and Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . 7-71
Installing the Spare Tire . . . . . . . . . . . . . . . . . . . . . . . . . . 7-86
Pressure Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
Pressure Monitor Operation . . . . . . . . . . . . . . . . . . . . . . 7-68
Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . . . . 7-67
Removing the Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-86
Removing the Spare Tire and Tools . . . . . . . . . . . . . . . 7-81
Secondary Latch System . . . . . . . . . . . . . . . . . . . . . . . . . 7-91
Sidewall Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-60
Spare Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-98
Storing a Flat or Spare Tire and Tools . . . . . . . . . . . . 7-94
Terminology and Definitions . . . . . . . . . . . . . . . . . . . . . . 7-62
Uniform Tire Quality Grading . . . . . . . . . . . . . . . . . . . . . 7-76
i - 14
