headlamp CADILLAC STS 2008 1.G Owner's Guide

Tire Pressure Monitor System.........................5-68
Tire Pressure Monitor Operation.....................5-70
Tire Inspection and Rotation...........................5-73
When It Is Time for New Tires.......................5-75
Buying New Tires.........................................5-76
Different Size Tires and Wheels......................5-78
Uniform Tire Quality Grading..........................5-79
Wheel Alignment and Tire Balance..................5-80
Wheel Replacement......................................5-80
Tire Chains..................................................5-82
Lifting Your Vehicle (STS-V)...........................5-83
If a Tire Goes Flat........................................5-86
Tire Sealant and Compressor Kit....................5-87
Changing a Flat Tire.....................................5-96
Removing the Spare Tire and Tools................5-98
Removing the Flat Tire and Installing
the Spare Tire..........................................5-99
Storing a Flat or Spare Tire and Tools...........5-104
Compact Spare Tire....................................5-106
Appearance Care..........................................5-107
Interior Cleaning.........................................5-107
Fabric/Carpet..............................................5-108
Leather......................................................5-109
Instrument Panel, Vinyl, and Other
Plastic Surfaces.......................................5-109
Wood Panels..............................................5-110Speaker Covers..........................................5-110
Care of Safety Belts....................................5-110
Weatherstrips.............................................5-110
Washing Your Vehicle..................................5-110
Cleaning Exterior Lamps/Lenses....................5-111
Finish Care................................................5-111
Windshield and Wiper Blades.......................5-112
Aluminum or Chrome-Plated Wheels and Trim . . .5-112
Tires.........................................................5-113
Sheet Metal Damage...................................5-113
Finish Damage...........................................5-114
Underbody Maintenance...............................5-114
Chemical Paint Spotting...............................5-114
Vehicle Care/Appearance Materials................5-115
Vehicle Identication.....................................5-116
Vehicle Identication Number (VIN)................5-116
Service Parts Identication Label...................5-116
Electrical System..........................................5-116
Add-On Electrical Equipment.........................5-116
Headlamp Wiring........................................5-117
Windshield Wiper Fuses...............................5-117
Power Windows and Other Power Options......5-117
Fuses and Circuit Breakers..........................5-117
Underhood Fuse Block................................5-118
Rear Underseat Fuse Block..........................5-121
Capacities and Specications........................5-128
Section 5 Service and Appearance Care
5-2

How to Check Lubricant
A. Drain Plug
B. Filler Plug
To get an accurate reading, the vehicle should be on a
level surface.
If the level is below the bottom of the ller plug hole,
located on the front axle, you may need to add
some lubricant.
What to Use
Refer to the Maintenance Schedule to determine what
kind of lubricant to use. SeeRecommended Fluids
and Lubricants on page 6-13.
Headlamp Aiming
Headlamp aim has been preset at the factory and
should need no further adjustment.
However, if your vehicle is damaged in a crash, the
headlamp aim may be affected. Aim adjustment to the
low-beam headlamps may be necessary if oncoming
drivers ash their high-beam headlamps at you
(for vertical aim).
If the headlamps need to be re-aimed, it is
recommended that you take the vehicle to your
dealer/retailer for service.
5-53

Bulb Replacement
For the proper type of replacement bulbs, see
Replacement Bulbs on page 5-55.
For any bulb changing procedure not listed in this
section, contact your dealer/retailer.
High Intensity Discharge (HID)
Lighting
{CAUTION:
The low beam high intensity discharge lighting
system operates at a very high voltage. If you
try to service any of the system components,
you could be seriously injured. Have your
dealer/retailer or a qualied technician
service them.
Your vehicle has HID headlamps. After your vehicle’s
HID headlamp bulb has been replaced, you may notice
that the beam is a slightly different shade than it was
originally. This is normal.
Halogen Bulbs
{CAUTION:
Halogen bulbs have pressurized gas inside and
can burst if you drop or scratch the bulb. You or
others could be injured. Be sure to read and
follow the instructions on the bulb package.
Back-Up Lamps
To replace a back-up lamp bulb:
1. Open the trunk. SeeTrunk on page 2-16for more
information.
5-54

Your dealer/retailer will know the kind of wheel
you need.
Each new wheel should have the same load-carrying
capacity, diameter, width, offset, and be mounted
the same way as the one it replaces.
If you need to replace any of your wheels, wheel bolts,
wheel nuts, or Tire Pressure Monitor System (TPMS)
sensors, replace them only with new GM original
equipment parts. This way, you will be sure to have the
right wheel, wheel bolts, wheel nuts, and TPMS
sensors for your vehicle.
{CAUTION:
Using the wrong replacement wheels, wheel
bolts, or wheel nuts on your vehicle can be
dangerous. It could affect the braking and
handling of your vehicle, make your tires lose
air and make you lose control. You could have
a collision in which you or others could be
injured. Always use the correct wheel, wheel
bolts, and wheel nuts for replacement.Notice:The wrong wheel can also cause problems
with bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper height,
vehicle ground clearance, and tire or tire chain
clearance to the body and chassis.
SeeChanging a Flat Tire on page 5-96for more
information.
Used Replacement Wheels
{CAUTION:
Putting a used wheel on your vehicle is
dangerous. You cannot know how it has been
used or how far it has been driven. It could fail
suddenly and cause a crash. If you have to
replace a wheel, use a new GM original
equipment wheel.
5-81

Headlamp Wiring
The headlamp wiring is protected by fuses in the fuse
block. An electrical overload will cause the lamps to turn
off. If this happens, have your headlamp wiring
checked right away.
Windshield Wiper Fuses
The windshield wiper motor is protected by an internal
circuit breaker. If the wiper motor overheats due to
heavy snow, the wipers will stop until the motor cools
and will then restart.
Power Windows and Other Power
Options
Circuit breakers in the fuse block protect the power
windows and other power accessories. When the
current load is too heavy, the circuit breaker opens
and closes, protecting the circuit until the problem is
xed or goes away.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links. This greatly reduces the
chance of res caused by electrical problems.
Look at the silver-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical
size and rating.
If you ever have a problem on the road and don’t have
a spare fuse, you can borrow one that has the same
amperage. Just pick some feature of your vehicle
that you can get along without – like the radio or
cigarette lighter – and use its fuse, if it is the correct
amperage. Replace it as soon as you can.
5-117

The underhood fuse block is located in the front of the
engine compartment on the passenger’s side of the
vehicle. SeeEngine Compartment Overview on
page 5-11for more information on location and removal
procedure for the front compartment underhood
sights shields.
To access the fuses, push in the tabs located on each
side of the fuse block cover, then lift the cover off.
Notice:Spilling liquid on any electrical components
on your vehicle may damage it. Always keep the
covers on any electrical component.
Fuses JCase Usage
ABS MTRABS Module- ABS
Module-StabiliTrak
®
AFS Active Front Steering
BLWR Blower Motor
FAN 1 Cooling Fan-Low Speed
FAN 2 Cooling Fan-High Speed
LPDB 1 Driver Side Rear Fuse Block
LPDB 2 Driver Side Rear Fuse Block
RPDB 1 Passenger Side Rear Fuse Block
RPDB 2 Passenger Side Rear Fuse Block
SPARE Spare
SPARE Spare
STRTR Starter
Fuses Mini Usage
A/C CLTCH Air Conditioning Compressor Clutch
ABS ABS Module-StabiliTrak
®
ABS IGN Antilock Brake Controller
AUX OUTLET Rear Accessory Power Outlet
BRK VAC
PUMPBrake Vacuum Pump
CCP Climate Control Panel
CCP/RLY
COILSClimate Control Panel, Headlamp
Level Control, Active Cruise Control,
Relay Coils, Starter, Front Blower
ECM 1 Engine Control Module (ECM)
ECM/TCM
BATTECM, Transmission Control
Module (TCM)
ECM/TCM IGNECM, TCM, Instrument Panel
Cluster
EKM/I/P MDLEasy Key Module (EKM), Instrument
Panel Module (I/P MDL)
EVEN COILSEven Ignition Coils, Even Fuel
Injectors
FOG LAMP Front Fog Lamps
FRT PWR
OUTLETFront Accessory Power Outlet
FUEL COOL Fuel Cooling
HORN Horn
HTD
WASH/AQSHeated Headlamp Washer, Air
Quality Sensor
5-119

Fuses Mini Usage
HUDHeads-Up Display, Steering Column
Switch
I/BEAM IntelliBeam Relay
I/P MDL/ALDLInstrument Panel Module, Assembly
Line Data Link Connector
LIC DIMLicense Plate, Instrument Panel
Dimming
LT HI BEAM Driver Side High Beam Headlamp
LT LO BEAM Driver Side Low Beam Headlamp
LT PRKDriver Side Park Lamp/Driver Side
Taillamp
ODD COILSOdd Ignition Coils, Odd Fuel
Injectors
POST
O2 SNSRPost Oxygen Sensor
PRE O2 SNSR Pre Oxygen Sensor, CAM Sensors
RAIN
SNSR/TPMRain Sensor, Relay Coil:
Headlamp Wash
RT HI BEAMPassenger Side High Beam
Headlamp
RT LO BEAMPassenger Side Low Beam
Headlamp
RT PRKPassenger Side Park Lamp,
Passenger Side Taillamp
SPARE Spare
SPARE SpareFuses Mini Usage
SPARE Spare
SPARE Spare
SPARE Spare
SPARE Spare
SPARE Spare
V/CHKInstrument Panel Module-Voltage
Check
WPR Wipe/Wash Module Assembly
WPR SW/VICS Rain Sensor, Wiper Switch
Relays Usage
A/C CMPRSR
CLTCHAir Conditioning Compressor Clutch
ACCYAccessory Rain Sensor, Headlamp
Washer Relay Coil, Windshield
Wiper/Washer Module
BRK
VAC PUMPBrake Vacuum Pump
FAN S/P Cooling Fan Series/Parallel
FOG LAMP Fog Lamps
FRT BLWR Front Blower Motor
FUEL COOL Fuel Cooling Pump
HI BEAM High Beam Headlamp
HI FAN SPD Cooling Fan High Speed
HORN Horn
5-120

Relays Usage
LO FAN SPD Cooling Fan Low Speed
LOW BEAM
W/O HID/HIDLow Beam Headlamp, High Intensity
Discharge (HID)
PRK LAMPParking Lamps, Instrument Panel
Dimming, Rear License Plate Lamps
PWR/TRN Engine Controls
RUN CRNKHeated Washer Nozzle, Air Quality,
Antilock Brake System, Climate
Control Panel, TCM, ECM,
Instrument Control Panel, Instrument
Control Panel Cluster
SPARE Spare
SPARE Spare
SPARE Spare
STRTR Starter
WPR HI Windshield Wiper High Speed
Circuit
BreakersUsage
HDLP WASHHeadlamp Washer Motor
(Circuit Breaker)
Rear Underseat Fuse Block
Removing the Rear Seat Cushion
Notice:If you touch the exposed wires with the
metal on the seat cushion, you could cause a short
that could damage the battery and or wires. Avoid
contact between the rear seat and the fuse
center whenever you remove or reinstall the rear
seat. Do not remove covers from any of the covered
parts, and do not store anything under the seats.
To remove the rear seat cushion, do the following:
1. Pull up on the front of the cushion to release the
front hooks.
2. Pull the cushion up and out toward the front of the
vehicle.
5-121

Audio System (cont.)
Setting the Time..........................................3-99
Theft-Deterrent Feature...............................3-121
XM™ Satellite Radio Antenna System...........3-124
Audio System(s)............................................3-100
Automatic Transmission
Fluid..........................................................5-25
Operation...................................................2-32
B
Backglass Antenna........................................3-124
Battery..........................................................5-44
Electric Power Management..........................3-42
Exterior Lighting Battery Saver......................3-40
Inadvertent Power Saver..............................3-43
Load Management.......................................3-42
Brake
Emergencies................................................ 4-6
Brakes..........................................................5-41
Panic Assist................................................4-12
System Warning Light..................................3-64
Braking........................................................... 4-4
Braking in Emergencies..................................... 4-6
Break-In, New Vehicle.....................................2-27
Bulb Replacement...........................................5-54
Back-Up Lamps...........................................5-54
Halogen Bulbs............................................5-54
Headlamp Aiming........................................5-53Bulb Replacement (cont.)
High Intensity Discharge (HID) Lighting...........5-54
Replacement Bulbs......................................5-55
Buying New Tires...........................................5-76
C
Calibration...............................................1-7, 2-41
California Fuel.................................................. 5-6
California Perchlorate Materials Requirements....... 5-4
California Proposition 65 Warning....................... 5-3
Canadian Owners................................................ ii
Capacities and Specications..........................5-128
Carbon Monoxide...........2-16, 2-38, 4-22, 4-34, 4-40
Care of
Safety Belts..............................................5-110
CD, MP3 .....................................................3-112
Center Console Storage Area...........................2-58
Chains, Tire...................................................5-82
Charging System Light....................................3-63
Check
Engine Light...............................................3-68
Checking Things Under the Hood......................5-10
Chemical Paint Spotting.................................5-114
Child Restraints
Child Restraint Systems...............................1-34
Infants and Young Children...........................1-30
Lower Anchors and Tethers for Children..........1-37
Older Children.............................................1-28
2

Customer Assistance Information (cont.)
Roadside Service.......................................... 7-6
Service Publications Ordering Information........7-15
DDaytime Running Lamps..................................3-37
Defensive Driving............................................. 4-2
Disc, MP3....................................................3-112
Doing Your Own Service Work........................... 5-4
Door
Locks........................................................2-14
Power Door Locks.......................................2-14
Programmable Automatic Door Locks.............2-15
Rear Door Security Locks.............................2-15
Driver Information Center (DIC).........................3-74
DIC Operation and Displays..........................3-74
DIC Warnings and Messages........................3-80
Other Messages..........................................3-97
Driving
At Night.....................................................4-18
Before a Long Trip......................................4-20
Defensive..................................................... 4-2
Drunken....................................................... 4-2
Highway Hypnosis.......................................4-20
Hill and Mountain Roads..............................4-21
In Rain and on Wet Roads...........................4-19
Rocking Your Vehicle to Get it Out.................4-26
Winter........................................................4-22
Dual Climate Control System............................3-48
E
EDR .............................................................7-16
Electrical System
Add-On Equipment.....................................5-116
Fuses and Circuit Breakers.........................5-117
Headlamp Wiring.......................................5-117
Power Windows and Other Power Options....5-117
Rear Underseat Fuse Block.........................5-121
Underhood Fuse Block...............................5-118
Windshield Wiper Fuses.............................5-117
Engine
Air Cleaner/Filter.........................................5-23
Check and Service Engine Soon Light............3-68
Coolant......................................................5-25
Coolant Heater............................................2-31
Coolant Temperature Gage...........................3-67
Coolant Temperature Warning Light................3-66
Drive Belt Routing.......................................6-16
Engine Compartment Overview......................5-11
Exhaust.....................................................2-38
Oil .............................................................5-18
Oil Life System...........................................5-21
Overheated Protection Operating Mode...........5-31
Overheating................................................5-29
Running While Parked..................................2-39
Starting......................................................2-29
4
