CADILLAC SRX 2007 1.G Owners Manual

Keys.............................................................. 93
Remote Keyless Entry (RKE) System.......... 94
Remote Keyless Entry (RKE) System
Operation................................................. 96
Doors and Locks........................................ 100
Door Locks................................................ 100
Central Door Unlocking System................. 101
Power Door Locks..................................... 101
Delayed Locking........................................ 102
Programmable Automatic Door Locks........ 102
Rear Door Security Locks......................... 103
Lockout Protection..................................... 104
Power Liftgate........................................... 104
Windows...................................................... 108
Power Windows........................................ 109
Sun Visors................................................ 112Theft-Deterrent Systems............................. 112
Theft-Deterrent System.............................. 112
PASS-Key
®III+......................................... 114
PASS-Key®III+ Operation......................... 114
Starting and Operating Your Vehicle......... 116
New Vehicle Break-In................................ 116
Ignition Positions....................................... 117
Retained Accessory Power (RAP)............. 118
Starting the Engine.................................... 119
Adjustable Throttle and Brake Pedal.......... 120
Engine Coolant Heater.............................. 121
Automatic Transmission Operation............. 122
Tow/Haul Mode......................................... 126
Parking Brake........................................... 127
Shifting Into Park (P) ................................. 129
Shifting Out of Park (P)............................. 131
Parking Over Things That Burn................. 131
Engine Exhaust......................................... 132
Running the Engine While Parked............. 133
Section 2 Features and Controls
91

Mirrors......................................................... 134
Automatic Dimming Rearview Mirror
with OnStar
®.......................................... 134
Automatic Dimming Rearview Mirror
with OnStar
®and Compass................... 134
Outside Power Heated Mirrors................... 137
Outside Automatic Dimming Mirror............. 138
Outside Curb View Assist Mirror................ 138
Outside Convex Mirror............................... 139
OnStar
®System.......................................... 139
Universal Home Remote System................ 143
Universal Home Remote System
(With Three Round LED)....................... 143
Universal Home Remote System
(With One Triangular LED)..................... 143Universal Home Remote System
Operation (With Three Round LED)....... 144
Universal Home Remote System
Operation (With One Triangular LED)....... 150
Storage Areas............................................. 153
Glove Box................................................. 153
Cupholder(s).............................................. 154
Cell Phone Storage Area........................... 154
Center Console Storage Area.................... 154
Luggage Carrier........................................ 154
Cargo Cover............................................. 155
Cargo Management System...................... 155
Sunroof....................................................... 156
Sunroof (Ultra View
®) ................................ 156
Sunroof (Ultra View®Plus)........................ 158
Section 2 Features and Controls
92

Keys
{CAUTION:
Leaving children in a vehicle with the
ignition key is dangerous for many
reasons, children or others could be badly
injured or even killed. They could operate
the power windows or other controls or
even make the vehicle move. The windows
will function with the keys in the ignition
and they could be seriously injured or
killed if caught in the path of a closing
window. Do not leave the keys in a vehicle
with children.
93

Your vehicle has a
double-sided key that
can be used for
the ignition and
door locks.
If you ever lose your keys, your dealer will be able
to assist you with obtaining replacements.
In an emergency contact Cadillac Roadside
Service
®. SeeRoadside Service on page 493for
more information.
Remote Keyless Entry (RKE)
System
Your Remote Keyless Entry (RKE) system
operates on a radio frequency subject to Federal
Communications Commission (FCC) Rules
and with Industry Canada.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation of the device.
94

This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation of the device.
Changes or modications to this system by other
than an authorized service facility could void
authorization to use this equipment.At times you may notice a decrease in operating
range. This is normal for any RKE system. If
the transmitter does not work or if you have to
stand closer to your vehicle for the transmitter to
work, try this:
Check the distance. You may be too far from
your vehicle. You may need to stand closer
during rainy or snowy weather.
Check the location. Other vehicles or objects
may be blocking the signal. Take a few steps
to the left or right, hold the transmitter
higher, and try again.
Check to determine if battery replacement is
necessary. See “Battery Replacement”
underRemote Keyless Entry (RKE) System
Operation on page 96.
If you are still having trouble, see your dealer
or a qualied technician for service.
95

Remote Keyless Entry (RKE)
System Operation
With this feature, you can lock and unlock the
doors and liftgate, open and close the liftgate, and
turn on your vehicle’s interior lamps from up to
65 feet (20 m) away using the Remote Keyless
Entry (RKE) transmitter supplied with your vehicle.
You will have one of the RKE transmitters
below.
Q(Lock):Press this symbol on the RKE
transmitter to lock the doors. This also arms the
theft-deterrent system. SeeTheft-Deterrent
System on page 112for additional information.
You can program your vehicle so that the exterior
lamps will ash and/or the horn will sound
when you lock the doors with the RKE transmitter.
SeeDIC Vehicle Customization on page 231for
more information on programming this feature.
"(Unlock):Press this symbol on the RKE
transmitter to unlock the driver’s door. This also
disarms the theft-deterrent system. Press the
button again, within ve seconds, to unlock the rest
of the doors.
You can program your vehicle so that the exterior
lamps will ash when you unlock the doors
with the RKE transmitter. SeeDIC Vehicle
Customization on page 231for more information
on programming this feature.
If your vehicle is programmed for remote
conrmation, the doors must be closed for this
feature to work. If a door is open, remote
conrmation will be canceled.
96

L(Panic Alarm):Press and release this button
to locate your vehicle. The turn signal lamps
will ash and the horn will sound three times.
Press and hold this button for more than
two seconds to activate the panic alarm. The
turn signal lamps will ash and the horn will sound
repeatedly for 30 seconds. The alarm will turn
off when the ignition is turned to ON or the alarm
button is pressed again. The ignition must be
in OFF for the panic alarm to work.
&(Power Liftgate):Press and hold this button
on the RKE transmitter to open and close the
liftgate. The taillamps will ash and a chime will
sound to indicate when the liftgate is opening and
closing.
Matching Transmitter(s) to Your
Vehicle
Each RKE transmitter is coded to prevent another
transmitter from unlocking your vehicle. If a
transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to
bring any additional transmitters with you so that
all of them can be re-coded to match the new
transmitter. Once your dealer has coded the new
transmitter, the lost transmitter will not unlock
your vehicle. Each vehicle can have a maximum
of eight transmitters matched to it.
Battery Replacement
Under normal use, the battery in your RKE
transmitter should last about four years.
The battery is weak if the transmitter will not work
at the normal range in any location. If you have
to get close to your vehicle before the transmitter
works, it is probably time to change the battery.
Notice:When replacing the battery, use
care not to touch any of the circuitry. Static
from your body transferred to these surfaces
may damage the transmitter.
97

To replace the battery in the RKE transmitter do
the following:
1. Use a at object with a thin edge into the
notch, located below the trunk release
button, and separate the bottom half from the
top half of the transmitter.2. Remove the old battery, but do not use a
metal object to do this.
3. Slide the new battery into the transmitter with
the positive side of the battery facing down.
Use a type CR2032 battery, or equivalent
type. Make sure the cover is on tightly,
so water will not get in.
4. Snap the front and the back of the transmitter
together.
5. Test the operation of the transmitter with the
vehicle.
98

To replace the battery in the RKE transmitter do
the following:
1. Use a at object with a thin edge into the
notch, located above the metal base, and
separate the bottom half from the top half of
the transmitter.2. Remove the old battery, but do not use a
metal object to do this.
3. Slide the new battery into the transmitter with
the positive side of the battery facing up. Use
a type CR2032 battery, or equivalent type.
Make sure the cover is on tightly, so water will
not get in.
4. Snap the front and the back of the transmitter
together.
5. Test the operation of the transmitter with the
vehicle.
99

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can
easily open the doors and fall out of a
moving vehicle. When a door is
locked, the handle will not open it.
You increase the chance of being
thrown out of the vehicle in a crash if
the doors are not locked. So, wear
safety belts properly and lock the
doors whenever you drive.
CAUTION: (Continued)
CAUTION: (Continued)

Young children who get into unlocked
vehicles may be unable to get out. A
child can be overcome by extreme
heat and can suffer permanent injuries
or even death from heat stroke.
Always lock your vehicle whenever
you leave it.
Outsiders can easily enter through an
unlocked door when you slow down
or stop your vehicle. Locking your
doors can help prevent this from
happening.
100
