Rear Heating System
If you have a crew cab
and your vehicle has a
rear heater, the
thumbwheel for this
feature is located on
the headliner.
To increase and decrease the flow of heated air to
the rear floor vents, turn the thumbwheel to the
desired fan speed. To turn the fan off, turn
the thumbwheel all the way down.
Warning Lights, Gages, and
Indicators
This part describes the warning lights and gages
that may be on your vehicle. The pictures will
help you locate them.Warning lights and gages can signal that
something is wrong before it becomes serious
enough to cause an expensive repair or
replacement. Paying attention to your warning
lights and gages could also save you or others
from injury.
Warning lights come on when there may be or
is a problem with one of your vehicle’s functions.
As you will see in the details on the next few
pages, some warning lights come on briefly when
you start the engine just to let you know they
are working. If you are familiar with this section,
you should not be alarmed when this happens.
Gages can indicate when there may be or is a
problem with one of your vehicle’s functions. Often
gages and warning lights work together to let you
know when there is a problem with your vehicle.
When one of the warning lights comes on and
stays on when you are driving, or when one of the
gages shows there may be a problem, check
the section that tells you what to do about
it. Waiting to do repairs can be costly and even
dangerous.
161

Instrument Panel Cluster
Your instrument panel cluster is designed to let you know at a glance how your vehicle is running. You
will know how fast you are going, about how much fuel is left and many other things you will need to drive
safely and economically.
United States Isuzu 6H Diesel Engine shown, Canada, 6.6L Diesel and Gasoline Engine similar
162

Speedometer and Odometer
Your speedometer lets you see your speed
in both miles per hour (mph) and kilometers per
hour (km/h).
Your odometer shows how far your vehicle
has been driven, in either miles (used in the
United States) or kilometers (used in Canada).
Trip Odometer
The trip odometer can tell you how far your
vehicle has been driven since you last set the trip
odometer to zero.
While the engine is running, press the reset
button, located to the right of the trip odometer, to
toggle between the trip odometer and the
regular odometer. Holding the reset button for
two seconds while the engine is running and the
trip odometer is displayed, will reset it.
To display the odometer reading with the ignition
off, press the reset button.
The hourmeter gage is accessed through the trip
odometer, for more information seeHourmeter
Gage on page 183.
Tachometer
This gage shows the safe operating range for the
engine speed in revolutions per minute (rpm).
7.2L Caterpillar®Diesel
Engine and Isuzu 6H
Diesel EnginesGasoline and
6.6L DURAMAX®
Diesel Engines
163

Engine Speed Limiter
All engines have electronic engine speed limiting.
The engine limited speeds range between
2,900 and 4,400 rpm depending on engine option
content.
Engine Road Speed Governor
This system controls maximum vehicle speed
automatically and reduces engine power
until vehicle speed gets down to maximum
governed speed.
The default setting for C4500 and C5500 models
up to 19,500 lbs GVWR is 80 to 85 mph
(128 to 136 km/h). Most other models have a
default setting of 75 mph (120 km/h), although
some tire sizes and tread patterns may limit
maximum speed to 55 to 65 mph (86 to 105 km/h).
You may have a label on the headliner of your
vehicle with more information on your engine
road speed governor. See your GM dealer
for assistance with programming your engine
limited speed.
Safety Belt Reminder Light
When the key is turned to RUN or START, a light
will come on for several seconds to remind
people to fasten their safety belts.
The safety belt light will
also come on and stay
on for several seconds.
Safety Belt Reminder Tone
If your vehicle has this feature, when you turn
your key to RUN or START, a tone will sound for
several seconds to remind people to fasten
their safety belts.
164

Airbag Readiness Light
If your vehicle has airbags, there is an airbag
readiness light on the instrument panel, which
shows the airbag symbol. The system checks the
airbag’s electrical system for malfunctions. The
light tells you if there is an electrical problem. The
system check includes the airbag sensors, the
airbag modules, the wiring, the passenger airbag
suppression circuit and the crash sensing and
diagnostic module. For more information on
the airbag system, seeAirbag System on page 68.
This light will come on
when you start your
vehicle, and it will flash
for a few seconds.
Then the light should go
out. This means the
system is ready.
If the airbag readiness light stays on after you
start the vehicle or comes on when you are driving,
your airbag system may not work properly.
Have your vehicle serviced right away.The airbag readiness light should flash for a few
seconds when you turn the ignition key to RUN or
START. If the light doesn’t come on then, have
it fixed so it will be ready to warn you if there is a
problem.
{CAUTION:
If the airbag readiness light stays on after
you start your vehicle, it means the airbag
system may not be working properly. The
airbags in your vehicle may not inate in
a crash, or they could even inate without
a crash. To help avoid injury to yourself
or others, have your vehicle serviced right
away if the airbag readiness light stays on
after you start your vehicle.
165

Airbag Off Light
If your vehicle is equipped with an airbag off
switch, when you turn the right front passenger’s
airbag off, this light will come on and stay on
to remind you that the airbag has been turned off.
This light will go off when you turn the airbag
on. SeeAirbag Off Switch on page 76for more on
this, including important safety information.{CAUTION:
If the right front passenger’s airbag is
turned off for a person who is not in a risk
group identied by the national
government, that person will not have the
extra protection of an airbag. In a crash,
the airbag will not be able to inate and
help protect the person sitting there. Do
not turn off the passenger’s airbag unless
the person sitting there is in a risk group.
SeeAirbag Off Switch on page 76for
more on this, including important safety
information.
United StatesCanada
166

{CAUTION:
If the airbag readiness light ever comes
on when you have turned off the airbag, it
means that something may be wrong with
the airbag system. The right front
passenger’s airbag could inate even
though the switch is off. If this ever
happens, do not let anyone whom the
national government has identied as a
member of a passenger airbag risk group
sit in the right front passenger’s position
(for example, do not secure a rear-facing
child restraint in the right front
passenger’s seat) until you have your
vehicle serviced. SeeAirbag Off Switch on
page 76andAirbag Readiness Light on
page 165for more on this, including
important safety information.
Charging System Light
The charging system
light may be located in
the instrument panel
cluster, or with the
auxiliary warning lights
in the center of the
instrument panel.
It should come on briefly when you turn on the
ignition, before the engine is running, as a check to
show that it is working.
If it stays on, or comes on while you are driving,
have your vehicle checked right away. You
could have a loose generator drive belt or some
other problem.
Driving while this light is on will drain your battery.
If you must drive a short distance with the light
on, turn off your radio and other accessories.
Sustained driving with a generator failure could
result in a lack of back-up braking if the engine
quits or the power steering pump should fail.
167

Voltmeter Gage
When your engine is
running, the voltmeter
gage shows the
charging system
voltage.
Readings in either warning zone indicate a
possible problem in the electrical system.
Readings in the low warning zone may occur
when a large number of electrical accessories are
operating in the vehicle and the engine is left at
an idle for an extended period. This condition
is normal since the charging system may not be
able to provide full power at engine idle. As engine
speeds are increased, this condition should
correct itself because higher engine speeds allow
the charging system to create maximum power.You can only drive a short time on the battery.
Be sure to shut off the radio, the fan or any
unnecessary accessories and have the system
serviced.
Service Transmission Warning Light
If your vehicle has an Allison®automatic
transmission, certain transmission malfunctions
will turn this light on.
This light is located with
the auxiliary warning
lights in the center of the
instrument panel.
If this light comes on while you are driving, do not
use the transmission shift control or you may
lose forward gears. The computer for the
transmission senses a problem and chooses a
gear to stay in so that you can drive the vehicle in
that gear. You may not be able to drive as fast
or back up when this light is on.
168

Notice:If you continue driving your vehicle
after the transmission warning light comes on,
you could damage the transmission. While
this light is on, the transmission cannot
operate in all gears. If you attempt to shift
gears, the vehicle may not continue to move.
Do not attempt to shift gears while the
transmission warning light is on. Instead, drive
directly to an authorized dealer for service. If
you cannot drive to a dealer immediately, have
the vehicle towed.
Range Inhibit Warning Indicator
If your vehicle has an Allison 1000/2200/2300/
2500 series automatic transmission, a lighted bar
under the current gear selected will flash.
If your vehicle has an Allison 3000/3500
series automatic transmission, the current gear
selected on the pushbutton display will flash.
The flashing bar or gear selection indicates that
transmission range shifts may not occur.
For detailed information on shift inhibit limitations,
see the Allison Automatic Transmission
Operator’s Manual in your vehicle for further
information.
Brake System Warning Light
Your vehicle has either hydraulic or air brakes.
Each system has different warning lights.
Hydraulic Brake System
Warning Lights
Vehicles with hydraulic brake systems
have two brake system warning lights on the
instrument panel.
If the brake system
warning light comes on,
it means that the
fluid level in the master
cylinder reservoir is
low or there is another
problem with your
hydraulic brakes.
When it comes on, you will also hear a
warning tone.
169

The brake system warning light may come on, and
the warning tone may sound, when you are
turning and braking at the same time. This is
normal. See “Hydraulic Brake Systems” under
Braking on page 210.
This light is located
above the climate
controls in the center of
the instrument panel.
If the service brakes soon warning light comes on,
it means there may be something wrong in the
brake system.
When this light comes on, you will also hear a
warning tone. Have the system repaired
immediately.Both of these lights should come on briefly every
time you start your engine. If they do not come
on then, have them fixed so they will be ready to
warn you if there is a problem. If one or both
of these warning lights stay on after you start the
engine, there could be a brake problem. Have
your brake system inspected right away.
If one or both of these lights come on while you
are driving, pull off the road and stop carefully. You
may notice that the pedal is harder to push, or
the pedal may go closer to the floor. It may take
longer to stop. If this light is still on, have the
vehicle towed for service. SeeTowing Your
Vehicle on page 241. See “Hydraulic Brake
Systems” underBraking on page 210for further
information.
170
