CADILLAC SEVILLE 2002 5.G Owners Manual

2-64
Roadside Assistance with Location: For vehicle
breakdowns, press the OnStar Services button.
An advisor will contact the appropriate help.
Remote Diagnostics: If an instrument panel light comes
on, press the OnStar Services button. An advisor can
perform a check of the engine on
-board computer,
and recommend what action needs to be taken.
OnStar MED
-NET: Med-Net can store your personal
medical history and provide it to emergency personnel
if necessary. (Requires activation and additional fee).
Accident Assist: An advisor can provide step
-by-step
guidance following an accident.
Remote Door Unlock: To contact the center, call
1
-888-4-ONSTAR. You will be required to provide your
security information. An advisor will send a command
to your vehicle to unlock itself. The advisor can delay
unlocking your vehicle. Remote Door Unlock is
disabled 48 hours after the vehicle is parked to maintain
the battery charge.
Vehicle Locator Service: To contact the center, call
1
-888-4-ONSTAR. You will be required to provide your
security information. An advisor will send a command
to your vehicle to sound the horn and/or flash the lamps.Route Support: An advisor can provide directions or
guidance to most places you want to go. In addition,
they can help you locate gas stations, rest areas, ATMs,
hospitals, hotels, stores, eateries and more.
Ride Assist: An advisor can locate transportation in the
event that you are unable to drive.
Concierge Services: The concierge advisor can obtain
tickets, reservations, or help with vacation/trip planning
and other unique items and services.
OnStar System Limitations
Complete limitations can be found on the Subscriber
Services Agreement.
In order to provide you with excellent service, calls with
the OnStar Center may be monitored or recorded.
OnStar service is:

available in the 48 contiguous United States, Alaska,
Hawaii and Canada;

available when the vehicle is within the operating
range of a cellular provider;

subject to limitations caused by atmospheric
conditions, such as severe weather or topographical
conditions, such as mountainous terrain;

subject to cellular carrier equipment limitations.

2-65
Global positioning locating capabilities will not be
available if satellite signals are obstructed.
OnStar will not function if the vehicle's battery is
discharged or disconnected. It may also be inoperative
if the vehicle is in an accident and the OnStar or vehicle
electrical system components are damaged.
OnStar is the communication link between you
and existing governmental emergency and roadside
service providers. OnStar will receive your call and use
reasonable effort to contact an appropriate provider.
OnStar cannot promise that the providers will respond
in a timely manner or at all.Assist Handles
An assist handle above each door can be used when
getting out of your vehicle.
Garment Hooks
For your convenience, a garment hook is attached to
each rear assist handle.
Umbrella Holder (If Equipped)
The driver's front seat cushion may come equipped
with an umbrella holder. Gently slide the umbrella into
the slot located under the front portion of the driver's
seat cushion.
Floor Mats
Your vehicle is equipped with rubber-backed front and
rear floor mats. Keep them clean by vacuuming and
using a spot cleaner, if necessary. Do not machine wash.

2-66
Sunroof (Option)
The two switches that operate the sunroof are located
on the overhead console and include VENT, ROOF,
open and close.
Press and hold the ROOF switch rearward to the
first position to open the glass panel and sunshade.
The sunshade also can be opened or closed manually.
To close the glass panel, press and hold the ROOF
switch forward. As the sunroof reaches the closed
position, it will open slightly toward the vent position
and then drop down to the closed position to provide
a better seal.Press and release the ROOF switch rearward to the
second position to express
-open the glass panel to
the comfort stop position, approximately half
-way
open. The comfort stop position is designed to help
reduce noise and make the rear seat passengers
more comfortable.
The glass panel may then be fully opened by pressing
the ROOF switch again.
If you press and hold the ROOF switch in the
express
-open position for more than one second,
the express
-open operation will be over-ridden and
the sunroof will stop when the switch is released.
To stop the glass panel when express opening,
press the the ROOF or VENT switch forward or
rearward and release.
To vent the glass panel, press and hold the VENT
switch in the open position. The sunshade must be
opened manually when using the vent position.
To close the glass panel, press and hold the VENT
switch in the close position.
The ROOF and VENT switches work only when the
ignition is on or when RAP is active. See ªRetained
Accessory Powerº in the Index.

2-67
HomeLink
Transmitter (If Equipped)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of
the device.Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Programming the HomeLink Transmitter
Do not use the HomeLink Transmitter with any garage
door opener that does not have the ªstop and reverseº
feature. This includes any garage door opener model
manufactured before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming.
It is recommended that a new battery be installed in
your hand
-held transmitter for quicker and more
accurate transmission of the radio frequency.
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps
to program up to three channels:
1. Decide which one of the three channels
(one of the HomeLink buttons) you want
to program.
2. Press and hold the desired button on HomeLink
through Step 3.

2-68
3. When the HomeLink indicator light begins to blink
slowly (this may take up to 30 seconds), hold the
hand
-held transmitter about 1 to 3 inches (3 to 8 cm)
away from HomeLink and then press and hold the
transmit button on the hand
-held transmitter.
Continue to hold both buttons until the indicator
light on HomeLink begins to flash rapidly
(this may take up to 90 seconds).
If you have trouble programming HomeLink, make
sure that you have followed the directions exactly as
described and that the battery in the hand
-held
transmitter is not weak. If you still cannot program it,
move the hand
-held transmitter to the left or right or
forward or backward or flip it upside down. HomeLink
may not work with older garage door openers that do
not meet current Federal Consumer Safety Standards.
If you cannot program the transmitter after repeated
attempts, refer to ªTraining a Garage Door Opener
with Rolling Codesº later in this section or contact
the manufacturer of HomeLink at 1
-800-355-3515,
or on the internet at www.homelink.com.
Be sure to keep the original hand
-held transmitter in
case you need to erase and reprogram HomeLink.
Operating the HomeLink Transmitter
Press and hold the appropriate button on HomeLink
for at least half of a second. The indicator light will
come on while the signal is being transmitted.
Training a Garage Door Opener with a
ªRolling Codeº Feature (If Equipped)
If you have not previously programmed the hand-held
transmitter to HomeLink, see ªProgramming the
HomeLink Transmitterº listed previously. If you have
completed this programming already, you now need to
train the garage door opener motor head unit to
recognize HomeLink.
1. Find the ªLearnº or ªSmartº button on the garage
door opener motor head unit. The exact location
and color will vary by garage door opener brand.
If you have difficulty finding the ªLearnº or
ªSmartº button, refer to your garage door opener
owner's manual or contact the manufacturer of
HomeLink at 1
-800-355-3515, or on the internet
at www.homelink.com.
Because of the steps involved, it may be helpful
to have another person assist in programming
the transmitter.

2-69
2. Press the ªLearnº or ªSmartº button on the garage
door opener motor head unit. An indicator light will
begin to flash when the motor head unit enters the
training mode.
Following this step, you have 30 seconds to start Step 3.
3. Return to HomeLink in your vehicle and firmly press
and release the programmed HomeLink button
three times.
The rolling
-code garage door opener should now
recognize HomeLink. You may either use HomeLink
or the hand
-held transmitter to open the garage door.
If after following these instructions, you still have
problems training the garage door opener, contact the
manufacturer of HomeLink at 1
-800-355-3515, or on
the internet at www.homelink.com.
Canadian Owners
Canadian Owners: During programming, the hand-held
transmitter may automatically stop transmitting after
two seconds. In this case, you should press and
hold the HomeLink button (see Steps 2 and 3 under
ªProgramming the HomeLink Transmitterº) while you
press and re
-press (cycle) your hand-held transmitter
every two seconds until HomeLink is trained.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons until the indicator light begins to
flash (approximately 20 seconds). Release both buttons.
Resetting Defaults
To reset HomeLink to default settings, hold down the
two outside buttons until the indicator light begins to
flash (approximately 20 seconds). Continue to hold both
buttons until the HomeLink indicator light turns off and
then release both buttons.
Accessories
Accessories for the HomeLink Transmitter are available
from the manufacturer of the unit. If you would like
additional information, please contact the manufacturer
of HomeLink at 1
-800-355-3515, or on the internet
at www.homelink.com.

2-70
The Instrument Panel -- Your Information System

2-71
The main components of the instrument panel are the following:
A. Air Outlets
B. Driver Information Center (DIC) Buttons
C. Turn Signal/Multifunction Lever
D. HVAC Steering Wheel Controls
(or Cellular Telephone Controls, If Equipped)
E. Instrument Panel Cluster
F. Windshield Wiper/Washer Lever
G. Audio Steering Wheel Controls
H. Ignition Switch
I. Air Vent Control Thumbwheel
J. Hazard Warning Flasher Button
K. Audio SystemL. Exterior Lamp Controls
M. Hood Release
N. Fuel Door Release
O. Trunk Release
P. Cruise Control
Q. Horn
R. Heated Seat Controls
S. Traction Control Switch
T. Console Shift Lever
U. Convenience Storage/Optional Ashtray
V. Climate Controls
W. Glove Box

2-72
Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You'll know how
fast you're going, how much fuel you're using and many other things you'll need to drive safely and economically.
United States version shown, Canada similar

2-73 Speedometer and Odometer
The speedometer lets you see your speed in both
miles per hour (mph) and kilometers per hour (km/h).
The odometer shows how far your vehicle has been
driven, in either miles (used in the United States) or
kilometers (used in Canada).
You may wonder what happens if a vehicle has to have
a new odometer installed. The new one may read the
correct mileage. This is because your vehicle's computer
has stored the mileage in memory.
Trip Odometer
The trip odometer can record the number of miles or
kilometers traveled for up to two trips.
The trip odometer button
is located to the left of
the steering wheel on
the instrument panel.The two trip modes are indicated by Trip A and Trip B.
In order to change from one mode to the other, press
the A/B portion of the TRIP button.
By pressing the bottom of this button, you can tell
how many miles have been recorded on either Trip A
or Trip B since you last set the odometer back to zero.
Press the RESET part of the button until zeros appear
to reset each trip mode.
If your vehicle is first sold in the United States, the trip
odometer will return to zero after 999.9 miles (1 609 km).
If your vehicle is first sold in Canada, the trip odometer
will return to zero after 1 999.9 km (1,242 miles).
The RESET TRIP A/B button only resets the trip
mode (A or B) that is being displayed. Each trip mode
must be reset individually.
