seat memory CADILLAC ESCALADE EXT 2007 3.G Owners Manual

Front Seats..................................................... 8
Power Seats................................................. 8
Power Lumbar.............................................. 9
Heated Seats.............................................. 10
Heated and Cooled Seats........................... 11
Memory Seat, Mirrors, and Pedals.............. 12
Power Reclining Seatbacks......................... 14
Head Restraints.......................................... 15
Rear Seats.................................................... 16
Rear Seat Operation................................... 16
Safety Belts.................................................. 18
Safety Belts: They Are for Everyone........... 18
Questions and Answers About Safety Belts.... 22
How to Wear Safety Belts Properly............. 23
Driver Position............................................. 23
Shoulder Belt Height Adjustment................. 30
Safety Belt Use During Pregnancy.............. 31
Right Front Passenger Position................... 31
Rear Seat Passengers................................ 32
Rear Safety Belt Comfort Guides................ 35
Safety Belt Pretensioners............................ 38
Safety Belt Extender................................... 38
Child Restraints............................................ 39
Older Children............................................. 39
Infants and Young Children......................... 42Child Restraint Systems.............................. 45
Where to Put the Restraint.......................... 50
Lower Anchors and Tethers for
Children (LATCH).................................... 51
Securing a Child Restraint in a Rear
Seat Position........................................... 60
Securing a Child Restraint in the Right
Front Seat Position.................................. 62
Airbag System.............................................. 67
Where Are the Airbags?.............................. 70
When Should an Airbag Inate?.................. 73
What Makes an Airbag Inate?................... 75
How Does an Airbag Restrain?................... 76
What Will You See After an Airbag
Inates?................................................... 76
Passenger Sensing System......................... 78
Servicing Your Airbag-Equipped Vehicle...... 84
Adding Equipment to Your
Airbag-Equipped Vehicle.......................... 85
Restraint System Check............................... 86
Checking the Restraint Systems.................. 86
Replacing Restraint System Parts
After a Crash........................................... 87
Section 1 Seats and Restraint Systems
7

Front Seats
Power Seats
The power seat controls are located on the
outboard side of the front seats.
Move the seat forward or rearward by sliding
the control forward or rearward.
Raise or lower the front part of the seat cushion
by moving the front of the control up or down.
Raise or lower the rear part of the seat cushion
by moving the rear of the control up or down.
Raise or lower the entire seat by moving the
entire control up or down.
The power reclining seatback control is located
behind the power seat control on the outboard side
of the seats. SeePower Reclining Seatbacks on
page 14.
Your vehicle has a memory function which allows
seat settings to be saved and recalled. See
Memory Seat, Mirrors, and Pedals on page 12.
Driver’s Seat with Power Seat Control, Power
Recline, and Power Lumbar shown
8

Power Lumbar
If the seats have power lumbar, the controls
used to operate this feature are located on the
outboard side of the seats.
To increase lumbar support, press and hold
the front of the control.
To decrease lumbar support, press and hold
the rear of the control.
To raise the height of the lumbar support,
press and hold the top of the control.
To lower the height of the lumbar support,
press and hold the bottom of the control.
Release the control when the lower seatback
reaches the desired level of lumbar support.
Your vehicle may have a memory function which
allows seat settings to be saved and recalled.
SeeMemory Seat, Mirrors, and Pedals on page 12
for more information.
Keep in mind that as your seating position
changes, as it may during long trips, so should the
position of your lumbar support. Adjust the seat
as needed.
9

Memory Seat, Mirrors, and Pedals
Your vehicle has the memory package.
The controls for this
feature are located on
the driver’s door, and are
used to program and
recall memory settings
for the driver’s seat,
outside mirrors, and the
adjustable throttle and
brake pedal feature, if
your vehicle has it.
To save your positions in memory, do the
following:
1. Adjust the driver’s seat, including the seatback
recliner and lumbar, both outside mirrors, and
the throttle and brake pedals to a comfortable
position.SeeOutside Power Foldaway Mirrors on
page 149andAdjustable Throttle and Brake
Pedal on page 128for more information.
Not all mirrors will have the ability to save and
recall the mirror positions.
2. Press and hold button 1 until two beeps let
you know that the position has been stored.
A second seating, mirror, and throttle and brake
pedal position can be programmed by repeating
the above steps and pressing button 2.
To recall the memory positions, the vehicle must be
in PARK (P). Press and release either button 1 or
button 2 corresponding to the desired driving
position. The seat, outside mirrors, and adjustable
throttle and brake pedals will move to the position
previously stored. You will hear a single beep.
12

If you use the remote keyless entry transmitter to
enter your vehicle and the remote recall memory
feature is on, automatic seat, mirror, and
adjustable pedal movement will occur. See
“MEMORY SEAT RECALL” underDIC Vehicle
Customization on page 257for more information.
To stop recall movement of the memory feature
at any time, press one of the power seat controls,
memory buttons, power mirror buttons, or
adjustable pedal switch.
If something has blocked the driver’s seat and/or
the adjustable pedals while recalling a memory
position, the driver’s seat and/or the adjustable
pedals recall may stop working. If this happens,
remove the obstruction and press the appropriate
function control for two seconds. Then try
recalling the memory position again by pressing
the appropriate memory button. If the memory
position is still not recalling, see your dealer
for service.Easy Exit Seat
The control for this feature is located on the
driver’s door between buttons 1 and 2.
With the vehicle in PARK (P), the exit position can
be recalled by pressing the exit button. You will
hear a single beep. The driver’s seat will
move back.
If the easy exit seat feature is on in the Driver
Information Center (DIC), automatic seat
movement will occur when the key is removed
from the ignition. See “EASY EXIT SEAT” under
DIC Vehicle Customization on page 257for
more information.
Further programming for the memory seat feature
can be done using the DIC. You can select the
automatic easy exit seat feature or the remote
memory seat recall feature.
For programming information, seeDIC Vehicle
Customization on page 257.
13

CAUTION: (Continued)
The shoulder belt cannot do its job. In a
crash, you could go into it, receiving neck
or other injuries.
The lap belt cannot do its job either. In a
crash the belt could go up over your
abdomen. The belt forces would be there,
not at your pelvic bones. This could cause
serious internal injuries.
For proper protection when the vehicle is
in motion, have the seatback upright.
Then sit well back in the seat and wear
your safety belt properly.
Do not have a seatback reclined if your vehicle is
moving.
Your vehicle has a memory function which allows
seat settings to be saved and recalled. See
Memory Seat, Mirrors, and Pedals on page 12.
Head Restraints
Adjust the head restraint so that the top of the
restraint is at the same height as the top of
the occupant’s head. This position reduces the
chance of a neck injury in a crash.
15

Adjustable Throttle and Brake Pedal
Your vehicle has an adjustable throttle and
brake pedal that lets you change their positions.
This feature is designed for shorter drivers,
since the pedals can not move farther away from
the standard position, but can move toward
the driver for better pedal reach.
The feature will not operate when the vehicle is in
REVERSE (R) or while using the cruise control.
The switch used to adjust the pedals is located on
the center console below the climate control
system.
Press the right and left arrows to move the pedals
either closer or further from your body.Your vehicle has a memory function which allows
the pedals to be saved and recalled. See
Memory Seat, Mirrors, and Pedals on page 12for
more information.
Engine Coolant Heater
Your vehicle may have an engine coolant heater.
In very cold weather, 0°F (−18°C) or colder,
the engine coolant heater can help. You will get
easier starting and better fuel economy during
engine warm-up.
Usually, the coolant heater should be plugged in a
minimum of four hours prior to starting your
vehicle. At temperatures above 32°F (0°C), use of
the coolant heater is not required. Your vehicle
may also have an internal thermostat in the
plug end of the cord. This will prevent operation of
the engine coolant heater when the temperature
is at or above 0°F (−18°C) as noted on the cord.
128

LOUD:The chime volume will be set to a
loud level.
NO CHANGE:No change will be made to this
feature. The current setting will remain.
Choose one of the available settings and press
the set/reset button while it is displayed on the
DIC to select it.
PARK TILT MIRRORS
This feature allows you to select whether or
not the outside mirror(s) will automatically tilt down
when the vehicle is shifted into REVERSE (R).
SeeOutside Power Foldaway Mirrors on page 149
for more information.
Press the customization button until PARK TILT
MIRRORS appears on the DIC display. Press the
set/reset button once to access the settings for
this feature. Then press the customization button
to scroll through the following settings:
OFF (default):Neither outside mirror will be tilted
down when the vehicle is shifted into
REVERSE (R).DRIVER MIRROR:The driver’s outside mirror will
be tilted down when the vehicle is shifted into
REVERSE (R).
PASSENGER MIRROR:The passenger’s outside
mirror will be tilted down when the vehicle is
shifted into REVERSE (R).
BOTH MIRRORS:The driver’s and passenger’s
outside mirrors will be tilted down when the vehicle
is shifted into REVERSE (R).
NO CHANGE:No change will be made to this
feature. The current setting will remain.
Choose one of the available settings and press
the set/reset button while it is displayed on the
DIC to select it.
EASY EXIT SEAT
This feature allows you to select your preference
for the automatic easy exit seat feature. See
Memory Seat, Mirrors, and Pedals on page 12for
more information.
264

Press the customization button until EASY EXIT
SEAT appears on the DIC display. Press the
set/reset button once to access the settings for
this feature. Then press the customization button
to scroll through the following settings:
OFF (default):No automatic seat exit recall
will occur.
ON:The driver’s seat will move back when the
key is removed from the ignition.
The automatic easy exit seat movement will only
occur one time after the key is removed from
the ignition. If the automatic movement has already
occurred, and you put the key back in the
ignition and remove it again, the seat will stay in
the original exit position, unless a memory
recall took place prior to removing the key again.
NO CHANGE:No change will be made to
this feature. The current setting will remain.
Choose one of the available settings and press
the set/reset button while it is displayed on the
DIC to select it.MEMORY SEAT RECALL
This feature allows you to select your preference
for the remote memory seat recall feature.
SeeMemory Seat, Mirrors, and Pedals on
page 12for more information.
Press the customization button until MEMORY
SEAT RECALL appears on the DIC display. Press
the set/reset button once to access the settings
for this feature. Then press the customization
button to scroll through the following settings:
OFF (default):No remote memory seat recall
will occur.
ON:The driver’s seat will automatically move
to the stored driving position when the unlock
button on the Remote Keyless Entry (RKE)
transmitter is pressed.
NO CHANGE:No change will be made to this
feature. The current setting will remain.
Choose one of the available settings and press
the set/reset button while it is displayed on the
DIC to select it.
265

M
Maintenance Schedule
Additional Required Services.................... 525
At Each Fuel Fill...................................... 529
At Least Once a Month............................ 530
At Least Once a Year.............................. 530
Introduction.............................................. 520
Maintenance Footnotes............................ 527
Maintenance Record................................ 537
Maintenance Requirements...................... 520
Normal Maintenance
Replacement Parts............................... 535
Owner Checks and Services.................... 529
Recommended Fluids and Lubricants....... 533
Scheduled Maintenance........................... 523
Using....................................................... 521
Your Vehicle and the Environment............ 520
Malfunction Indicator Light........................... 236
Memory Seat, Mirrors, and Pedals................ 12Message
DIC Warnings and Messages................... 248
Midgate....................................................... 104
Mirrors
Automatic Dimming Mirror with
Intellibeam™, OnStar
®, Compass, and
Temperature Display............................. 143
Automatic Dimming Rearview with
OnStar
®, Compass and Temperature
Display................................................. 145
Outside Power Foldaway Mirrors.............. 149
MyGMLink.com............................................ 545
N
Navigation/Radio System, see Navigation
Manual..................................................... 302
New Vehicle Break-In.................................. 123
Normal Maintenance Replacement Parts..... 535
573
