CHEVROLET AVEO 2009 1.G Owners Manual

Rear Window and Outside Mirror
Defogger
For vehicles with a rear window and outside mirror
defogger, they only work when the ignition is turned to
ON/RUN.
The rear window defogger uses a warming grid to
remove fog or frost from the rear window.
<(Rear Window Defogger):Press to turn the rear
window and outside mirror defogger on or off. An
indicator light comes on to show that the feature is on.
If the vehicle does not have air conditioning, the rear
window defogger may turn off about 10 minutes after the
button is pressed. If it remains on, it can be turned off by
pressing
If the vehicle has air conditioning, the rear window
defogger turns off about 10 minutes after the button is
pressed. The defogger can also be turned off by turning
the engine off.
Notice:Do not use anything sharp on the inside of
the rear window. If you do, you could cut or
damage the warming grid, and the repairs would not
be covered by the vehicle warranty. Do not attach
a temporary vehicle license, tape, a decal or
anything similar to the defogger grid.
Outlet Adjustment
To open an outlet, press on its cover. Turn the cover to
change the direction of the airow.
Operation Tips

Clear away any ice, snow or leaves from the air
inlets at the base of the windshield that may
block the ow of air into the vehicle.
Use of non-GM approved hood deectors may
adversely affect the performance of the system.
Keep the path under the front seats clear of objects
to help circulate the air inside of the vehicle more
effectively.
3-21

Passenger Compartment Air Filter
For vehicles with a passenger compartment air lter, it is
located behind the glove box. It can be accessed after
removing the glove box from its housing.
Pollen and dust are removed by the lter. The air
cleaner/lter may need to be changed periodically.
To change the passenger compartment air lter, use the
following steps:
1. Open the glove box halfway down.
2. Grip the glove box by both the upper and lower
sides and pull it out of its housing.3. Remove the lter cover by pressing in on the
bottom retaining tab and pulling the cover down.
3-22

4. Replace the air conditioner lter.
5. View the air ow arrows on the lter before installing
to ensure the lter is installed correctly.
Warning Lights, Gages, and
Indicators
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause
an expensive repair or replacement. Paying attention to
the warning lights and gages could prevent injury.
Warning lights come on when there may be or is a
problem with one of the vehicle’s functions. Some
warning lights come on briey when the engine is started
to indicate they are working.
Gages can indicate when there may be or is a problem
with one of the vehicle’s functions. Often gages and
warning lights work together to indicate a problem with
the vehicle.
When one of the warning lights comes on and stays on
while driving, or when one of the gages shows there
may be a problem, check the section that explains what
to do. Follow this manual’s advice. Waiting to do
repairs can be costly and even dangerous.
3-23

Instrument Panel Cluster
The instrument panel cluster is designed to show how the vehicle is running. It indicates how fast the vehicle is
going, how much fuel is being used, and many other things needed to drive safely and economically.
The vehicle’s instrument panel cluster includes indicator warning lights and gages that are explained on the following
pages.
United States Manual Transmission shown, Canada and Automatic Transmission similar
3-24

Speedometer and Odometer
The speedometer shows the vehicle’s speed in both
miles per hour (mph) and kilometers per hour (km/h).
The odometer shows how far the vehicle has been
driven, in either miles (used in the United States)
or kilometers (used in Canada).
Trip Odometer
The trip odometer can record the number of miles, used
in the United States, or kilometers, used in Canada,
traveled for up to two trips.
Cycle between the odometer and trip odometers A
and B by pressing the reset button located in the lower
right area of the speedometer. Press the reset button
to tell how many miles or kilometers have been recorded
on either Trip A or Trip B since the trip odometer was
last set back to zero.
To reset each trip odometer to zero, press and hold the
reset button. The reset button resets only the trip
odometer that is being displayed. Each trip odometer
must be reset individually.
Tachometer
The tachometer displays the engine speed in revolutions
per minute (rpm).
Notice:If the engine is operated above 6,500 rpm,
the vehicle could be damaged, and the damages
would not be covered by the vehicle warranty.
Do not operate the engine with the tachometer
above 6,500 rpm.
3-25

Safety Belt Reminders
Safety Belt Reminder Light
When the engine is
started this light and chime
comes on and stays on
for several seconds
to remind the people to
fasten their safety belts.
The light also begins
to ash.
This cycle repeats if the driver remains unbuckled and
the vehicle is moving.
If the driver safety belt is already buckled, neither the
light nor chime comes on.
Airbag Readiness Light
There is an airbag readiness light on the instrument
panel cluster, which shows the airbag symbol.
The system checks the airbag’s electrical system for
malfunctions. The light tells if there is an electrical
problem. The system check includes the airbag sensor,
the airbag modules, the wiring and the crash sensing
and diagnostic module. For more information on
the airbag system, seeAirbag System on page 1-60.This light comes on when
the vehicle is started,
and it will ash for a
few seconds. When the
light goes out this indicates
the system is functioning
properly.
If the airbag readiness light stays on or comes on while
driving, the airbag system may not work properly.
Have the vehicle serviced right away.
{CAUTION:
If the airbag readiness light stays on after the
vehicle is started or comes on while driving, it
means the airbag system might not be working
properly. The airbags in the vehicle might not
inate in a crash, or they could even inate
without a crash. To help avoid injury, have the
vehicle serviced right away.
3-26

Passenger Airbag Status Indicator
The vehicle has the passenger sensing system.
SeePassenger Sensing System on page 1-67for
important safety information. The vehicle has a
passenger airbag status indicator near the clock,
located in the center of the instrument panel.
When the vehicle is started, the passenger airbag status
indicator will light ON and OFF or the symbol for on and
off, for several seconds as a system check. Then, after
several more seconds, the status indicator will light either
ON or OFF, or either the on or off symbol, to let you know
the status of the right front passenger frontal and
seat-mounted side impact airbag (if equipped).If the word ON or the on symbol is lit on the passenger
airbag status indicator, it means that the right front
passenger frontal airbag and seat-mounted side impact
airbag (if equipped) is enabled (may inate).
If the word OFF or the off symbol is lit on the passenger
airbag status indicator, it means that the passenger
sensing system has turned off the right front passenger
frontal airbag and seat-mounted side impact airbag
(if equipped).
If, after several seconds, both status indicator lights
remain on, or if there are no lights at all, there may be
a problem with the lights or the passenger sensing
system. See your dealer/retailer for service.
{CAUTION:
If the airbag readiness light ever comes on and
stays on, it means that something may be wrong
with the airbag system. To help avoid injury to
yourself or others, have the vehicle serviced right
away. SeeAirbag Readiness Light on page 3-26
for more information, including important safety
information. United States
Canada
3-27

Charging System Light
This light will come on briey when the ignition is turned
on, and the engine is not running, as a check to show
it is working.
It should go out when the engine is started. If it stays
on, or comes on while driving, there may have a problem
with the electrical charging system. Have it checked
by your dealer/retailer. Driving while this light is on could
drain the battery. If a short distance must be driven
with the light on, turn off all accessories, such as
the radio and air conditioner to help reduce the drain
on the battery.
Up-Shift Light
The vehicle may have an
up-shift light.
When this light comes on, shift to the next higher gear if
weather, road, and traffic conditions allow.
SeeManual Transmission Operation on page 2-26for
more information.
Brake System Warning Light
The vehicle’s hydraulic brake system is divided into
two parts. If one part is not working, the other part can
still work and stop the vehicle. For good braking,
both parts need to work.
3-28

{CAUTION:
The brake system might not be working properly if
the brake system warning light is on. Driving with
the brake system warning light on can lead to a
crash. If the light is still on after the vehicle has
been pulled off the road and carefully stopped,
have the vehicle towed for service.If the warning light comes on, there is a brake problem.
Have the brake system inspected right away.
When the ignition is on, the brake system warning light
will also come on when the parking brake is set.
The light will stay on if the parking brake does not fully
release. If it stays on after the parking brake is fully
released, it means there is a brake problem.
If the light comes on while driving, carefully pull off the
road and stop. The pedal may be harder to push or
may go closer to the oor. It may take longer to stop.
If the light is still on, have the vehicle towed for service.
SeeTowing Your Vehicle on page 4-24. United States
Canada
3-29

Antilock Brake System (ABS)
Warning Light
For vehicles with the
Antilock Brake System
(ABS), this light comes on
briey when the engine
is started.
If the light stays on, turn the ignition to LOCK/OFF or if
the light comes on, stop as soon as possible and
turn the ignition off. Then start the engine again to reset
the system. If the light still stays on, or comes on
again while driving, the vehicle needs service. See your
dealer/retailer. If the regular brake system warning
light is not on, the brakes will still work, but the antilock
brakes will not work. If the regular brake system
warning light is also on, the antilock brakes will not
work and there is a problem with the regular brakes.
SeeBrake System Warning Light on page 3-28.The ABS warning light will come on briey when the
ignition is turned to ON/RUN. This is normal. If the light
does not come on then, have it xed so it will be
ready to warn if there is a problem.
Hold Mode Light
If the vehicle has this
feature, this light comes on
when the hold mode is
active.
If the HOLD mode light ashes, have the vehicle
checked. See “Hold Mode” underAutomatic
Transmission Operation on page 2-22for more
information.
3-30
