CHEVROLET HHR 2008 1.G Owners Manual

{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack,
you could be badly injured or killed. Never get
under a vehicle when it is supported only by
a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.4. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground so there is enough room for the tire.
5-97

5. Remove all the wheel
nuts and take off the
at tire.
6. Install the tire.
{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
places where the wheel attaches to the vehicle.
CAUTION: (Continued)
CAUTION: (Continued)
In an emergency, you can use a cloth or a paper
towel to do this; but be sure to use a scraper or
wire brush later, if needed, to get all the rust or
dirt off. SeeChanging a Flat Tire on page 5-86.
7. Remove any rust or dirt
from the wheel bolts,
mounting surfaces,
and wheel.
5-98

8. Place the tire on the wheel mounting surface.
9. Reinstall the wheel nuts with the rounded end of
the nuts toward the wheel. Tighten each by hand
until the wheel is held against the hub.
{CAUTION:
Never use oil or grease on studs or nuts.
Because the nuts might come loose.
The vehicle’s wheel could fall off, causing
a crash.
10. Lower the vehicle by turning the jack handle
counterclockwise. Lower the jack completely.
5-99

{CAUTION:
Incorrect or improperly tightened wheel nuts
can cause the wheel to come loose and
even come off. This could lead to a crash.
If you have to replace them, be sure to get
new original equipment wheel nuts. Stop
somewhere as soon as you can and have the
nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-125for wheel nut
torque specication.Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-125for the wheel nut
torque specication.
11. Tighten the wheel nuts
rmly in a crisscross
sequence, as shown.
5-100

Removing the Flat Tire and
Installing the Spare Tire
(All Models Except SS)
1. Do a safety check before proceeding. SeeChanging
a Flat Tire on page 5-86for more information.
2. Using the wheel wrench, loosen all the wheel nuts.
Do not remove them yet.3. Position the jack and raise the jack lift head to t
over the car ange under the down arrow markings
on the rocker panel.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack, you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
5-101

{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
4. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground so there is enough room for the compact
spare tire to t underneath the wheel well.
5-102

5. Remove all the wheel
nuts and take off the
at tire.
{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
places where the wheel attaches to the vehicle.
CAUTION: (Continued)
CAUTION: (Continued)
In an emergency, you can use a cloth or a paper
towel to do this; but be sure to use a scraper or
wire brush later, if needed, to get all the rust or
dirt off. SeeChanging a Flat Tire on page 5-86.
6. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
5-103

7. Place the compact spare tire on the wheel-mounting
surface.
{CAUTION:
Never use oil or grease on studs or nuts.
Because the nuts might come loose.
The vehicle’s wheel could fall off, causing
a crash.
8. Reinstall the wheel nuts with the rounded end of
the nuts toward the wheel. Tighten each nut by
hand until the wheel is held against the hub.
9. Lower the vehicle by turning the jack handle
counterclockwise. Lower the jack completely.
5-104

{CAUTION:
Incorrect or improperly tightened wheel nuts
can cause the wheel to come loose and
even come off. This could lead to a crash.
If you have to replace them, be sure to get
new original equipment wheel nuts. Stop
somewhere as soon as you can and have the
nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-125for wheel nut
torque specication.Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-125for the wheel nut
torque specication.
10. Tighten the wheel nuts
rmly in a crisscross
sequence as shown.
5-105

Storing a Flat or Spare Tire
and Tools
{CAUTION:
Storing a jack, a tire, or other equipment in the
passenger compartment of the vehicle could
cause injury. In a sudden stop or collision,
loose equipment could strike someone.
Store all these in the proper place.
Storing the Flat Tire and Tools
To store the at tire:
1. Open the liftgate. SeeLiftgate on page 2-12for
more information.
2. Put back all tools as they were stored in the rear
storage compartment and put the compartment cover
back on. For more information, see “Storing the
Compact Spare Tire and Tools” next in this section.
3. Install the cargo cover. For more information,
seeRear Compartment Storage Panel/Cover on
page 2-48.Aluminum Wheel
5-106
