CHEVROLET CITY EXPRESS 2018 Owner's Guide

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
30 Keys, Doors, and Windows
Caution (Continued)
Always look before fully opening
the back doors to avoid an
accident with oncoming traffic or
pedestrians.
When closing the back doors, be
sure to close the left-side door
before closing the right-side door.
The back door wire mesh is not
designed as either an ejection
mitigation feature or an anti-theft
feature. Do not hang items on the
back door wire mesh. Any damage
of failure caused by misuse would
not be covered by the vehicle
warranty.
Vehicle Security
This vehicle has theft-deterrent
features; however, they do not make
the vehicle impossible to steal.
Vehicle Alarm System
This vehicle may have a security
system.
The security light shows the status
of the system.
Arming the Alarm System
1. Close the windows. Thesystem will arm with open
windows.
Turn off the vehicle and
remove the key.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
Keys, Doors, and Windows 31
2. Close all the doors and lockthe vehicle in one of
three ways:
.Use the key.
. With the door open, press
the inside lock button and
close the door. Make sure
the key is not inside the
vehicle.
. Use the RKE transmitter.
See Remote Keyless Entry
(RKE) System Operation
0 23.
If the lock button is pressed
when the doors are locked,
the lights flash twice and
the horn may beep once to
indicate the doors are
locked.
3. Confirm that the security light comes on. The security light
stays on for about 30 seconds.
The vehicle security system is
now pre-armed. After 30 seconds the alarm system
will arm, and the security light will
begin to slowly flash indicating the
alarm system is operating.
The system will not arm if any of the
following occur during the
30-second pre-arm time period:
.
The door is unlocked with the
key, the power door lock switch,
or the RKE transmitter.
. Any door is open.
. The ignition key is turned to
ACC or ON.
. The key is turned slowly when
locking the door.
If the key is turned beyond the
vertical position toward the unlock
position to remove the key, the
system may be disarmed when the
key is removed. If the security light
fails to glow for a period of time,
unlock the door once and lock it
again. When the driver and/or passengers
are in the vehicle, the system will
still arm when all doors are closed
and locked and the ignition key is in
the OFF position.
Vehicle Security System
Activation
The security system will activate as
follows:
.
The headlamps blink and the
horn sounds intermittently. The
alarm automatically turns off
after a period of time. The alarm
will sound if the vehicle is
tampered with again.
. The alarm will sound if opening
a door without using the key or
RKE transmitter, even if the door
is unlocked by using the inside
lock knob or the power door lock
switch.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
32 Keys, Doors, and Windows
Disarming the Alarm System
Do one of the following to disarm
the alarm system or turn off the
alarm if it has been activated:
.Press
Kon the RKE transmitter.
. Unlock the driver door using
the key.
Immobilizer
See Radio Frequency Statement
0 273.
Immobilizer Operation
This vehicle has an alarm system.
The system does not have to be
manually armed or disarmed.
This security light blinks whenever
the ignition is turned off or to ACC/
ACCESSORY. The system is automatically
disarmed when the vehicle is
started. The key uses a transponder
that matches an immobilizer control
unit in the vehicle and automatically
disarms the system. Only the
correct key starts the vehicle. The
vehicle may not start if the key is
damaged.If the immobilizer system is
malfunctioning, the security light will
remain on while the ignition is on.
If the engine will not start using a
registered key:
1. Leave the ignition on for about five seconds.
2. Turn the ignition off, and wait for about 10 seconds.
3. Repeat Steps 1 and 2.
4. Restart the engine.
If the engine will not start, place the
key on a separate key ring to avoid
interference from other devices.
If the light still remains on and/or the
engine will not start, see a dealer for
service. Bring all registered keys to
the dealer.
Do not leave the key or device that
disarms or deactivates the
theft-deterrent system in the vehicle.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
Keys, Doors, and Windows 33
Exterior Mirrors
Convex Mirrors
{Warning
A convex mirror can make things,
like other vehicles, look farther
away than they really are. If you
cut too sharply into the right lane,
you could hit a vehicle on the
right. Check the inside mirror or
glance over your shoulder before
changing lanes.
The passenger side mirror is convex
shaped. A convex mirror's surface is
curved so more can be seen from
the driver seat.
Manual Mirrors
Adjust the mirrors by pressing up,
down, left, or right on the sides of
the mirror.
Power Mirrors
If equipped with power outside
mirrors, adjust by selecting the left
or right mirror (1) and then use the
control pad (2) to move each mirror
to the desired position.
Return the switch (1) to the center
position to prevent accidental mirror
movement.
The power mirrors will operate only
when the ignition is in the ACC or
ON position.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
34 Keys, Doors, and Windows
Folding Mirrors
Manual Folding Mirrors
The mirrors can be folded inward
toward the vehicle to prevent
damage when going through an
automatic car wash. Push the mirror
outward to return it to the original
position.
Heated Mirrors
For vehicles with heated mirrors:
1:Press to heat the mirrors.
An indicator light in the button lights
when the outside heated mirrors are
activated.
See “Rear Window Defogger” under
Climate Control Systems 0129.
Interior Mirrors
Interior Rearview Mirrors
Adjust the rearview mirror for a clear
view of the area behind the vehicle.
Do not spray glass cleaner directly
on the mirror. Use a soft towel
dampened with water.
Manual Rearview Mirror
If equipped, push the tab forward for
daytime use and pull it rearward for
nighttime use to avoid glare of the
headlamps from behind.
Windows
{Warning
Never leave a child, a helpless
adult, or a pet alone in a vehicle,
especially with the windows
closed in warm or hot weather.
They can be overcome by the
extreme heat and suffer
permanent injuries or even death
from heat stroke.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
Keys, Doors, and Windows 35
Power Windows
{Warning
Leaving children in a vehicle with
the Remote Keyless Entry (RKE)
transmitter is dangerous for many
reasons; children or others could
be badly injured or even killed.
They could operate the power
windows or other controls or even
make the vehicle move. They
could be seriously injured or killed
if caught in the path of a closing
window. Do not leave the RKE
transmitter in a vehicle with
children.
The power window controls (1) are
on the front doors. The driver door
also has a control (2) to operate the
front passenger window.
Press the switch to the first detent to
lower the window. Pull to the first
detent to raise the window. Release
to stop at the desired position.
The switches work when the ignition
is in ON or for a period of time after
the ignition is placed in the OFF
position. If the driver or passenger
door is opened the power to the
windows is canceled.
Express-Up/Down
If equipped, the front windows have
an express feature that allows the
window to be raised or lowered
without holding the switch. Press or
pull the switch fully and release it to
activate the express feature. This
mode can be canceled by briefly
pressing or pulling the switch.
Auto-Reverse Function
If any object is in the path of the
window when express operation is
active, the window stops at the
obstacle and auto-reverses to a
preset factory position. Weather
conditions such as severe icing also
cause the window to auto-reverse.
The window returns to normal
operation once the obstacle or
condition is removed.
If the battery on the vehicle has
been recharged, disconnected, or is
not working, the auto-reverse
function may not operate properly.
If this occurs, see“Programming the
Power Windows” later in this
section.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
36 Keys, Doors, and Windows
{Warning
There are some small distances
immediately before the closed
position which cannot be
detected. Make sure that all
passengers have their hands,
etc., inside the vehicle before
closing the window.
Window Lockout
When the window lockout button (1)
is pressed, only the driver side
window can be opened or closed.
Press again to cancel the window
lockout function.
Programming the Power
Windows
If the power window automatic
function (closing only) does not
operate properly, reprogram the
windows:1. With the ignition in ON or ACC/ ACCESSORY, close all doors.
2. Press and hold the power window switch until the window
is fully open.
3. Pull the power window switch up until the window is fully
closed.
4. Continue holding the switch up for approximately two seconds
after the window is completely
closed.
The window is now reprogrammed.
Repeat the process for the other
windows. If the power window automatic
function does not operate properly
after performing this procedure, see
your dealer.
Sun Visors
Pull the sun visor down to block
glare. Detach the sun visor from the
center mount to pivot to the side
window.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
Seats and Restraints 37
Seats and
Restraints
Head Restraints
Head Restraints . . . . . . . . . . . . . . . 37
Front Seats
Seat Adjustment . . . . . . . . . . . . . . . 39
Lumbar Adjustment . . . . . . . . . . . . 40
Reclining Seatbacks . . . . . . . . . . . 40
Front Seat Armrest . . . . . . . . . . . . 41
Folding Seatback . . . . . . . . . . . . . . 41
Seat Belts
Seat Belts . . . . . . . . . . . . . . . . . . . . . 43
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . 44
Lap-Shoulder Belt . . . . . . . . . . . . . 45
Seat Belt Use During Pregnancy . . . . . . . . . . . . . . . . . . . . 47
Seat Belt Extender . . . . . . . . . . . . . 48
Safety System Check . . . . . . . . . . 48
Seat Belt Care . . . . . . . . . . . . . . . . . 48
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . 49
Airbag System
Airbag System . . . . . . . . . . . . . . . . . 49
Where Are the Airbags? . . . . . . . 51 When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . 52
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . 54
How Does an Airbag
Restrain? . . . . . . . . . . . . . . . . . . . . . 54
What Will You See after an Airbag Inflates? . . . . . . . . . . . . . . 55
Passenger Sensing System . . . 56
Servicing the Airbag-Equipped Vehicle . . . . . . . . . . . . . . . . . . . . . . . 62
Adding Equipment to the Airbag-Equipped Vehicle . . . . . 63
Airbag System Check . . . . . . . . . . 63
Replacing Airbag System Parts after a Crash . . . . . . . . . . . . . . . . . 64
Child Restraints
Older Children . . . . . . . . . . . . . . . . . 64
Infants and Young Children . . . . 65
Child Restraint Systems . . . . . . . 68
Where to Put the Restraint . . . . . 70
Lower Anchors and Tethers forChildren (LATCH System) . . . . 71
Replacing LATCH System Parts After a Crash . . . . . . . . . . . . . . . . . 75
Securing Child Restraints . . . . . . 75
Head Restraints
The vehicle’s front seats have
adjustable head restraints in the
outboard seating positions.
{Warning
With head restraints that are not
installed and adjusted properly,
there is a greater chance that
occupants will suffer a neck/
spinal injury in a crash. Do not
drive until the head restraints for
all occupants are installed and
adjusted properly.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
38 Seats and Restraints
Adjustable head restraints
Adjust the head restraint/headrest
so the center is level with the center
of your ears. If your ear position is
still higher than the recommended
alignment, place the head restraint
at the highest position.The height of the head restraint can
be adjusted. Pull the head restraint
up to raise it. Try to move the head
restraint to make sure that it is
locked in place.
To lower the head restraint, press
the button located on the top of the
seatback and push the restraint
down. Try to move the head
restraint after the button is released
to make sure that it is locked in
place.Head Restraint Removal and
Reinstallation
{Warning
If the head restraints are removed
for any reason, they should be
securely stored to prevent them
from causing injury to passengers
or damage to the vehicle in case
of sudden braking or an accident.
To remove the head restraint: 1. Pull the head restraint up to the highest position.
2. Press and hold the lock knob.
3. Remove the head restraint from the seat.
4. Store the head restraint properly in a secure place so it
is not loose in the vehicle.
5. Reinstall and properly adjust the head restraint before an
occupant uses the seating
position.

Chevrolet City Express Owner Manual (GMNA-Localizing-U.S./Canada-
11683523) - 2018 - CRC - 7/10/17
Seats and Restraints 39
To reinstall the head restraint.1. Align the head restraint stalks with the holes in the seat.
Make sure that the head
restraint is facing the correct
direction. The stalk with the
notch (notches) must be
installed in the hole with the
lock knobs.
2. Push and hold the lock knob and push the head
restraint down.
3. Properly adjust the head restraint before an occupant
uses the seating position.
{Warning
With head restraints that are not
installed and adjusted properly,
there is a greater chance that
occupants will suffer a neck/
spinal injury in a crash. Do not
drive until the head restraints for
all occupants are installed and
adjusted properly.
Front Seats
Seat Adjustment
{Warning
You can lose control of the
vehicle if you try to adjust a driver
seat while the vehicle is moving.
Adjust the driver seat only when
the vehicle is not moving.
To adjust the seat:
1. Lift the bar under the front edge of the seat cushion to
unlock the seat.
2. Slide the seat to the desired position and release the bar.
3. Try to move the seat back and forth to be sure the seat is
locked in place.
To lift the seat, pull up or push down
the lever to adjust the seat.
