CHEVROLET HHR 2008 1.G Owners Manual

When you have a at tire, use the following example as
a guide to assist you in the placement of wheel blocks.
The following information will tell you how to use the
jack and change a tire.Removing the Spare Tire and Tools
If your vehicle is equipped with a spare tire, the jack,
wheel wrench, and spare tire are stowed in the rear of
the vehicle, underneath the oor of the cargo area.
To remove the spare tire and tools:
1. Open the liftgate. SeeLiftgate on page 2-12for
more information.
2. Remove the cargo cover.
5-87

3. Turn the retainer counterclockwise to remove the
tire cover.
4. Remove the tire cover.
5. Remove the spare tire by placing your hands at the
four and eight o’clock positions. Gently pull it up
and out of the trunk. SeeCompact Spare Tire
on page 5-109.
6. Remove the wing nut that holds the jack. Then
remove the jack, wheel wrench, and at tire strap.The tools needed are the jack (A) and wheel wrench (B).
5-88

Turn the plastic wheel nut counterclockwise to loosen
the wheel wrench from the jack.Press the button and then pull on the end of the wheel
wrench to extend the handle.
5-89

Removing the Flat Tire and
Installing the Spare Tire (SS Model)
The SS Model has larger performance brakes than
the Base Model. The compact spare tire will not clear
the front brakes.
Do not use the compact spare tire in the event of a front
at tire.
You must use the rear tire to replace the front at tire.To change the rear road tire:
Rear Tire Changing Procedure
1. Do a safety check before proceeding. SeeChanging
a Flat Tire on page 5-86for more information.
2. Using the wheel wrench, loosen all the wheel nuts
on the rear tire. Do not remove them yet.
5-90

3. Position the jack on the rear position and raise the
jack lift head to t over the car ange under the
down arrow markings on the rocker panel.
{CAUTION:
Getting under a vehicle when it is jacked up
is dangerous. If the vehicle slips off the jack,
you could be badly injured or killed. Never get
under a vehicle when it is supported only by
a jack.
5-91

{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
4. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground so there is enough room for the compact
spare tire to t underneath the wheel well.
5-92

5. Remove all the
wheel nuts and
take off the tire.
6. Install the compact spare tire.
{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
places where the wheel attaches to the vehicle.
CAUTION: (Continued)
CAUTION: (Continued)
In an emergency, you can use a cloth or a paper
towel to do this; but be sure to use a scraper or
wire brush later, if needed, to get all the rust or
dirt off. SeeChanging a Flat Tire on page 5-86.
7. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
5-93

8. Place the compact spare tire on the wheel-mounting
surface.
{CAUTION:
Never use oil or grease on studs or nuts.
Because the nuts might come loose.
The vehicle’s wheel could fall off, causing
a crash.
9. Reinstall the wheel nuts with the rounded end of
the nuts toward the wheel. Tighten each nut by
hand until the wheel is held against the hub.
10. Lower the vehicle by turning the jack handle
counterclockwise. Lower the jack completely.
5-94

{CAUTION:
Incorrect or improperly tightened wheel nuts
can cause the wheel to come loose and
even come off. This could lead to a crash.
If you have to replace them, be sure to get
new original equipment wheel nuts. Stop
somewhere as soon as you can and have the
nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-125for wheel nut
torque specication.Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-125for the wheel nut
torque specication.
11. Tighten the wheel nuts
rmly in a crisscross
sequence as shown.
5-95

To change the front at tire:
Front Tire Changing Procedure
1. Perform a rear tire change by removing the rear tire
and installing the compact spare tire in the rear
wheel location. The rear road tire will be used
to replace the front at tire. See Rear Tire Changing
Procedure in this section.
2. Using the wheel wrench, loosen all the wheel nuts
on the front at tire. Do not remove them yet.3. Position the jack on the front position and raise the
jack lift head to t over the car ange under the
down arrow markings on the rocker panel.
5-96
