2-8 Lockout Prevention
To protect you from locking your keys in the vehicle,
this feature stops the power door locks from locking
when the keys are in the ignition and a door is open.
If the power lock switch is pressed when a door is open,
a chime will sound five times as a reminder to take the
keys out of the ignition before locking the door.
The vehicle is shipped from the factory with this feature
turned on. If you would like to turn this feature off, see
ªFeature Customizationº in the Index.
Leaving Your Vehicle
If you are leaving the vehicle, take your keys, open your
door and set the locks from inside. Then get out and
close the door.
Keyless Entry System (Option)
If your vehicle has this feature, you can lock and unlock
your doors or unlock your trunk from about 3 feet (1 m)
up to 30 feet (9 m) away using the remote keyless entry
transmitter supplied with your vehicle.
Your keyless entry system operates on a radio frequency
subject to Federal Communications Commission (FCC)
Rules and with Industry Canada.

2-9
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

Check to determine if battery replacement or
resynchronization is necessary. See the instructions
that follow.

If you're still having trouble, see your dealer or a
qualified technician for service.

2-10 Operation
The driver's door will unlock automatically when
UNLOCK is pressed on the transmitter. If UNLOCK
is pressed again within five seconds, the passenger's
door will also unlock. All doors will lock when LOCK
is pressed.
The hatch will unlock when the REAR 2X button on the
transmitter is pressed twice within five seconds (pause
slightly between presses) and as long as the ignition is
turned to OFF. If the ignition is on, the REAR 2X button
will only work if the transmission is in PARK (P) for an
automatic transmission, or if the parking brake is set on
a manual transmission.
The system will turn on the interior lamps for about
40 seconds (or until the ignition is turned to RUN),
when you unlock the doors or hatch. The interior lamps
will go off when you lock the doors.
Operating the remote keyless entry transmitter may
interact with the content theft
-deterrent/alarm system
(option). See ªContent Theft
-Deterrent/Alarm Systemº
in the Index.Alarm/Panic Mode
If you are involved in a panic situation, press the horn
symbol button on your remote keyless entry transmitter
and the horn will sound and the parking lamps will
flash. This will draw needed attention to you and your
vehicle. To turn this feature off, either push the horn
symbol button again or turn the ignition key to RUN.
This feature will not work if your ignition is on or if
the transmitter is 30 feet (9 m) or more away from
your vehicle.
Transmitter Verification
This feature provides feedback to the holder of the
remote keyless entry transmitter that a command has
been received by the keyless entry receiver. The parking
lamps will flash on every lock and unlock command and
the horn will sound only if the LOCK button is pressed
twice within five seconds. This allows for silent
operation of locking and unlocking, unless a confirming
horn chirp is desired. Other options may be selected for
this feature (see ªFeature Customizationº in the Index).

2-11
Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
Have each transmitter you intend to match ready for
the next steps. To match transmitters to your vehicle,
do the following:
1. Turn the ignition key to RUN, then to OFF. This
will disarm the content theft
-deterrent/alarm
system (option).
2. Remove the RADIO fuse. This fuse is located in the
main fuse block which is located on the left side of
your instrument panel. See ªFuses and Circuit
Breakersº in the Index.3. Turn the ignition key from OFF to RUN three times
quickly (within five seconds). The vehicle will respond
by locking the doors, unlocking the driver's door and
releasing the hatch. Your transmitter is now ready to
match the vehicle. Leave the ignition in RUN.
4. Press and hold the LOCK and UNLOCK buttons on
the first transmitter for 15 seconds. The vehicle will
respond as in Step 3.
5. Repeat Step 4 for the remaining transmitters.
6. When you have finished matching all of your
transmitters, replace the RADIO fuse.
7. Check that all transmitters work by pressing
the buttons.
If the transmitters don't work, or if you'd rather not
match the transmitters yourself, see your dealer.

2-12 Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about two years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.NOTICE:
When replacing the battery, use care not to
touch any of the circuitry. Static from your
body transferred to these surfaces may damage
the transmitter.
To replace the battery in the remote keyless entry
transmitter, do the following:
1. Carefully pry off the cover by inserting a coin
(or similar object) in the slot between the covers
and twist.
2. Lift off the back cover.
3. Remove and replace the battery. Use one battery,
type CR2032, or a similar type. Put the new battery
in printed side down.
4. Put the back cover on. Make sure the cover is on
tight so water won't get in.
5. Check the transmitter operation. If the transmitter
does not work after battery replacement, it may need
to be resynchronized or matched to your vehicle.
See ªResynchronizationº following.

2-13
Resynchronization
Resynchronization may be necessary due to the security
method used by the remote keyless entry system.
The transmitter does not send the same signal twice to
the receiver. The receiver will not respond to a signal
that has been sent previously. This prevents anyone
from recording and playing back the signal from
the transmitter.
To resynchronize the transmitter with the receiver,
do the following:
1. Stand close to the vehicle.
2. Press and hold the LOCK and UNLOCK buttons
on the transmitter at the same time for about
eight seconds.
The door locks should cycle and the interior lamps
should flash to confirm resynchronization.
If this does not happen, you may need to replace the
battery in your transmitter or match the transmitter to
your vehicle. See ªMatching Transmitter(s) to Your
Vehicleº in the Index.
Hatch
CAUTION:
It can be dangerous to drive with the hatch open
because carbon monoxide (CO) gas can come into
your vehicle. You can't see or smell CO. It can
cause unconsciousness and even death.
If you must drive with the hatch open or if
electrical wiring or other cable connections
must pass through the seal between the body
and the hatch:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on vent. That will force outside air into
your vehicle. See ªComfort Controlsº in
the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.

2-14 Hatch Release
Your door key opens the hatch from the outside. If your
vehicle has the content theft
-deterrent/alarm system and
the system is armed, opening the hatch this way will
trigger the alarm. First, disarm the system or use the
remote keyless entry transmitter to open the hatch. See
ªContent Theft
-Deterrent/Alarm Systemº in the Index.
Remote Hatch Release (If Equipped)
Press the button located
under the exterior lamp
control on the driver's side
below the instrument panel
to unlock the hatch from
inside your vehicle.If you have an automatic transmission, the shift lever
must be in PARK (P) or NEUTRAL (N) to use the
remote hatch release. If you have a manual transmission
and the ignition is in RUN, you must set the parking
brake before you can use the remote hatch release.
This button only works when the ignition is in RUN,
ACCESSORY or when RAP is active. See ªRetained
Accessory Power (RAP)º in the Index.NOTICE:
If you put things in the hatchback area, be sure
they won't break the glass when you close it.
Never slam the hatch down. You could break the
glass or damage the defogger grid (if equipped).
On vehicles with the content theft-deterrent/alarm
system the remote hatch release button will not
work while the system is armed. See ªContent
Theft
-Deterrent/Alarm Systemº in the Index.

2-15
Trunk Release Handle (Convertible Only)
NOTICE:
The trunk release handle was not designed to be
used to tie down the trunk lid or as an anchor
point when securing items in the trunk. Improper
use of the trunk release handle could damage it.
There is a glow-in-the-dark trunk release handle located
on the inside wall of the trunk near the floor. The handle
will be on the passenger's side. This handle will glow
following exposure to light. Pull the release handle
down to open the trunk from the inside.
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition. If you take the key with you, and you have an
automatic transmission, it will be locked. And remember
to lock the doors.

2-16 Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
Even if you park in a lot where someone will be
watching your vehicle, it's still best to lock it up and
take your keys. But what if you have to leave your
ignition key?

If possible, park in a busy, well
-lit area.

Put your valuables in a storage area, like your trunk
or glove box.

Be sure to close and lock the storage area.

Close all windows.

Lock the glove box.

Lock all the doors except the driver's.

Then take the door key and remote keyless entry
transmitter with you.
Content Theft-Deterrent/Alarm
System (Option)
If your vehicle has this option, it has a theft-deterrent
alarm system. Once armed, the system will sound
the horn and flash the parking lamps if the vehicle is
broken into.
Arming the System
The alarm system can be armed to detect break-ins by
locking your vehicle with the remote keyless entry
transmitter or by locking the doors with the power door
lock switch.
Passive arming is also available if you would like the
system to arm all by itself after the doors have been
closed for a short time. When the system is armed, a red
light located on top of the instrument panel will flash
briefly once every two seconds. If you return to your
vehicle and the red light is flashing two brief flashes
every two seconds, the system is armed and the shock
sensor had triggered a two minute alarm. If the red light
is flashing three times every two seconds, the system is
armed and there was an intrusion that sounded the
alarm. Horn chirps and parking lamp flashes can be
customized to your preference. See ªFeature
Customizationº in the Index.

2-17
Turning Off the Alarm
If you started the alarm by pressing the panic button on
the remote keyless entry transmitter, you must either
push that button again or turn the ignition to RUN to
stop the alarm.
If the alarm is sounding due to the shock sensor or a
door or hatch opening, it can be turned off by either
turning the ignition to RUN with a proper key or by
pressing any button on the remote keyless entry
transmitter. If you use your remote keyless entry
transmitter to silence the alarm, additional things will
happen depending upon which button you press.

Pressing the panic button or the UNLOCK button
will turn the alarm off, unlock the driver's door and
disarm the system.

Pressing the LOCK button will turn the alarm off,
keep the doors locked and keep the system armed.

Pressing the REAR 2X button will turn the alarm off
and keep the system armed. A second push of the
button (within five seconds, pausing slightly between
presses) will unlock and disarm the hatch only.
If the alarm is sounding because an incorrect ignition
key was used, press any button on the remote keyless
entry transmitter to turn the alarm off.
The alarm will stop by itself after two minutes.
Shock Sensor
Coupe Convertible
The shock sensor is what triggers the alarm when it
detects a blow to your vehicle. It is located over the
wheelhouse near the spare tire in the hatch area, on the
passenger's side of the vehicle. There are two levels
of alarms via the shock sensor. Two horn blasts and
parking lamp flashes for non
-threatening blows to the
vehicle and a full two
-minute alarm for harder blows to
the vehicle. Its sensitivity can be adjusted if more or less
sensitivity is desired. If sensitivity is increased too
much, it may give false alarms caused by gusts of wind
or other natural events that may shake the vehicle.
