CADILLAC SEVILLE 2000 5.G Owners Manual
Manufacturer: CADILLAC, Model Year: 2000, Model line: SEVILLE, Model: CADILLAC SEVILLE 2000 5.GPages: 359, PDF Size: 2.59 MB
Page 191 of 359

3-37
be the same or different. Press BAND to recall the
frequency and program type displays. If the radio is
tuned to a station that is not broadcasting RDS
information, the station's frequency will remain on the
display. While RDS is on, the radio will search for a
stronger station in the network when a station gets too
weak for listening. Press the RDS SELECT button,
followed by this button again to turn RDS off.
All RDS functions will be turned off.
REGION: You can also use the RDS button to access
the region function. When an RDS station becomes
weak, this function searches for a stronger station within
the same network. A network can span a great distance.
One network can have stations spread across a country
or continent. Each network breaks down into regions.
With regions, local news items like weather and traffic
are available to you. When the region function is on,
the radio only searches for stations in the same network
and region. You can only use the region function when
RDS is already on. Press the RDS SELECT button.
Then press and hold the RDS button for two seconds.
REGION: ON will appear on the display. While
REGION: ON appears on the display, press the RDS
button again to turn the region function off. REGION:
OFF will appear on the display. The region function can
be turned on again by pressing the RDS button.TA (2): Press the RDS SELECT button, followed
by this button to receive traffic announcements.
The radio will turn on the TA display. TP will appear
on the display if the tuned station broadcasts traffic
announcements. You may also receive traffic
announcements from stations in the network related to
the tuned station. If the current tuned station does not
broadcast traffic announcements, the radio will seek to a
station which does. When the radio finds a station which
broadcasts traffic announcements, it will stop. If no
station is found, NONE FOUND will appear on the
display. When SEEK or SCAN is pressed with the
traffic announcement function on, the radio will only
stop at stations which broadcast traffic announcements.
While a traffic announcement plays, the radio uses a
special type of volume called TA volume. To increase
TA volume, turn the PWR/VOL knob clockwise.
Turn it counterclockwise to decrease volume.
TA VOLUME will appear on the display while the
volume is being adjusted.
Page 192 of 359

3-38
When a traffic announcement comes on the tuned
radio station or a related network station, you will
hear it, even if the volume is muted or a cassette tape
or MiniDisc is playing. If the radio tunes to a related
network station for a traffic announcement, it will
return to the original station when the announcement is
finished. If the cassette tape or MiniDisc player was
being used, the tape or MiniDisc will stay in the player
and resume play at the point where it stopped.
Press the RDS SELECT button, followed by this
button again to turn TA off.
MSG (3): When RDS is on, if the current station has
a message, MSG will appear on the display. Press the
RDS SELECT button, followed by this button to see
the message. If the whole message does not appear on
the display, parts of the message will appear every three
seconds until the message is completed. To see the parts
of the message faster than every three seconds, press this
button again. A new group of words will appear on the
display. Once the complete message has been displayed,
MSG will disappear from the display until another new
MSG is received.
PTY (4): This button is used to turn on and off Program
Type (PTY) seeks and scans. Press the RDS SELECT
button, followed by this button. The PTY display willturn on. RDS SELECT: PTY NEWS will appear on the
display for three seconds. (The PTY shown will be the
last PTY selected.) Press the RDS SELECT button,
followed by this button again to turn the PTY display off.
PTY (5) (6): With RDS on, press the RDS
SELECT button, followed by
or . The PTY
display will turn on, if it is not already on. RDS
SELECT: PTY NEWS will appear on the display for
three seconds. (The PTY shown will be the last PTY
selected.) While this message is displayed, use
and
to move up and down the PTY list. If you pause on
a PTY for three seconds, PRESET PTY: NEWS will
appear on the display. While this message is displayed,
you can save the PTY in a preset by pressing one of the
six numbered pushbuttons until you hear a beep. Allow
three seconds for the message to disappear if you do not
want to save the PTY in a preset. See ªRadio Data
Systems (RDS) Program Type (PTY) Selectionsº
in the Index.
When the PTY display is on, press SEEK and SCAN to
find radio stations of the PTY you want to listen to. The
last PTY selected will be used for seek and scan modes.
If a station with the selected PTY is not found, NONE
FOUND will appear on the display. If both PTY and
TA are on, the radio will search for stations with traffic
announcements and the selected PTY.
Page 193 of 359

3-39
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite Program Types (PTYs).
These buttons have factory PTY presets. See ªRadio
Data Systems (RDS) Program Type (PTY) Selectionsº
in the Index. You can set up to 12 PTYs (six FM1 and
six FM2). Just:
1. Turn PTY on.
2. Press BAND to select FM1 or FM2.
3. Tune in an RDS station with the PTY you desire.
4. Press and hold one of the six numbered buttons
for more than two seconds until you hear a beep.
Whenever you press that numbered button for less
than two seconds, the PTY you set will return.
5. Repeat the steps for each pushbutton.
When battery power is removed and later applied, you
will not have to reset your RDS presets because the
radio remembers them.
HR or MN: Press the RDS SELECT button,
followed by one of these buttons to display the time
for the current station. STATION TIME IS will be
displayed. If a time has not been sent to the radio, NO
STATION TIME will be displayed. If you have recentlytuned to the station, you may need to wait a minute
before the time is available to the radio. To set the clock
to the current displayed station time, press and hold HR
or MN until TIME UPDATED is displayed. There is a
two second delay before the time is updated. RDS mode
does not have to be on to use this function, but you must
be tuned to an FM RDS station.
ALERT: This type of announcement warns of national
or local emergencies. You will not be able to turn off alert
announcements. Alert announcements will come on even
if RDS mode is turned off. ALERT appears on the
display when an alert announcement plays. The radio
uses TA volume during these announcements. To increase
volume, turn the PWR/VOL knob clockwise. Turn it
counterclockwise to decrease volume. TA VOLUME will
appear on the display while the volume is being adjusted.
When an alert announcement comes on the tuned radio
station or a related network station, you will hear it, even
if the volume is muted or a cassette tape or MiniDisc is
playing. If the radio tunes to a related network station
for an alert announcement, it will return to the original
station when the announcement is finished. If the
cassette tape or MiniDisc player is playing, play will
stop for the announcement and resume when the
announcement is finished.
Page 194 of 359

3-40
Setting the Tone
TONE: Press and release this button until the desired
tone control (BASS, TREBLE or MIDRANGE) is
found. The radio keeps separate tone settings for each
band, preset (except weather band presets) and source.
LEVEL: After selecting the desired tone control, press
the plus (+) or minus (
-) symbol on this button to select
the desired level.
To save the tone settings for your presets, press and hold
the numbered button for the desired preset for more than
two seconds until you hear a beep.
Using DSP Mode
DSP: The Digital Signal Processing (DSP) feature
is used to provide a choice of four different listening
experiences: TALK, FRONT SEAT, AMBIENCE and
SPACIOUS. DSP can be used while listening to the
radio, the cassette tape player or the remote CD changer.
Press this button to turn DSP on. Press and release this
button until you reach the desired selection. To turn DSP
off, press and hold this button until DSP OFF appears
on the display. When DSP OFF is displayed, the system
will provide the best overall Bose performance. The radio
keeps separate DSP settings for each band (except
weather band, which is always set to TALK), preset and
source. (This feature is available on the Bose radio only.)TALK: This setting is used when listening to
non
-musical material such as news, talk shows,
sports broadcasts and books on tape. TALK makes
spoken words sound very clear.
FRONT SEAT: This setting adjusts the audio to
give the front seat occupants the best possible sound
qualities. FRONT SEAT can be used at any time for
any material. Rear seat passengers in the vehicle may
not get the same effect.
AMBIENCE: This setting is used to enhance the
stereo effect.
SPACIOUS: This setting is used to make the
listening space seem larger.
Adjusting the Speakers
TONE: Press and release this button until the desired
BALANCE or FADE control is found.
SPEAKER: Press and release this button until
the desired BALANCE or FADE control is found.
This button is not available on the Bose radio.
LEVEL: After selecting the desired BALANCE or
FADE control, press the plus (+) or minus (
-) symbol
on this button to select the desired level.
Page 195 of 359

3-41
Playing a Cassette Tape
With the radio on, insert a cassette tape. The tape will
begin playing as soon as it is inserted. When one side of
your cassette tape is done playing, auto reverse plays the
other side of your cassette tape. Cassette tapes may be
loaded with the radio off but they will not start playing
until the radio is on. If you want to insert a cassette tape
when the ignition is off, first press the eject button.
While the tape is playing, use the VOL, TONE, LEVEL
and DSP controls just as you do for the radio. Other
controls may have different functions when a tape is
inserted. The display will show an underlined tape
symbol. TAPE PLAY will appear on the display when a
tape is playing, with an arrow to indicate which side of
the tape is playing.
If an error occurs while trying to play a cassette tape,
it could be that:
The cassette tape is tight and the cassette player
cannot turn the hubs of the tape. Hold the cassette
tape with the open end down and try turning the
right hub counterclockwise with a pencil. Flip the
tape over and repeat. If the hubs do not turn easily,
your cassette tape may be damaged and should not
be used in the player. Try a new tape to be sure your
player is working properly.The cassette tape is broken. (Check to see if your
tape is broken. Try a new tape.)
RW: Press the left arrow to rewind the tape rapidly.
The radio will play while the tape rewinds. You may use
your station pushbuttons to tune to another radio station
while in RW mode. Press the left arrow again to return
to playing speed.
FF: Press the right arrow to fast forward to another part
of the tape. The radio will play while the tape advances.
You may use your station pushbuttons to tune to another
radio station while in FF mode. Press the right arrow
again to return to playing speed.
TUNE SEEK: When this button is pressed, it has
two positions. This button works the same, whether it is
pressed to the first or second position. Press this button
to seek to the next or previous selection on the tape.
Your tape must have at least three seconds of silence
between each selection for TUNE
-SEEK to work.
The sound will mute while seeking.
SCAN: Press this button to listen to selections for a
few seconds. The tape will go to a selection, stop for
a few seconds, then go on to the next selection.
Press this button again to stop scanning.
Page 196 of 359

3-42
SIDE: Press this button to change the side of the tape
that is playing.
EJECT: Press the upward triangle button to the right
of the cassette tape player to remove a tape. The radio
will play. Eject may be activated with the radio off
and/or the ignition off.
CLEAN TAPE: If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you
clean the player, press and hold the eject button for three
seconds to reset the CLEAN TAPE indicator. The radio
will display CLEAN TAPE MSG CLEARED to show
that the indicator was reset.
Your cassette tape player automatically reduces
background noise. Dolby Noise Reduction is
manufactured under a license from Dolby Laboratories
Licensing Corporation. Dolby and the double
-D
symbol are trademarks of Dolby Laboratories
Licensing Corporation.
Auto CrO
2 allows the cassette tape player to adjust to
the type of cassette tape for clearer sound for CrO
2cassette tapes.
Multimedia System
This radio has been designed to connect to your internet
account to send or receive e
-mail or to browse the world
wide web. The radio also uses enhanced Radio Data
Systems (RDS) to provide you with information such as
localized traffic and weather.
Internet Access
Your radio contains a modem that allows you to access
e
-mail or the World Wide Web using a Personal Digital
Assistant (PDA), Hand held PC or Laptop Computer.
You will need a modem cable with a 25
-pin connector
designed for your device. If you have a nine pin serial
cable, you will need to supply a null modem with a
DB9 to DB25 connector. To access your internet
account, you must first configure your computer to
work with the radio's modem.
Palm Pilot Products
If you are using a Palm Pilot product, you will need to
obtain an e
-mail program and/or a web browser. You
can find these products at www.palm.com
. Select the
preferences application in your Palm Pilot Professional
or newer product, then select modem from the pull down
window. In the modem window, select speed at 4800 bps
and add the string AT&FX3.
Page 197 of 359

3-43
Use the network panel to configure your PDA to
work with your Internet Service Provider (ISP).
Consult the information provided with your PDA and
e
-mail/browser applications for details. You may need to
contact your ISP for your Domain Name Service (DNS).
The e
-mail application you choose will require a POP3
and SMTP host, user identification and password.
You may need to contact your ISP for the information
required to complete the setup.
Palm PC Products
Your Palm PC will allow you to send and receive e-mail.
You will need to obtain a browser if you plan to access
the world wide web (www). You can find a browser for
your Palm PC at www.windowsce.microsoft.com
.
If your Palm PC uses Windows CE, create a connection
by following these steps:
1. Click on Start.
2. Click on Programs.
3. Click on Communications.
4. Click on Connections.
5. Double click on the Make New Connection icon.
6. Select Dial Up Connection, then Next and Configure.Under the Port Settings tab, make the following selections:
Baud rate 4800,
Data bits 8,
Parity None,
Stop Bits 1 and
Flow Control Hardware.
Next select the Call Options tab and clear the box labeled
ªWait for dial tone before dialingº and select OK.
Select the TCP/IP settings to configure your Palm PC
to work with your ISP. Consult the documentation
provided with your PDA and browser application for
details. You may need to contact your ISP for your
Domain Name Service (DNS).
To complete the setup follow these steps:
1. Click on Start.
2. Click on Programs.
3. Click on Inbox.
Then using the menu bar at the top of the screen:
4. Click on Compose.
5. Click on Options and select the Services tab.
Page 198 of 359

3-44
The Setup Wizard will guide you through the steps to
create an e
-mail service. You may need to contact your
ISP for the information required to complete the setup.
Receiving and Sending E-Mail
Your radio uses the cellular phone to connect to your
ISP. Make sure the phone is secure and connected.
Begin the modem session by connecting the modem
cable (or serial cable with a null modem) to your
computing device. Press and release the modem door on
the radio near the recessed bumps. Connect the cable to
the radio's 25
-pin connector. Start your e-mail program
and connect to the ISP. The radio will receive the phone
number from your PDA and instruct the phone to dial
the number. While connecting, the audio from your
radio will be briefly muted and you will hear the tones
being generated as the modem establishes a connection.
When the connection is complete, the audio will return.
When you end your e
-mail session your radio will
instruct the phone to hang up.
Cellular Phone Reception
If the reception of the cellular signal weakens the error
rate of the modem will increase. If you are having
difficulty connecting or sending and receiving data the
cellular signal may be too weak. To ensure good signal conditions, the cell phone display should show
a minimum of three to four bars for signal strength.
The volume on the phone handset should be set to
three bars for best results.
Text Based Information Services
Your radio can be used to gather information using
enhanced Radio Data Systems (RDS) while you are out of
the vehicle. The radio can provide text
-based information
such as traffic and weather. This is done through a
nationwide network of FM stations. You do not need to
know which station is providing this service, the radio will
search out the station when not being used. Your dealer
can provide details on how to obtain this service.
You can program the radio to automatically wake up
twice daily, for example, at 7 AM and again at 4:30 PM.
If your vehicle is off, the radio will wake up at these
programmed times to gather the information. Although
the radio is awake and receiving data, it will appear to
be off. There will be no sound or display. It may take
up to 15 minutes for each update. The information
will then be available for review when you enter your
vehicle. If the vehicle is on at the time of the scheduled
update, the update will not be performed. In addition
to the user programmable times, the system will
automatically update the information when you turn
the ignition off and leave the vehicle.
Page 199 of 359

3-45 Programming for News/Information Updates
Your vehicle is delivered with the Communiport
Infotainment radio programmable updates off. You
can program the radio to provide two daily updates.
To program the update times follow these steps:
1. Press and hold the INFO button for approximately
two seconds. This will cause the radio to enter the
programming mode.
2. Press and release the INFO button, UPDATE 1
TIME will appear on the display. Use the HR and
MN buttons to set the time you would like to retrieve
the first news and information update.
3. Press and release the INFO button again, UPDATE
2 TIME will appear on the display. Use the HR and
MN buttons to set the time to retrieve the second
daily news and information update.
The HR button can be used to select OFF if one or both
automatic updates are not required.
If you have not started your vehicle in a couple of days
the radio will switch to a reduced update schedule by
skipping every other update time. After approximately
three days the radio will stop providing information
updates until you restart your vehicle. This is intended
to conserve your vehicle's battery.
Programming for an Immediate
Information Update
To program an immediate news update, press and hold
the INFO button until UPDATE NOW? PRESS RDM
appears on the display. Then press the RDM button while
UPDATE NOW? PRESS RDM is being displayed.
The radio will begin the update by switching to the
FM band, if not already there, and tuning to the service
provider's station. If you are listening to AM, FM or
weather, UPDATING INFO.... will appear on the
display until the update has completed. You can switch
the source to cassette or CD changer or turn the radio
off without interrupting the update.
You can also perform the update while listening to the
cassette player or CD changer. The radio will briefly
display UPDATING INFO...., then return to the
normal display. The radio will beep once to let you
know when the update has completed.
To cancel the update and return to the station you were
listening to, turn the radio off and back on again.
Page 200 of 359

3-46
While performing the information update, the radio will
temporarily disable the RDS buttons. The RDS buttons
will be enabled again once the update is completed.
When the radio begins an update, the information
contained in the radio's memory is cleared. If you
perform an immediate update and then quickly cancel it,
NO TEXT AVAILABLE will appear on the display.
Viewing the News/Information
To view the news/information, press and release the
INFO button. The radio will display TOPIC: ALL.
The radio will then begin displaying all the received
information at a rate of approximately three seconds
per display. You can page through the topics at a faster
rate by pressing and releasing the INFO button after
the text appears.
You can access a topic directly from the TOPIC: ALL
display by pressing and releasing the INFO button until
the desired topic is displayed. The radio will display the
information for that topic only.
If the radio has not received any information, NO TEXT
AVAILABLE will appear on the display. This will be
followed by the UPDATE NOW? PRESS RDM display
previously described.
Vehicle Control
Your radio can provide you with safety and convenience
features by performing the following vehicle control actions:
Unlocking or locking the doors,
opening the trunk,
flashing the parking lights and
sounding the horn.
If you need one of these services, contact the OnStar
service center.
When you turn your vehicle off, the radio will
automatically tune to your FM provider's station and
check for a vehicle control request received through
RDS. Your vehicle control request will be completed in
five minutes or less if your vehicle is in the continental
United States and in a location that can receive
FM broadcasts.
Vehicle control is available for six days from the time
you last turned off your vehicle. This time can be
increased up to 11 days by turning off the automatic
information updates as described previously. This would
be useful if you are going to be away from your vehicle
for an extended period of time.
For more information see OnStar in the Index.
