Black plate (65,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Notice: Loading cargo on the roof rack that weighs
more than 91 kg (200 lbs) or hangs over the rear or
sides of the vehicle may damage the vehicle. Load
cargo so that it rests evenly between the crossrails,
making sure to fasten cargo securely.
To prevent damage or loss of cargo when driving, check
to make sure crossrails and cargo are securely
fastened. Loading cargo on the roof rack will make the
vehicle ’ s center of gravity higher. Avoid high speeds,
sudden starts, sharp turns, sudden braking or abrupt
maneuvers, otherwise it may result in loss of control.
If driving for a long distance, on rough roads, or at high
speeds, occasionally stop the vehicle to make sure the
cargo remains in its place.
Do not exceed the maximum vehicle capacity when
loading the vehicle. For more information on vehicle
capacity and loading, see Loading the Vehicle
on
page 6 ‑ 32 .
To prevent damage or loss of cargo, check now and
then to make sure the luggage and cargo are still
securely fastened.
Be sure the cargo is properly loaded. .
If small heavy objects are placed on the roof, place
the load in the area over the rear wheels (behind
the rear side door on extended models). If needed,
cut a piece of 3/8 inch plywood to fit inside the
crossrails and siderails to spread the load.
If plywood is used, tie it to the siderail supports. .
Tie the load to the crossrails or the siderail
supports. Use the crossrails only to keep the load
from sliding. To move the crossrails, pull out on the
latch release handle at each end. Slide the
crossrail to the desired position balancing the force
side to side. Push the release handle back into the
latched position and slide the crossrail back and
forth slightly to be sure the latch snaps securely
into place. .
If needed to carry long items, move the crossrails
as far apart as they will go. Tie the load to the
crossrails and the siderails or siderail supports.
Also tie the load to the bumpers. Do not tie the
load so tightly that the crossrails or siderails are
damaged. .
After moving a crossrail, be sure it is securely
locked into the siderail.
A Center High-Mounted Stoplamp (CHMSL) is located
above the glass or above the rear load doors.
If items are loaded on the roof of the vehicle, care
should be taken not to block or damage the
CHMSL unit.
3-65

Black plate (32,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Loading the Vehicle It is very important to know how much weight your
vehicle can carry. This weight is called the vehicle
capacity weight and includes the weight of all
occupants, cargo, and all nonfactory-installed
options. Two labels on your vehicle show how
much weight it was designed to carry, the Tire and
Loading Information label and the Certification/Tire
label.
{ WARNING: Do not load the vehicle any heavier than the
Gross Vehicle Weight Rating (GVWR),
or either the maximum front or rear Gross
Axle Weight Rating (GAWR). If you do, parts
on the vehicle can break, and it can change
the way the vehicle handles. These could
cause you to lose control and crash. Also,
overloading can shorten the life of the
vehicle. Tire and Loading Information Label
Label Example
A vehicle specific Tire and Loading Information
label is attached to the center pillar (B-pillar).
With the driver's door open, you will find the label
attached below the door lock post (striker).
The tire and loading information label shows the
number of occupant seating positions (A), and the
maximum vehicle capacity weight (B) in kilograms
and pounds.
6-32

Black plate (33,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
The Tire and Loading Information label also
shows the size of the original equipment tires (C)
and the recommended cold tire inflation
pressures (D). For more information on tires and
inflation see Tires
on page 7 ‑ 58 and Inflation - Tire
Pressure
on page 7 ‑ 65 .
There is also important loading information on the
vehicle Certification/Tire label. It tells you the
Gross Vehicle Weight Rating (GVWR) and the
Gross Axle Weight Rating (GAWR) for the front
and rear axles. See “ Certification/Tire Label ” later
in this section.
Steps for Determining Correct Load Limit 1.
Locate the statement “ The combined weight
of occupants and cargo should never exceed
XXX kg or XXX lbs ” on your vehicle's placard.2.
Determine the combined weight of the driver
and passengers that will be riding in your
vehicle.
3.
Subtract the combined weight of the driver
and passengers from XXX kg or XXX lbs. 4.
The resulting figure equals the available
amount of cargo and luggage load capacity.
For example, if the “ XXX ” amount equals
1400 lbs and there will be five 150 lb
passengers in your vehicle, the amount of
available cargo and luggage load capacity is
650 lbs (1400 − 750 (5 x 150) = 650 lbs).5.
Determine the combined weight of luggage
and cargo being loaded on the vehicle. That
weight may not safely exceed the available
cargo and luggage load capacity calculated in
Step 4. 6.
If your vehicle will be towing a trailer, the load
from your trailer will be transferred to your
vehicle. Consult this manual to determine
how this reduces the available cargo and
luggage load capacity of your vehicle. See
Towing a Trailer
on page 6 ‑ 42 for important
information on towing a trailer, towing safety
rules and trailering tips.
6-33

Black plate (35,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Example 3
Item Description Total
A Vehicle Capacity
Weight for
Example 3 = 1,000 lbs
(453 kg)
B Subtract Occupant
Weight @ 200 lbs
(91 kg) × 5 = 1,000 lbs
(453 kg)
C Available Cargo
Weight = 0 lbs (0 kg)
Refer to your vehicle's tire and loading information
label for specific information about your vehicle's
capacity weight and seating positions. The combined weight of the driver, passengers,
and cargo should never exceed your vehicle's
capacity weight.
Certification/Tire Label
A vehicle specific Certification/Tire label is
attached to the rear edge of the driver's door.
The label shows the size of your vehicle's original
tires and the inflation pressures needed to obtain
the gross weight capacity of your vehicle. This is
called Gross Vehicle Weight Rating (GVWR).
The GVWR includes the weight of the vehicle,
all occupants, fuel, and cargo.
6-35

Black plate (42,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
If a weight ‐ distributing hitch is being used, it is
recommended to allow the shocks to inflate, thereby
leveling the vehicle prior to adjusting the hitch.
Autoride ®
With this feature, improved vehicle ride and handling is
provided under a variety of passenger and loading
conditions.
The system is fully automatic and uses a computer
controller to continuously monitor vehicle speed, wheel
to body position, lift/dive and steering position of the
vehicle. The controller then sends signals to each shock
absorber to independently adjust the damping level to
provide the optimum vehicle ride.
Autoride also interacts with the tow/haul mode that,
when activated, will provide additional control of the
shock absorbers. This additional control results in better
ride and handling characteristics when the vehicle is
loaded or towing a trailer. See “ Tow/Haul Mode ” under
Towing a Trailer
on page 6 ‑ 42 for more information.
Towing a Trailer If the vehicle has a two – mode hybrid engine, see the
Two – mode Hybrid manual for more information.
Do not tow a trailer during break ‐ in. See New Vehicle
Break-In on page 3 ‑ 26 for more information. { WARNING: The driver can lose control when pulling a trailer if
the correct equipment is not used or the vehicle is
not driven properly. For example, if the trailer is
too heavy, the brakes may not work well — or
even at all. The driver and passengers could be
seriously injured. The vehicle may also be
damaged; the resulting repairs would not be
covered by the vehicle warranty. Pull a trailer only
if all the steps in this section have been followed.
Ask your dealer for advice and information about
towing a trailer with the vehicle.
Notice: Pulling a trailer improperly can damage the
vehicle and result in costly repairs not covered by
the vehicle warranty. To pull a trailer correctly,
follow the advice in this section and see your dealer
for important information about towing a trailer with
the vehicle.
To identify the trailering capacity of the vehicle, read the
information in “ Weight of the Trailer ” that appears later
in this section.
6-42

Black plate (45,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Weight of the Trailer Tongue The tongue load (A) of any trailer is very important
because it is also part of the vehicle weight. The Gross
Vehicle Weight (GVW) includes the curb weight of the
vehicle, any cargo carried in it, and the people who will
be riding in the vehicle as well as trailer tongue weight.
Vehicle options, equipment, passengers and cargo in
the vehicle reduce the amount of tongue weight the
vehicle can carry, which will also reduce the trailer
weight the vehicle can tow. See Loading the Vehicle
on
page 6 ‑ 32 for more information about the vehicle's
maximum load capacity.
Trailer tongue weight (A) should be 10 percent to
15 percent and fifth wheel or gooseneck kingpin weight
should be 15 to 25 percent of the loaded trailer weight
up to the maximums for vehicle series and hitch type
shown below:
Vehicle Series Hitch Type Maximum
Tongue Weight
1500 Weight Carrying 272 kg (600 lbs)
1500 Weight Distributing 499 kg (1,100 lbs)
Do not exceed the maximum allowable tongue weight
for the vehicle. Choose the shortest hitch extension that
will position the hitch ball closest to the vehicle. This will
help reduce the effect of trailer tongue weight on the
rear axle.
6-45

Black plate (61,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
(G) Maximum Cold Inflation Load Limit :
Maximum load that can be carried and the
maximum pressure needed to support that load.
For information on recommended tire pressure
see Inflation - Tire Pressure
on page 7 ‑ 65 and
Loading the Vehicle
on page 6 ‑ 32 .
Tire Size The following examples show the different parts of
a tire size.
Passenger (P ‐ Metric) Tire
(A) Passenger (P ‐ Metric) Tire :
The United States
version of a metric tire sizing system. The letter P
as the first character in the tire size means a
passenger vehicle tire engineered to standards
set by the U.S. Tire and Rim Association. (B) Tire Width :
The three ‐ digit number indicates
the tire section width in millimeters from sidewall
to sidewall.
(C) Aspect Ratio :
A two ‐ digit number that
indicates the tire height ‐ to ‐ width measurements.
For example, if the tire size aspect ratio is 75, as
shown in item C of the light truck (LT ‐ Metric) tire
illustration, it would mean that the tire's sidewall is
75% as high as it is wide.
(D) Construction Code :
A letter code is used to
indicate the type of ply construction in the tire.
The letter R means radial ply construction; the
letter D means diagonal or bias ply construction;
and the letter B means belted ‐ bias ply
construction.
(E) Rim Diameter :
Diameter of the wheel in
inches.
(F) Service Description :
These characters
represent the load index and speed rating of the
tire. The load index represents the load carry
capacity a tire is certified to carry. The speed
rating is the maximum speed a tire is certified to
carry a load.
7-61

Black plate (62,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Tire Terminology and Definitions Air Pressure :
The amount of air inside the tire
pressing outward on each square inch of the tire.
Air pressure is expressed in pounds per square
inch (psi) or kilopascal (kPa).
Accessory Weight :
This means the combined
weight of optional accessories. Some examples of
optional accessories are, automatic transmission,
power steering, power brakes, power windows,
power seats, and air conditioning.
Aspect Ratio :
The relationship of a tire's height to
its width.
Belt :
A rubber coated layer of cords that is
located between the plies and the tread. Cords
may be made from steel or other reinforcing
materials.
Bead :
The tire bead contains steel wires wrapped
by steel cords that hold the tire onto the rim.
Bias Ply Tire :
A pneumatic tire in which the plies
are laid at alternate angles less than 90 degrees
to the centerline of the tread. Cold Tire Pressure :
The amount of air pressure
in a tire, measured in pounds per square inch (psi)
or kilopascals (kPa) before a tire has built up heat
from driving. See Inflation - Tire Pressure
on
page 7 ‑ 65
.
Curb Weight :
The weight of a motor vehicle with
standard and optional equipment including the
maximum capacity of fuel, oil, and coolant, but
without passengers and cargo.
DOT Markings :
A code molded into the sidewall
of a tire signifying that the tire is in compliance
with the U.S. Department of Transportation (DOT)
motor vehicle safety standards. The DOT code
includes the Tire Identification Number (TIN), an
alphanumeric designator which can also identify
the tire manufacturer, production plant, brand, and
date of production.
GVWR :
Gross Vehicle Weight Rating.
See Loading the Vehicle
on page 6 ‑ 32 .
GAWR FRT :
Gross Axle Weight Rating for the
front axle. See Loading the Vehicle on page 6 ‑ 32 .
GAWR RR :
Gross Axle Weight Rating for the rear
axle. See Loading the Vehicle
on page 6 ‑ 32 .
7-62

Black plate (63,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Intended Outboard Sidewall :
The side of an
asymmetrical tire, that must always face outward
when mounted on a vehicle.
Kilopascal (kPa) :
The metric unit for air pressure.
Light Truck (LT ‐ Metric) Tire :
A tire used on light
duty trucks and some multipurpose passenger
vehicles.
Load Index :
An assigned number ranging from
1 to 279 that corresponds to the load carrying
capacity of a tire.
Maximum Inflation Pressure :
The maximum
air pressure to which a cold tire can be inflated.
The maximum air pressure is molded onto the
sidewall.
Maximum Load Rating :
The load rating for a tire
at the maximum permissible inflation pressure for
that tire.
Maximum Loaded Vehicle Weight :
The sum of
curb weight, accessory weight, vehicle capacity
weight, and production options weight.
Normal Occupant Weight :
The number of
occupants a vehicle is designed to seat multiplied
by 150 lbs (68 kg). See Loading the Vehicle
on
page 6 ‑ 32 . Occupant Distribution :
Designated seating
positions.
Outward Facing Sidewall :
The side of an
asymmetrical tire that has a particular side that
faces outward when mounted on a vehicle.
The side of the tire that contains a whitewall,
bears white lettering, or bears manufacturer,
brand, and/or model name molding that is higher
or deeper than the same moldings on the other
sidewall of the tire.
Passenger (P-Metric) Tire :
A tire used on
passenger cars and some light duty trucks and
multipurpose vehicles.
Recommended Inflation Pressure :
Vehicle
manufacturer's recommended tire inflation
pressure as shown on the tire placard. See
Inflation - Tire Pressure
on page 7 ‑ 65 and Loading
the Vehicle
on page 6 ‑ 32 .
Radial Ply Tire :
A pneumatic tire in which the
ply cords that extend to the beads are laid at
90 degrees to the centerline of the tread.
Rim :
A metal support for a tire and upon which
the tire beads are seated.
Sidewall :
The portion of a tire between the tread
and the bead.
7-63

Black plate (64,1)Cadillac Escalade/Escalade ESV Owner Manual - 2010
Speed Rating :
An alphanumeric code assigned
to a tire indicating the maximum speed at which a
tire can operate.
Traction :
The friction between the tire and the
road surface. The amount of grip provided.
Tread :
The portion of a tire that comes into
contact with the road.
Treadwear Indicators :
Narrow bands, sometimes
called wear bars, that show across the tread of a
tire when only 1/16 inch (1.6 mm) of tread
remains. See When It Is Time for New Tires
on
page 7 ‑ 73
.
UTQGS (Uniform Tire Quality Grading
Standards) :
A tire information system that
provides consumers with ratings for a tire's
traction, temperature, and treadwear. Ratings
are determined by tire manufacturers using
government testing procedures. The ratings are
molded into the sidewall of the tire. See Uniform
Tire Quality Grading
on page 7 ‑ 76 . Vehicle Capacity Weight :
The number of
designated seating positions multiplied by 150 lbs
(68 kg) plus the rated cargo load. See Loading the
Vehicle
on page 6 ‑ 32 .
Vehicle Maximum Load on the Tire :
Load on
an individual tire due to curb weight, accessory
weight, occupant weight, and cargo weight.
Vehicle Placard :
A label permanently attached to
a vehicle showing the vehicle's capacity weight
and the original equipment tire size and
recommended inflation pressure. See “ Tire and
Loading Information Label ” under Loading the
Vehicle
on page 6 ‑ 32 .
7-64
