3-11
Finding RDS Stations
To find an RDS station perform the following steps:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST knob to display the program type list.
2. Turn the knob either clockwise or counterclockwise
to select a program type. The list is alphabetical. If
you select ANY TYPE your radio will seek to the
first PTY available.
3. Push the SEEK TYPE button to activate search.
DISP (Display): Press this knob to change what appears
on the display while using RDS. Pressing this knob will
also display an RDS station frequency or program type
when the radio is on. The display options are station
name, station frequency, PTY and the name of the
program (if available). Pressing and holding this knob
will activate the RDS default display.
Finding a PTY Preset Stations
P
-TYPE LIST (Program Type): Turn this knob
clockwise or counterclockwise to select the Program
Type (PTY) you want to listen to. TYPE and a PTY
will appear on the display.Press the SEEK TYPE button and the radio will seek to
the first RDS broadcaster of the selected program type.
If the radio cannot find the desired program type, NONE
will appear on the display and the radio will return to the
last station you were listening to.
BAND (Alternate Frequency): Alternate frequency
allows the radio to switch to a stronger station with
the same program type. Press and hold BAND for
two seconds to turn alternate frequency on. AF ON
will appear on the display. The radio may switch to
stronger stations. Press and hold BAND again for two
seconds to turn alternate frequency off. AF OFF will
appear on the display. The radio will not switch to other
stations. When you turn the ignition off and then on
again, the alternate frequency feature will automatically
be turned on.
SEEK TYPE: Press this button to go to a station with
the last selected PTY; TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press SEEK TYPE a second time to seek. If a station
with the selected PTY is not found, the radio will return
to the original station and display NONE.

3-12
RDS Messages
ALERT!: Alert warns of national or local emergencies.
You will not be able to turn off alert announcements.
ALERT! appears on the display when an alert
announcement plays. When an alert announcement
comes on the current radio station, you will hear it,
even if the volume is muted or a cassette tape is
playing. If the cassette tape player is playing, play
will stop for the announcement and resume when
the announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.
INFO (Information): If the current station has a
message, the information symbol will appear on the
display. These text messages are from the RDS
broadcaster to the listening public and may be general
information such as artist and song title, call in phone
numbers, etc. Press this button to see the message. If the
whole message does not appear on the display, parts of
the message will appear every three seconds until the
message is completed. To scroll through the message at
your own speed, press the INFO button again for lessthan one second. A new group of words will appear on
the display. Once the complete message has been
displayed, the information symbol will disappear from
the display until another new message is received. The
old message can be displayed by pressing the INFO
button until a new message is received or a different
station is tuned to. When a message is not available
from an FM station, NO INFO will be displayed.
TRAF (Traffic): Press this button to receive traffic
announcements. If the current station does not broadcast
traffic announcements, the radio will seek to a station
that does. The traffic symbol will flash on the display.
When the radio finds a station that broadcasts traffic
announcements, it will stop. If no station is found, NO
TRAF will appear on the display.
Your radio can be programmed to interrupt the playback
of a cassette tape or FM radio by enabling the traffic
interrupt feature. Press the TRAF button once to seek
to an RDS station that supports the traffic interrupt
feature if the current station does not. The traffic symbol
will flash on the display when seeking for a station that
supports traffic interrupt. When the traffic interrupt
feature is on, the traffic symbol will appear on
the display.

3-13
When a traffic announcement comes on the current
radio station, you will hear it, even if the volume is
muted or a cassette tape is playing. The traffic symbol
and TRAFFIC will appear on the display while the
traffic announcement plays. If the cassette tape player
was being used, the tape will stay in the player and
resume play at the point where it stopped.
Radio Messages
CAL ERR (Calibration Error): This message is
displayed when the radio has not been calibrated
properly for the vehicle. You must return to the
dealership for service.
LOCKED: This message is displayed when the
THEFTLOCK

system has locked up. You must
return to the dealership for service.
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
to the right. If the ignition is on and the radio is off,
the tape can be inserted and will begin playing. A tape
symbol is shown on the display whenever a tape is
inserted. If you hear nothing but a garbled sound, the tape may not be in squarely. Press EJT to remove
the tape and start over. If you want to insert a tape when
the ignition is off, first press EJT or DISP.
While the tape is playing, use VOL, TUNE, SEEK and
PSCAN controls just as you do for the radio. The radio
will display TAPE and an arrow showing which side of
the tape is playing.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.
1 PREV (Previous): Press this pushbutton to go to the
previous selection on the tape if the selection has been
playing for less than three seconds. If this pushbutton is
pressed and the current selection has been playing for
more than 13 seconds, it will go to the beginning of the
current selection. If this pushbutton is pressed and the
current selection has been playing from 3 to 13 seconds,
it will go to the beginning of the previous selection or the
beginning of the current selection, depending upon the
position on the tape. SEEK and a
-1 will appear on the
display while the cassette player is in the previous mode.
If this pushbutton is pressed additional times or held, the
radio will go to the displayed number of previous
selections up to 9. SEEK and a negative number will
appear on the display. Your tape must have at least three
seconds of silence between each selection for previous to
work. The sound will mute while seeking.

3-14
2 NEXT: Press this pushbutton to go to the next
selection on the tape. If you press this pushbutton more
than once, the player will continue moving forward
through the tape. SEEK and a positive number will
appear on the display. Your tape must have at least three
seconds of silence between each selection for next to
work. To forward through each selection press the right
SEEK arrow. The sound will mute while seeking.
3 REV (Reverse): Press this pushbutton to reverse the
tape rapidly. Press it again to return to playing speed.
The radio will play the last selected station while the
tape reverses. The station frequency and REV will
appear on the display. You may select stations during
reverse operation by using TUNE and the SEEK arrows.
4 FWD (Forward): Press this pushbutton to advance
quickly to another part of the tape. Press the pushbutton
again to return to playing speed. The radio will play the
last selected station while the tape advances. The station
frequency and FWD will appear on the display. You
may select stations during forward operation by using
TUNE and the SEEK arrows.
5
SIDE: Press this pushbutton to play the other side
of the tape.6
(Dolby): Press this pushbutton to reduce
background noise. The double
-D symbol will appear
on the display.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
 SEEK
: If the right or left arrow is held or
pressed more than once, the player will continue moving
forward or backward through the tape. SEEK and a
positive or negative number will appear on the display.
BAND: Press this button to listen to the radio
when a tape is playing. The tape will stop but remain
in the player.
TAPE AUX (Auxiliary): Press this button to play
a cassette tape when listening to the radio. The
inactive tape will remain safely inside the radio for
future listening.
EJT (Eject): Press this button to stop a tape when it
is playing or to eject a tape when it is not playing. Eject
may be activated with the radio off. Cassette tapes may
be loaded with the radio off if this button is pressed first.

3-15
Cassette Tape Messages
CHK TAPE (Check Tape): If this message appears on
the radio display, the tape won't play because of one of
the following errors.

The tape is tight and the player can't turn the tape
hubs. Remove the tape. Hold the tape with the open
end down and try to turn the right hub
counterclockwise with a pencil. Turn the tape over
and repeat. If the hubs do not turn easily, your tape
may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.

The tape is broken. Try a new tape.

The tape is wrapped around the tape head. Attempt
to get the cassette out. Try a new tape.
CLEAN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, use the following steps:
1. Turn the radio off.
2. Press and hold the TAPE AUX button for five
seconds. READY will appear on the display for five
seconds, indicating the feature is active.
3. Insert the adapter into the cassette slot. It will power
up the radio and begin playing.
This override routine will remain active until EJT
is pressed.

3-16 AM-FM Stereo with Compact Disc Player
with Radio Data System (RDS) and
Automatic Tone Control (If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
 VOL
(Volume): Turn the knob clockwise
to increase volume. Turn it counterclockwise to
decrease volume.AUTO VOL (Automatic Volume): With automatic
volume, your audio system adjusts automatically to
make up for road and wind noise as you drive.
Set the volume at the desired level. Press this button to
select LOW, MEDIUM or HIGH. AVOL will appear on
the display. The volume level should always sound the
same to you as you drive. Each higher volume setting
allows for more volume compensation at faster vehicle
speeds. Then as you drive, automatic volume increases
the volume as necessary to overcome noise at any speed.
NONE will appear on the display if the radio cannot
determine the vehicle speed. If you don't want to use
automatic volume, select OFF.
DISP (Display): Press this knob when the ignition is
off to display the clock.
Finding a Station
BAND: Press this button to switch between AM, FM1
and FM2. The display shows your selection. TUNE
: Turn this knob to choose radio stations.
 SEEK
: Press the right or left arrow to seek to
the next or previous station and stay there. The radio
will seek to stations with a strong signal only. The sound
will mute while seeking.

3-17
 PSCAN
(Preset Scan): Press and hold one of
the arrows for more than two seconds and the radio will
produce one beep. The radio will scan to the first preset
station stored on your pushbuttons, play for a few
seconds and flash the station frequency, then go on to
the next preset station. Press one of the arrows or one of
the pushbuttons again to stop scanning. SCAN will be
displayed whenever the tuner is in the preset scan mode.
The channel number (P1 through P6) will appear with
the frequency. In FM mode, this function will scan
through the current band such as FM1 or FM2. The
radio will scan preset stations with a strong signal only.
The sound will mute while scanning.
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press AUTO TONE to choose the bass and treble
equalization that best suits the type of station you are
listening to.5. Press and hold one of the six numbered pushbuttons.
The radio will produce one beep. Whenever you
press that numbered pushbutton, the station you set
will return and the bass and treble equalization that
you selected will also be automatically selected for
that pushbutton.
6. Repeat the steps for each pushbutton.
Setting the Tone (Bass/Treble)
AUDIO: Push and release the AUDIO knob until BASS
or TREB appears on the display. Turn the knob
clockwise or counterclockwise to increase or decrease.
The display will show the bass or treble level. If a
station is weak or noisy, you may want to decrease the
treble.
To adjust bass and treble to the middle position, push
and hold the AUDIO knob. The radio will produce one
beep and adjust the display level to the middle position.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone
or speaker control is displayed. You will hear one beep
and the radio will display ALL. The bass and treble will
be adjusted to the middle position.

3-18
AUTO TONE: This feature allows you to choose
preset bass and treble equalization settings designed
for country/western, jazz, talk, pop, rock and
classical stations.
Each time you press the AUTO TONE button, this
feature will switch to one of these program types.
To return the bass and treble to the manual mode,
push and release the AUDIO knob until the display
goes blank.
Adjusting the Speakers (Balance/Fade)
AUDIO: To adjust the balance between the right and
left speakers, push and release the AUDIO knob until
BAL appears on the display. Turn the knob clockwise to
move the sound to the right speakers and
counterclockwise to move the sound to the left speakers.
To adjust the fade, push and release the AUDIO
knob until FADE appears on the display. Turn the
knob clockwise to move the sound to the front
speakers and counterclockwise to move the sound
to the rear speakers.To adjust the balance and fade to the middle position,
push the AUDIO knob, then push it again and hold it
until you hear one beep. The balance and fade will be
adjusted to the middle position and the display will
show the speaker balance.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone
or speaker control is displayed. The radio will produce
one beep and display ALL with the level display in the
middle position.
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that receives data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS your radio can do
the following:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.

3-19
RDS features are only available on FM stations which
broadcast RDS information. The RDS features of your
radio rely on receiving specific RDS information from
these stations. These features will only work when the
RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, contact the radio station.
When you are tuned to an RDS station, the station
name will appear on the display, instead of the
frequency. Most RDS stations provide their station
name, the time of day and a Program Type (PTY) for
their current programming. Some stations also provide
the name of the current program.
Finding RDS Stations
To find RDS stations, perform the following steps:
1. Press the SEEK TYPE button or turn the P
-TYPE
LIST knob to display the program type list.
2. Turn the knob either clockwise or counterclockwise
to select a program type. The list is alphabetical. If
you select ANY TYPE your radio will seek to the
first PTY available.
3. Press the SEEK TYPE button to activate search.DISP (Display): Press this knob to change what appears
on the display while using RDS. Pressing this knob will
also display an RDS station frequency or program type
when the radio is on. The display options are station
name, station frequency, PTY and the name of the
program (if available). Pressing and holding this knob
will activate the RDS default display.
Finding a PTY Preset Station
P
-TYPE LIST (Program Type): Turn this knob
clockwise or counterclockwise to select the Program
Type (PTY) you want to listen to. TYPE and a PTY will
appear on the display. Press the SEEK TYPE button and
the radio will seek to the first RDS broadcaster of the
selected program type. If the radio cannot find the desired
program type, NONE will appear on the display and the
radio will return to the last station you were listening to.
BAND (Alternate Frequency): Alternate frequency
allows the radio to switch to a stronger station with the
same program type. Press and hold BAND for two
seconds to turn alternate frequency on. AF ON will
appear on the display. The radio may switch to stronger
stations. Press and hold BAND again for two seconds to
turn alternate frequency off. AF OFF will appear on the
display. The radio will not switch to other stations. When
you turn the ignition off and then on again, the alternate
frequency feature will automatically be turned on.

3-20
SEEK TYPE: Press this button to go to a station with
the last selected PTY; TYPE and the last selected PTY
will appear on the display, if it is not already showing.
Press TYPE a second time to seek. If a station with the
selected PTY is not found, the radio will return to the
original station and display NONE.
RDS Messages
ALERT!: Alert warns of national or local emergencies.
You will not be able to turn off alert announcements.
ALERT! appears on the display when an alert
announcement plays. When an alert announcement
comes on the current radio station, you will hear it,
even if the volume is muted or a compact disc is
playing. If the compact disc player is playing, play
will stop for the announcement and resume when the
announcement is finished.
This function will only work during actual emergency
broadcasts, and will not work during tests of the
emergency broadcast system. This feature is not
supported by all RDS stations.INFO (Information): If the current station has a
message, the information symbol will appear on the
display. These text messages are from the RDS
broadcaster to the listening public and may be general
information such as artist and song title, call in phone
numbers, etc. Press this button to see the message. If the
whole message does not appear on the display, parts of
the message will appear every three seconds until the
message is completed. To scroll through the message at
your own speed, press the INFO button again for less
than one second. A new group of words will appear on
the display. Once the complete message has been
displayed, the information symbol will disappear from
the display until another new message is received. The
old message can be displayed by pressing the INFO
button until a new message is received or a different
station is tuned to. When a message is not available
from an FM station, NO INFO will be displayed.
TRAF (Traffic): Press this button to receive traffic
announcements. If the current station does not broadcast
traffic announcements, the radio will seek to a station
that does. The traffic symbol will flash on the display.
When the radio finds a station that broadcasts traffic
announcements, it will stop. If no station is found,
NO TRAF will appear on the display.
