2-49 Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine when
the battery is in a heavy discharge condition. During times
of high electrical loading, the engine may idle at a higher
revolutions per minute (rpm) setting than normal to make
sure the battery charges. High electrical loads may occur
when several of the following are on: headlamps, high
beams, fog lamps, rear window defogger, high blower fan,
heated seats and engine cooling fans.
If the battery continues to discharge, even with the
engine idling at a higher rpm setting, some electrical
loads will automatically be reduced. When this occurs,
the rear window defogger may take slightly longer to
clear the glass, the heated seats may not get as warm as
they usually do and the fan blower may cut back to a
lower speed. For more battery saving information, see
ªBattery Saver Active Messageº in the Index.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp, glove
box lamp, cigarette lighters or the garage door opener. When
the ignition is turned off, the power to these features will
automatically turn off after 10 minutes. Power will be
restored for an additional 10 minutes if any door is opened,
the trunk is opened or the courtesy lamp switch is turned on.
Mirrors
Electrochromic Day/Night Rearview Mirror
with Compass
Your vehicle has an electrochromic inside rearview
mirror with a compass.
By pressing the MIRROR side of the button located at
the bottom of the mirror, the position of the mirror
automatically changes to reduce glare from headlamps
behind you.

yellowblue
2-50
The mirror also includes an eight-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing.
Cleaning the Photocells
Use a cotton swab and glass cleaner to clean the
photocells when necessary.
Mirror Operation
The right side of the button, located at the bottom of the
mirror, turns the electrochromic mirror on and off. To
turn on the automatic dimming feature, press MIRROR.
To turn off the automatic dimming, press MIRROR
again. The indicator light will be illuminated when this
feature is active.
Time Delay
The automatic mirror has a time delay feature which
prevents unnecessary changing from the night back to
the day position. This delay prevents rapid changing of
the mirror as you drive under lights and through traffic.Compass Operation
Press the COMPASS side of the button to turn the
compass on or off.
When the ignition and the compass feature are on, the
compass will show two character boxes for
approximately two seconds. After two seconds, the
mirror will display the compass heading.
Compass Calibration
If, after two seconds, the display does not show a
compass heading (ªNº for North, for example), there
may be a strong magnetic field interfering with the
compass. Such interference may be caused by a
magnetic antenna mount, magnetic note pad holder or a
similar magnetic item. If the letter ªCº should ever
appear in the compass window, the mirror
needs calibration.
The mirror can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or less
until the display reads a direction, or

Drive the vehicle on your everyday routine.

yellowblue
2-51
Compass Variance
The mirror is set in zone eight upon leaving the factory.
It will be necessary to adjust the compass to compensate
for compass variance if you live outside zone eight.
Under certain circumstances, as during a long distance
cross
-country trip, it will be necessary to adjust for
compass variance. Compass variance is the difference
between earth's magnetic north and true geographic
north. If not adjusted to account for compass variance,
your compass could give false readings.
To adjust for compass variance:
1. Use the COMPASS side of the button located at the
bottom of the mirror. Press and hold COMPASS
until a zone number appears in the display.
2. Find your current location and variance zone number
on the following zone map.
3. Press COMPASS on the bottom of the mirror until
the new zone number appears in the display. After
you stop pressing the button, the display will show a
ªCº and will need recalibration.

yellowblue
2-52 Power Remote Control Mirror (Heated)
This feature is located on
the driver's door armrest.
Move the L/R select switch
located under the power
mirror control to choose the
left or right mirror.
To adjust the mirror, move the arrow control in the
direction you want the mirror to go. Leave the L/R
select switch in the center position to disable mirror
movement by the four
-arrow control switch. This is
helpful in preventing unwanted mirror movement in
case the control is accidentally bumped while driving.
Adjust each outside mirror so the vehicle is barely
visible in the mirror to maximize your side view.The mirrors can also be programmed for personalization
and parallel parking feature if you have the optional
memory package. For more information, see ªMemory
Seat and Mirrorsº and ªMemory and Personalization
Featuresº in the Index. For information on the heated
outside mirrors, see ªRear Window Defoggerº in
the Index.
Driver's Outside Auto-Dimming
Rearview Mirror
Only the driver's side outside mirror will adjust for the
glare of headlamps behind you. This feature is
controlled by pressing the MIRROR side of the button
on and off. This button is located at the bottom of the
electrochromic mirror. See ªElectrochromic Day/Night
Rearview Mirror with Compassº in the Index for
more information.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from
the driver's seat. This mirror does not have a
dimming feature.

yellowblue
2-53
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
Curb View Assist Mirror (If Equipped)
If your vehicle is equipped with memory mirrors, it will
also be equipped with the curb view assist mirror
feature. This feature will cause the passenger's mirror to
tilt when the vehicle is in REVERSE (R). This feature is
especially useful in allowing you to view the curb when
you are parallel parking. If further adjustment is needed
after the mirror is tilted, the power mirror controls may
be used to adjust the mirror. If the mirror control is
pressed while the passenger's mirror is tilted, the mirror
will move in that direction, but will return to its original
position once the vehicle is shifted out of REVERSE (R)
and a five
-second delay has occurred.
To program the feature, see ªCurb View Assist Mirror
Programmingº in the Index.
Storage Compartments
Glove Box
The glove box is located in front of the passenger's seat.
To lock the glove box door, insert the master key into
the lock cylinder and turn it clockwise. Turn the key
counterclockwise to unlock the door.
Map Pocket
The map/storage pockets are located on each front door as
well as on the passenger's and driver's front seatbacks.

yellowblue
2-54 Center Console Storage
The center console comes with a storage tray, a storage
compartment for CDs or tapes, a dual cupholder that
unfolds, a coinholder, an optional phone and an armrest.
The cupholder can be opened by pressing on the surface
panel located in front of the armrest and unfolding it.
Close the lid to secure.
Rear Storage Armrest
Your vehicle is equipped with a rear seat armrest which
includes an open storage compartment and a dual
cupholder that unfolds for use. Pull the armrest down by
using the attached handle. Push in the lever located at
the end of the armrest to open the storage compartment
and access the cupholder.
Wastebasket
The wastebasket is located on the passenger's side near
the footwell. To remove, pull the bottom portion
outward to release the velcro and slide the basket toward
you. Reverse the steps to reinstall.
Convenience Net
The convenience net is inside the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops.
The net is not for larger, heavier loads. Store them in the
trunk as far forward as you can. When not using the net,
hook the net to the tabs securing it to the sill plate.

yellowblue
2-55
Ashtrays and Cigarette Lighter
(Option)
The ashtrays and cigarette lighters may be ordered
through your dealer.
NOTICE:
Don't put papers or other flammable items into
your ashtrays. Hot cigarettes or other smoking
materials could ignite them, causing a
damaging fire.
Front Ashtray
Press on the lower edge of the cover of the console
located below the climate control system to reveal the
front ashtray. To clean the ashtray, lift it out by pulling
on the snuffer.
Rear Ashtray
To use the rear ashtray, lift the lid. For more
information, see your dealer.
Cigarette Lighter
The front cigarette lighter is located near the ashtray.
Press it all the way in and release. It will pop back by
itself when it's ready to light. You may also have a
lighter on the back of the center console near the rear
seat air outlet.
Note: Power to the cigarette lighter will shut off 10
minutes after the ignition is turned off. This helps to
prevent battery drainage. For more information, see
ªInadvertent Power Battery Saverº in the Index.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.

yellowblue
2-56
Sun Visors
Swing down the visor to block out glare. It can be
detached from the center mount and moved to the side.
When moved to the side, the sun visor will also move
forward and rearward. The sun visors are equipped with
a storage flap that can be used for small items such as
toll tickets.
There is also a secondary visor attached separately to
the headliner.
Lighted Visor Vanity Mirror
Turn the sunshade down and lift the cover to see the
mirror. Move the slide switch up or down to brighten or
dim the lamp.
Cellular Telephone (Option)
Your vehicle has been prewired for dealer installation of
a dual
-mode (analog/digital) cellular telephone. A fixed
mobile or a portable hand
-held system are available.
Either system has steering wheel telephone controls and
information output through the Driver's Information
Center (DIC). Voice activation and hands
-free operation
are standard features. For more information, contact
your dealer. A user's guide is provided with
the telephone.
OnStar
System (Option)
OnStar is a vehicle communications service which may
be ordered through your dealer. The following OnStar
services are available 24 hours a day:

Automatic Notification of Front and Side
Air Bag Deployment

Emergency Services

Theft Detection/Notification and
Stolen
-Vehicle Tracking

Remote Door Unlock

Roadside Assistance with Location

Route Support

Convenience Services

Remote Diagnostics

Hands
-Free, Voice-Activated Cellular Telephone
For more information, contact your dealer.
Assist Handles
An assist handle above each door can be used when
getting out of your vehicle.

yellowblue
2-57
Garment Hooks
For your convenience, a garment hook is attached to
each rear assist handle.
Umbrella Holder (If Equipped)
The driver's front seat cushion may come equipped with
an umbrella holder. Gently slide the umbrella into the
slot located under the front portion of the driver's
seat cushion.
Floor Mats
Your vehicle is equipped with rubber-backed front and
rear floor mats. Keep them clean by vacuuming and
using a spot cleaner, if necessary. Do not machine wash.
Sunroof (Option)
There are two control switches to operate the
sunroof
-- one to open/close or express-open the
sunroof and the other to vent the sunroof. The control
switches work only when the ignition is on or when the
ignition is off and the Retained Accessory Power (RAP)
is active.
Press and hold the ROOF
switch rearward to the first
position to open the glass
panel and sunshade. The
sunshade can also be
opened or closed by hand.
To close the glass panel,
press and hold the ROOF
switch forward.
Press and release the ROOF switch rearward to the
second position to express
-open the glass panel. If you
want to stop the glass panel in a partially
-open position,
press either the ROOF or VENT switch in any direction.
Note: If you press and hold the ROOF switch in the
express
-open position for more than one second, the
sunroof will operate manually.

yellowblue
2-58
To vent the sunroof, press
and hold the upper part of
the VENT switch. The
sunshade must be opened by
hand. To close, press and
hold the lower part of the
VENT switch.Universal Transmitter (Option)
K1±62±1116±W
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.
