2-18
When your vehicle is new, there will be a label covering
the adjustment knob. Remove the label and adjust the
sensor as desired. Turn the knob clockwise to increase
sensitivity and counterclockwise to decrease sensitivity.
The shock sensor is ignored by the alarm system when
the following happens:

The ignition is on,

the hatch is open,

the alarm is disarmed,

when customized to be ignored, and

for five seconds after the horn sounds an alarm
or chirp.
The shock sensor is ignored after triggering three full
alarms until the system is rearmed.Remote Keyless Entry Transmitter Locking
If all the doors are closed, locking the vehicle with the
remote keyless entry transmitter will immediately arm
the system. The horn will chirp twice and the parking
lamps will flash, confirming that the system is armed.
If any door is open when the LOCK button is pressed,
the system goes into an armed wait mode, waiting for
the doors to close. Once they are closed, the system will
arm, the horn will chirp twice and the parking lamps
will flash. If the hatch is open or ajar at the time the
system is arming, the horn will only chirp once.
Power Door Lock Switch Locking
If any door is open when the power door lock switch is
pressed, the system goes into an armed wait mode,
waiting for the doors to close. Once they are closed, the
system will arm and the parking lamps will flash. If both
doors are closed when the power door lock switch is
pressed, the system assumes you are inside the vehicle,
so it will not arm. Locking the doors by using the
manual door locks will not arm the system.

2-19
Passive Arming
If the ignition was just turned off and a door was
opened, the system will arm six seconds after both doors
are closed, whether or not you lock them. In all other
cases, the system will wait 30 seconds after both doors
are closed before arming, allowing you time to get into
the vehicle and put the key in the ignition. The parking
lamps will flash when the system arms.
The vehicle is shipped from the factory with this feature
turned off. To turn this feature on, see ªFeature
Customizationº in the Index.
Disarming the System
There are two ways to disarm the system:

Press the UNLOCK button on the remote keyless
entry transmitter. If the horn chirps two or three
times when you unlock the vehicle, the alarm
sounded in your absence. Two chirps means that the
shock sensor was set off and three chirps means that
a door or the hatch was opened.

Turn the ignition key to RUN.
For more information on customizing the features
mentioned here, see ªFeature Customizationº in
the Index.

2-20 Feature Customization (If Equipped)
Your vehicle's content theft-deterrent/alarm system, locks and lighting systems can be programmed with several
different features. The features you can program depend upon the options that came with your vehicle. The following
chart shows the features that can be programmed. To determine which features your vehicle is equipped with, follow
the steps listed for entering the programming mode.

2-21
Entering Programming Mode
To program any feature, your vehicle must be in the
programming mode. Follow these steps:
1. Put your key in the ignition.
2. Turn the ignition to RUN to disarm the content
theft
-deterrent/alarm system.
3. Turn the ignition to OFF.
4. Remove the RADIO fuse. This fuse is in the main
fuse block, located on the left side of your
instrument panel. See ªFuses and Circuit Breakersº
in the Index.
5. Turn the ignition toward you to ACCESSORY.
6. Count the number of chimes you hear. You will
hear one or two chimes depending on the features
your vehicle is equipped with. Refer to the chart
shown previously.
You can now program your choices.
To exit the programming mode, follow the steps
listed under ªLeaving Programming Modeº later
in this section.Exit Lighting and Delayed Illumination
With Exit Lighting, your interior lamps will come on
for up to 25 seconds when the key is removed from
the ignition.
With Delayed Illumination, your interior lamps will
come on and stay on for up to 25 seconds when
entering your vehicle and up to five seconds when
leaving your vehicle.
Programmable Modes
Mode 1: Both Off
Mode 2: Delayed Illumination Only
Mode 3: Exit Lighting Only
Mode 4: Both On

2-22
Before your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Turn the courtesy lamps on by turning the instrument
panel brightness thumbwheel all the way up.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is set
for. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
3. Turn the courtesy lamps off to change the
current mode.
4. Turn the courtesy lamps from on to off until you hear
the number of chimes that corresponds to the mode
selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Last Door Closed Locking and Lockout Prevention
These features are designed to help prevent your keys
from being locked in your vehicle.
Programmable Modes
Mode 1: Both Off (Doors will lock/unlock when you
press the power door lock switch.)
Mode 2: Lockout Prevention Only (If you leave your
keys in the ignition and leave through the driver's door,
you won't be able to lock the doors with the power door
lock switch.)
Mode 3: Last Door Closed Locking Only (If the power
door lock switch is used to lock the vehicle while any
door is open, you will hear three chimes. The doors will
not lock until after all doors are closed.)
Mode 4: Both On (This combines Mode 2 and 3.)

2-23
Before your vehicle was shipped from the factory, it was
programmed in Mode 2. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Press the power door lock switch located on
the door.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is set
for. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
3. Press the power door lock switch again on the door
until you hear the number of chimes that corresponds
to the mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Remote Keyless Entry Verification
This feature provides feedback when the vehicle
receives a command from the remote keyless
entry transmitter.
Programmable Modes
Mode 1: All Off (The headlamps will not flash and the
horn will not sound to provide you feedback that a
lock/unlock command has been received by the remote
keyless entry transmitter.)
Mode 2: Horn and Lamps/Lamps (Your horn will
sound briefly and your parking lamps will flash when
you press LOCK on the remote keyless entry
transmitter. Only your parking lamps will flash when
you press UNLOCK.)
Mode 3: Horn and Lamps (Your horn will sound briefly
and your parking lamps will flash every time you push
LOCK or UNLOCK.)
Mode 4: Lamps (Your parking lamps will flash every
time you press LOCK or UNLOCK.)
Mode 5: Lamps/Horn and Lamps/Lamps (Your lamps
will flash upon the first press on LOCK, your lamps
will flash and your horn will sound upon the second
press on LOCK and your lamps will flash upon any
press on UNLOCK.)

2-24
Before your vehicle was shipped from the factory, it was
programmed in Mode 5. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Press the UNLOCK button on the remote keyless
entry transmitter.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is set
for. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
3. Press the UNLOCK button again on the remote
keyless entry transmitter until you hear the number
of chimes that corresponds to the mode selection
you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Theft-Deterrent Arming Verification
With this feature, you can program your vehicle to
give verification when the theft
-deterrent system has
been armed.
Programmable Modes
Mode 1: All Off (No horn chirps or parking lamp flash.)
Mode 2: Horn and Lamps (Your parking lamps will
flash and your horn will chirp twice to verify the system
is armed using any arming method.)
Mode 3: Horn and Lamps/Lamps (If you use the remote
keyless entry transmitter to arm the system, your
parking lamps will flash and your horn will chirp twice
to verify that the system is armed. If it only chirps once,
the hatch is open or unlatched. If you use either the
power door lock switch or passive arming, only your
parking lamps will flash for verification.)
Mode 4: Lamps (When your vehicle arms, only your
parking lamps will flash for verification.)

2-25
Before your vehicle was shipped from the factory, it was
programmed in Mode 3. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Press the LOCK button on the remote keyless
entry transmitter.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is set
for. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
3. Press the LOCK button again on the remote
keyless entry transmitter until you hear the number
of chimes that corresponds to the mode selection
you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Theft-Deterrent Arming Method
With this feature, you can program your vehicle to arm
the content theft
-deterrent/alarm system using the
remote keyless entry transmitter, the power door lock
switch or by passive arming.
Programmable Modes
Mode 1: Alarm System Off (The system will not arm.)
Mode 2: Remote Keyless Entry Transmitter Lock
(When you lock your doors using the LOCK button
on the remote keyless entry transmitter, the system will
arm itself.)
Mode 3: Remote Keyless Entry Transmitter/Power
Door Lock Switch (If you use either the LOCK button
on the remote keyless entry transmitter or the power
door lock switch to lock the doors, the system will
arm itself.)
Mode 4: Passive Arming and Remote Keyless
Entry Transmitter/Power Door Lock Switch Arming
(The system will arm itself after all doors are closed,
plus arming per Mode 3.)

2-26
Before your vehicle was shipped from the factory, it was
programmed in Mode 3. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Press the unlock switch on the door.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is set
for. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
3. Press the unlock switch again on the door until you
hear the number of chimes that corresponds to the
mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.Driver's Door Alarm Delay and Shock
Sensor Enable
These features will allow you to change when the alarm
system will sound and to turn the shock sensor on or off.
Programmable Modes
Mode 1: Zero Delay and Shock Sensor Disabled
(The alarm will sound immediately if the driver's door
is opened with your key and the shock sensor will not
be available to measure sharp blows to your vehicle.)
Mode 2: Eight
-Second Delay and Shock Sensor
Disabled (The alarm will sound eight seconds after the
driver's door is opened with your key and the shock
sensor will not be available to measure sharp blows to
your vehicle.)
Mode 3: Zero Delay and Shock Sensor Enabled
(The alarm will sound immediately after the driver's
door is opened with your key and the shock sensor will
be available to measure sharp blows to your vehicle.)
Mode 4: Eight
-Second Delay and Shock Sensor
Enabled (The alarm will sound eight seconds after the
driver's door is opened with your key and the shock
sensor will be available to measure sharp blows to
your vehicle.)

2-27
Before your vehicle was shipped from the factory, it was
programmed in Mode 4. The mode to which the vehicle
has been programmed may have been changed since it
left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Turn the parking lamps on and off.
2. Count the number of chimes you hear. The number
of chimes tells you which mode your vehicle is set
for. (If you do not wish to change the current mode,
you can either exit the programming mode by
following the instructions later in this section or
program the next feature available on your vehicle.)
3. Turn the parking lamps on and off again until you
hear the number of chimes that corresponds to the
mode selection you want.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
Exiting Programming Mode
When programming is complete, turn the ignition to
OFF and reinstall the RADIO fuse.PASS-Key
II
Your vehicle is equipped
with the PASS
-Key II
(Personalized Automotive
Security System)
theft
-deterrent system.
PASS
-Key II is a passive
theft
-deterrent system.
It works when you insert
or remove the key from
the ignition.
PASS
-Key II uses a resistor pellet in the ignition key
that matches a decoder in your vehicle.
When the PASS
-Key II system senses that someone is
using the wrong key, it shuts down the vehicle's starter
and fuel systems. For about three minutes, the starter
won't work and fuel won't go to the engine. If someone
tries to start your vehicle again or uses another key
during this time, the vehicle will not start. This
discourages someone from randomly trying different
keys with different resistor pellets in an attempt to
make a match.
