Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 379
If the tire is overinflated by
more than 35 kPa (5 psi), the
horn will sound multiple times
and the turn signal lamp will
continue to flash for several
seconds after filling stops. To
release and correct the
pressure, while the turn signal
lamp is still flashing, briefly
press the center of the valve
stem. When the recommended
pressure is reached, the horn
sounds once.
If the turn signal lamp does
not flash within 15 seconds
after starting to inflate the
tire, the tire fill alert has not
been activated or is not
working.
If the hazard warning flashers
are on, the tire fill alert visual
feedback will not work
properly.
The TPMS will not activate the
tire fill alert properly under the
following conditions:
.There is interference from
an external device or
transmitter.
.The air pressure from the
inflation device is not
sufficient to inflate the tire.
.There is a malfunction in
the TPMS.
.There is a malfunction in the
horn or turn signal lamps.
.The identification code of
the TPMS sensor is not
registered to the system.
.The battery of the TPMS
sensor is low.
If the tire fill alert does not
operate due to TPMS
interference, move the vehicle
about 1 m (3 ft) back or
forward and try again. If the
tire fill alert feature is not
working, use a tire pressure
gauge.
TPMS Sensor Matching
Process
Each TPMS sensor has a
unique identification code. The
identification code needs to be
matched to a new tire/wheel
position after rotating the
vehicle’s tires or replacing one or more of the TPMS sensors.
The TPMS sensor matching
process should also be
performed after replacing a
spare tire with a road tire
containing the TPMS sensor.
The malfunction light and the
DIC message should go off at
the next ignition cycle. The
sensors are matched to the
tire/wheel positions, using a
TPMS relearn tool, in the
following order: driver side
front tire, passenger side front
tire, passenger side rear tire,
and driver side rear. See your
dealer for service or to
purchase a relearn tool.
A TPMS relearn tool can also
be purchased. See Tire
Pressure Monitor Sensor
Activation Tool at www.
gmtoolsandequipment.com or
call 1-800-GM TOOLS
(1-800-468-6657).
There are two minutes to
match the first tire/wheel
position, and five minutes
overall to match all four tire/

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
380 Vehicle Care
wheel positions. If it takes
longer, the matching process
stops and must be restarted.
The TPMS sensor matching
process is:1. Set the parking brake.
2. Place the vehicle in Service Mode. See Ignition
Positions 0247.
3. Make sure the Tire Pressure info display
option is turned on. The
info displays on the DIC
can be turned on and off
through the Options menu.
See Driver Information
Center (DIC) 0136.
4. Use the five-way DIC control on the right side of
the steering wheel to scroll
to the Tire Pressure
screen under the DIC info
page. See Driver
Information Center (DIC)
0136.
5. Press and hold the thumbwheel in the center
of the five-way DIC control. The horn sounds twice to
signal the receiver is in
relearn mode and the TIRE
LEARNING ACTIVE
message displays on the
DIC screen.
6. Start with the driver side front tire.
7. Place the relearn tool against the tire sidewall,
near the valve stem. Then
press the button to
activate the TPMS sensor.
A horn chirp confirms that
the sensor identification
code has been matched to
this tire and wheel
position.
8. Proceed to the passenger side front tire, and repeat
Step 7.
9. Proceed to the passenger side rear tire, and repeat
Step 7.
10. Proceed to the driver side rear tire, and repeat
Step 7. The horn sounds
two times to indicate the
sensor identification code has been matched to the
driver side rear tire, and
the TPMS sensor matching
process is no longer active.
The TIRE LEARNING
ACTIVE message on the
DIC display screen
goes off.
11. Turn the vehicle off.
12. Set all four tires to the recommended air pressure
level as indicated on the
Tire and Loading
Information label.
Tire Inspection
We recommend that the
tires, including the spare
tire, if the vehicle has one,
be inspected for signs of
wear or damage at least
once a month.
Replace the tire if:
.The indicators at three or
more places around the
tire can be seen.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
404 Vehicle Care
Compact Spare Tire
{Warning
Driving with more than one
compact spare tire at a time
could result in loss of
braking and handling. This
could lead to a crash and
you or others could be
injured. Use only one
compact spare tire at a time.
If this vehicle has a compact
spare tire, it was fully inflated
when new; however, it can
lose air over time. Check the
inflation pressure regularly.
It should be 420 kPa (60 psi).
Stop as soon as possible and
check that the spare tire is
correctly inflated after being
installed on the vehicle. The
compact spare tire is designed
for temporary use only. The
vehicle will perform differently
with the spare tire installed
and it is recommended that
the vehicle speed be limited to
80 km/h (50 mph). To conserve the tread of the spare tire,
have the standard tire
repaired or replaced as soon
as convenient and return the
spare tire to the storage area.
When using a compact spare
tire, the AWD (if equipped),
ABS, and Traction Control
systems may engage until the
spare tire is recognized by the
vehicle, especially on slippery
roads. Adjust driving to reduce
possible wheel slip.
Caution
When the compact spare is
installed, do not take the
vehicle through an
automatic car wash with
guide rails. The compact
spare can get caught on the
rails which can damage the
tire, wheel, and other parts
of the vehicle.
Do not use the compact spare
on other vehicles. Do not mix the compact spare
tire or wheel with other
wheels or tires. They will not
fit. Keep the spare tire and its
wheel together.
Caution
Tire chains will not fit the
compact spare. Using them
can damage the vehicle and
the chains. Do not use tire
chains on the compact
spare.
Jump Starting
Jump Starting - North
America
For more information about
the vehicle battery, see
Battery - North America
0346.
If the battery has run down,
try to use another vehicle and
some jumper cables to start
your vehicle. Be sure to use
the following steps to do it
safely.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
460 Connected Services
vehicles, Wi-Fi can also be
managed from the Wi-Fi
Hotspot menu.
MyCadillac Mobile App (If
Available)
Download the myCadillac
mobile app to compatible
Apple and Android
smartphones. Cadillac users
can access the following
services from a smartphone:
.Remotely start/stop the
vehicle, if factory-equipped.
.Lock/unlock doors,
if equipped with automatic
locks.
.Activate the horn and lamps.
.Check the vehicle fuel level,
oil life, or tire pressure,
if factory-equipped with the
Tire Pressure Monitor
System.
.Send destinations to the
vehicle.
.Locate the vehicle on a map
(U.S. market only).
.Turn the vehicle's Wi-Fi
hotspot on/off, manage
settings, and monitor data
consumption, if equipped.
.Locate a dealer and
schedule service.
.Request Roadside
Assistance.
.Set a parking reminder with
pin drop, take a photo, make
a note, and set a timer.
.Connect with Cadillac on
social media.
Features are subject to
change. For myCadillac mobile
app information and
compatibility, see
my.cadillac.com.
An active OnStar or
connected service plan may be
required. A compatible device,
factory-installed remote start,
and power locks are required.
Data rates apply. See
www.onstar.com for details
and system limitations.
Remote Services
Contact an OnStar Advisor to
unlock the doors or sound the
horn and flash the lamps.
Marketplace
OnStar Advisors can provide
offers from restaurants and
retailers on your route, help
locate hotels, or book a room.
These services vary by
market.
Diagnostics
By monitoring and reporting
on the vehicle’s key systems,
OnStar Advanced Diagnostics,
if equipped, provides a way
to keep up on maintenance.
Capabilities vary by model. See
www.onstar.com for details
and system limitations.
Features are subject to
change. For updates on
feature capabilities, see
my.cadillac.com. Message and
data rates may apply.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
472 INDEX
Starting the Engine . . . . . . . . . 248
Steering . . . . . . . . . . . . . . . . . . . . . . . . . 231Heated Wheel . . . . . . . . . . . . . . . 110
Wheel Adjustment . . . . . . . . . 109
Wheel Controls . . . . . . . . . . . . . 159
Stop/Start System . . . . . . . . . . 249
Storage Center Console . . . . . . . . . . . . . 105
Compartments . . . . . . . . . . . . . . 102
Cupholders . . . . . . . . . . . . . . . . . . . 102
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Glove Box . . . . . . . . . . . . . . . . . . . . . 102
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Roof Rack System . . . . . . . . . 106
Sunglasses . . . . . . . . . . . . . . . . . . . 103
Umbrella . . . . . . . . . . . . . . . . . . . . . . 105
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . 106
Storing the Tire Sealant and
Compressor Kit . . . . . . . . . . . . . 398
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . 349
Stuck Vehicle . . . . . . . . . . . . . . . . . . 241
Summer Tires . . . . . . . . . . . . . . . . 366
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . 41
Sunglass Storage . . . . . . . . . . . . 103
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Surround Vision
System . . . . . . . . . . . . . . . . . . . . . . . . .287
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Navigation . . . . . . . . . . . . . . . . . . . . 177
System Airbag . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Driver Assistance . . . . . . . . . 284
Engine Air Filter Life . . . . . . 336
Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 297
Global Positioning . . . . . . . . . . 185
Infotainment . . . . . . . . . . . . . . . . 450
Rear Cross Traffic
Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Roof Rack . . . . . . . . . . . . . . . . . . . . . 106
Surround Vision . . . . . . . . . . . . . 287
T
Tachometer . . . . . . . . . . . . . . . . . . . . 122
Teen Driver . . . . . . . . . . . . . . . . . . . . 207
Text Telephone (TTY) Users . . . . . . . . . . . . . . . . . . . . . . . . . . 438
Theft-Deterrent Systems . . . . . . . . . . . . . . . . . . . . . . . . 33
Immobilizer . . . . . . . . . . . . . . . . . . . . 33
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 364
All-Season . . . . . . . . . . . . . . . . . . . 365 Tires (cont'd)
Buying New Tires . . . . . . . . . . 383
Chains . . . . . . . . . . . . . . . . . . . . . . . . 388
Changing . . . . . . . . . . . . . . . . . . . . . 398
Compact Spare . . . . . . . . . . . . 404
Designations . . . . . . . . . . . . . . . . 369
Different Size . . . . . . . . . . . . . . . 385
If a Tire Goes Flat . . . . . . . . . 389
Inspection . . . . . . . . . . . . . . . . . . . 380
Pressure . . . . . . . . . . . . . . . 372, 374
Pressure Light . . . . . . . . . . . . . . 134
Pressure Monitor
Operation . . . . . . . . . . . . . . . . . . 376
Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 375
Rotation . . . . . . . . . . . . . . . . . . . . . . . 381
Sealant and
Compressor Kit . . . . . . . . . . . 390
Sealant and Compressor Kit,
Storing . . . . . . . . . . . . . . . . . . . . . . 398
Sidewall Labeling . . . . . . . . . . 367
Terminology and Definitions . . . . . . . . . . . . . . . . . 370
Uniform Tire Quality Grading . . . . . . . . . . . . . . . . . . . . . 385
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . 387
