Memory Seat and Mirrors
If your vehicle has the memory feature, you can
program and recall memory settings for the driver’s
seating and outside rearview mirror driving
positions for up to two drivers. If your vehicle has
the adjustable throttle and brake pedal feature,
you can also program and recall memory settings
for the throttle and brake pedal driving positions.
The buttons for this feature are located on the
driver’s door armrest.
Use the following steps to program the buttons:
1. Adjust the driver’s seat including the seatback
recliner, both outside mirrors, and the throttle
and brake pedals. SeeOutside Power
Heated Mirrors on page 137andAdjustable
Throttle and Brake Pedal on page 120
for more information.2. Press and hold button 1 for at least
three seconds.
Two beeps will sound to conrm that the seat
and mirror positions have been saved.
3. Repeat the procedure for a second driver
using button 2.
The vehicle must be in PARK (P) to recall the
stored driving positions.
Press one of the numbered memory buttons to
recall the stored setting. Each time a memory
button is pressed, a single beep will sound.
A chime will sound and the setting will not be
recalled if you press button 1 or 2 when the vehicle
is not in PARK (P).
If you would like the stored driving positions to be
recalled when unlocking your vehicle with the
remote keyless entry transmitter or when you place
the key in the ignition, seeDIC Vehicle
Customization on page 231.
To stop recall movement of the memory feature at
any time, press one of the power seat or mirror
controls.
12

Two personalized exit positions can also be
programmed. Use the following steps to program
exit positions:
1. Press memory seat button 1 or the button with
the unlock symbol on the remote keyless
entry transmitter with the number 1 on
the back to recall the driving position.
2. Adjust the driver’s seat to the desired exit
position.
3. Press and hold the exit button located above
buttons 1 and 2 on the driver’s door armrest
for at least three seconds.
Two beeps will sound to conrm that the exit
position has been saved.
4. Repeat the procedure for a second driver
using memory seat button 2 or the remote
keyless entry transmitter with the number 2 on
the back.To recall the stored exit positions, press and
release the exit button. One beep will sound, and
the seat will move to the previously stored exit
position for the currently identied driver. If an exit
position has not been stored for this driver, the
seat will move all the way back. The position of the
outside mirrors is not stored or recalled for the
exit position.
The vehicle must be in PARK (P) to recall the exit
positions.
A chime will sound and the exit setting will not be
recalled if you press the exit button when the
vehicle is not in PARK (P).
If you would like your stored exit position to be
recalled when unlocking the vehicle with the
remote keyless entry transmitter or when the
ignition is turned off and the driver’s door is
opened, seeDIC Vehicle Customization on
page 231.
13

Stowable Seat
If your vehicle has a third row seat, it is a power
folding seat.
The head rests need to be removed before folding
the third row seat. SeeHead Restraints on
page 17for instructions for removing the third row
seat head rests. The seatback will not fold all
of the way down if the head rests are not removed.The buttons that are used to operate the power
folding third row seat are located inside of the
liftgate and behind the second row seat on the
passenger’s side of the vehicle.
Two buttons are located inside the liftgate.
One button is to tilt the seatback forward for added
storage space or when storing a at tire. The
other button is the power folding seat button. The
button behind the second row seat is also a
power folding seat button. Press and hold either
one of the two power folding seat buttons to
fold the seat.
Notice:Folding a rear seat with the safety
belts still fastened may cause damage to the
seat or the safety belts. Always unbuckle
the safety belts and return them to their normal
stowed position before folding a rear seat.
Inside Liftgate
20

Before folding or unfolding the third row seat, all of
the following conditions must be met:
The liftgate or passenger’s side rear door
must be open.
The unlock button on either the remote
keyless entry transmitter or the door must be
pressed three times to enable the rear
seat for two minutes, or the ignition must be in
ON or ACCESSORY.
The vehicle must be in PARK (P).
The vehicle cannot have a low battery.After the seat has folded, the panel on the seat
must be folded forward to create the at oor.
If the seat’s path is blocked it will stop and back
away. Press the button again to return the seat to
its previous position.
Before returning the third row seat to the
passenger seating position, the panel must be
folded back upon itself. Press and hold one of the
power folding seat buttons and the seat will
unfold into the seating position. If the seat is not
unfolded fully into the seating position, a chime will
sound when the vehicle is shifted out of PARK (P).
This indicates that the seat is not ready for a
passenger.
Replace the head rests.
21

Sun Visors
Swing down the primary visor to block out glare.
It can also be detached from the center mount and
moved to the side to block glare from that
direction.
The driver’s sunshade may also have buttons for
a built-in garage door opener. SeeUniversal
Home Remote System (With Three Round LED)
on page 143orUniversal Home Remote
System (With One Triangular LED) on page 143
for more information.
Lighted Visor Vanity Mirror
Pull the visor down and lift the cover. The light will
automatically come on. The light will go out when
you close the cover.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Theft-Deterrent System
The security light is
located on the
instrument panel cluster.
If the ignition is off and a door is open, the
security light will ash, reminding you to arm the
theft-deterrent system.
To arm the system, do the following:
1. Lock the door using the Remote Keyless
Entry (RKE) transmitter or the power door
lock switch.
2. Close all the doors. The security light will
illuminate. It should go off within approximately
30 seconds.
If a door or a liftgate is opened without a key or a
RKE transmitter, the horn will sound and the
lamps will ash for up to 30 seconds.
112

Outside Power Heated Mirrors
The power mirror
controls are located on
the driver’s door
armrest and operate
both outside rearview
mirrors.
Press (A) to select the driver’s side mirror.
The LED indicator will turn on to indicate
that this mirror is selected. Then press
the arrows located on the four-way control pad
to adjust the mirror. Press (A) again to
deselect the mirror. The LED indicator will turn
off to indicate that this mirror is de-selected.
Press (B) to select the passenger’s side
mirror. The LED indicator will turn on to
indicate that this mirror is selected. Then press
the arrows located on the four-way control
pad to adjust the mirror. Press (B) again
to deselect the mirror. The LED indicator will
turn off to indicate that this mirror is
de-selected.
If your vehicle has the power fold function, use the
following buttons:
Press (C), to fold the mirrors out to the driving
position.
Press (D) to fold the mirrors in to the folded
position.
If the mirrors are accidentally folded/unfolded
manually, they may shake or utter at normal
driving speeds and may not stay in the unfolded
position. If this happens, you will need to reset the
mirrors. See “Resetting the Power Foldaway
Mirrors” next.
137

How OnStar®Service Works
In order to provide you with OnStar®services,
your vehicle’s OnStar®system has the capability
of recording and transmitting vehicle information.
This information is automatically sent to an
OnStar
®Call Center at the time of an OnStar®
button press, Emergency button press or if
your airbags or AACN system deploys. The vehicle
information usually includes your GPS location
and, in the event of a crash, additional information
regarding the accident that your vehicle has
been involved in (e.g. the direction from which
your vehicle was hit). When you use the Virtual
Advisor feature of OnStar
®Hands-Free Calling,
your vehicle also sends OnStar®your GPS
location so that we can provide you with
location-based services.
OnStar
®service cannot work unless your vehicle
is in a place where OnStar®has an agreement
with a wireless service provider for service in that
area. OnStar
®service also cannot work unless
you are in a place where the wireless service
provider OnStar
®has hired for that area
has coverage, network capacity and reception
when the service is needed, and technology thatis compatible with the OnStar
®service. Not all
services are available everywhere, particularly in
remote or enclosed areas, or at all times.
OnStar
®service that involves location information
about your vehicle cannot work unless GPS
satellite signals are unobstructed and available in
that place as well.
Your vehicle must have a working electrical
system (including adequate battery power) for the
OnStar
®equipment to operate. There are other
problems OnStar®cannot control that may prevent
OnStar®from providing OnStar®service to you
at any particular time or place. Some examples are
damage to important parts of your vehicle in an
accident, hills, tall buildings, tunnels, weather
or wireless phone network congestion.
Your Responsibility
You may need to increase the volume of your radio
to hear the OnStar®advisor. If the light next to the
OnStar®buttons is red, this means that your system
is not functioning properly and should be checked
by a dealer. If the light appears clear (no light is
appearing), your OnStar
®subscription has expired.
You can always press the OnStar®button to
conrm that your OnStar®equipment is active.
142

This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful
interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation.
The FCC Grant of Equipment Authorization
Certicate number is CB2SAHL3.
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation of the device.
The Canadian Registration ID number is
2791021849A.
Changes or modications to this system by other
than an authorized service facility could void
authorization to use this equipment.Universal Home Remote System
Operation (With Three Round LED)
Your vehicle may have the Universal Home Remote
System. If there are three round Light Emitting
Diode (LED) above the Universal Home Remote
System buttons, follow the instructions below. If
there is one triangular LED above the Universal
Home Remote System buttons, follow the
instructions under Universal Home Remote System
Operation (with one triangular LED).
This system provides a way to replace up to
three remote control transmitters used to activate
devices such as garage door openers, security
systems, and home lighting.
Do not use this system with any garage door
opener that does not have the stop and reverse
feature. This includes any garage door opener
model manufactured before April 1, 1982.
144

Read the instructions completely before attempting
to program the transmitter. Because of the steps
involved, it may be helpful to have another
person available to assist you in programming the
transmitter.
Be sure to keep the original remote control
transmitter for use in other vehicles, as well as, for
future programming. You only need the original
remote control transmitter for xed code
programming. It is also recommended that upon
the sale or lease termination of the vehicle,
the programmed buttons should be erased for
security purposes. See “Erasing your Universal
Home Remote Buttons” later in this section.
Be sure that people and objects are clear of the
garage door or security device you are
programming. When programming a garage door,
it is advised to park outside of the garage.If you do not know if your garage door opener is a
xed code or rolling code device, open your
garage door opener’s remote control battery cover.
Your garage door opener is a xed code device
if there is a panel of switches. If not, your
garage door opener is a rolling code device.
145

Programming Universal Home
Remote — Fixed Code
Fixed Code garage door openers are used for
garage doors produced prior to 1996. Fixed code
uses the same coded signal every time, which
is manually programmed by setting DIP switches
for a unique personal code.
To program up to three channels,
1. Remove the battery cover of the hand-held
transmitter.
2. Write down the eight to 12 coding switch
settings from left to right. When the switch
is in the up position, write “on,” and when a
switch is in the down position, write “off”.
If a switch is set between the up and down
position, write “middle”.
3. Enter these positions into the Universal Home
Remote System as follows.
Press and release all three buttons at
the same time to put the device into
programming mode.
Example of Switch Settings
146
