display CHEVROLET MONTE CARLO 2002 6.G User Guide

2-33
How long should you keep the coolant heater plugged
in? The answer depends on the outside temperature, the
kind of oil you have, and some other things. Instead of
trying to list everything here, we ask that you contact
your dealer in the area where you'll be parking your
vehicle. The dealer can give you the best advice for
that particular area.
Automatic Transaxle Operation
Your automatic transaxle has a shift lever located on the
console between the front seats.
The above graphic is displayed on your instrument
panel cluster.
Maximum engine speed is limited on automatic
transaxle vehicles when you're in PARK (P) or
NEUTRAL (N) to protect driveline components
from improper operation.

2-53
Delayed Entry Lighting
Delayed entry lighting illuminates the interior for a
period of time after all the doors have been closed.
The ignition must be off for delayed entry lighting to
work. Immediately after both doors have been closed,
the delayed entry lighting feature will continue to work
until one of the following occurs:

The ignition is in moved to ON,

the doors are locked or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on.
Delayed Exit Lighting
This feature illuminates the interior for a period of time
after the key is removed from the ignition.
The vehicle's ignition must be off for delayed exit
lighting to work.When the key is removed, interior illumination will
activate and remain on until one of the following occurs:

The ignition is moved to ON,

the power door locks are activated or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on.
Parade Mode
The instrument panel has an added feature called
parade mode. This feature prohibits the dimming of
your instrument panel displays during the daylight
while the headlamps are on so that you'll still be able
to see the displays.
Reading Lamps
The reading lamps are located on the rearview mirror.
These lamps and the interior courtesy lamps come
on when any door is opened. Press the button to turn
them on when the doors are closed. Press it again to
turn them off.

2-75
Tachometer
The tachometer displays
the engine speed in
thousands of revolutions
per minute (rpm).
3800 V6 Engine Shown
NOTICE:
Do not operate the engine with the tachometer in
the shaded area, or engine damage may occur.
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you
are familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.

2-85
United States Canada
This message is displayed in the message center
when the engine oil pressure is low. A chime will
sound continuously, also.
If this occurs, you should have your vehicle
serviced immediately.
CAUTION:
Don't keep driving if the oil pressure is low.
If you do, your engine can become so hot that it
catches fire. You or others could be burned.
Check your oil as soon as possible and have your
vehicle serviced.
NOTICE:
Damage to your engine from neglected oil
problems can be costly and is not covered by
your warranty.
Cruise Light (If Equipped)
The CRUISE light comes
on whenever you set your
cruise control. See ªCruise
Controlº in the Index.

2-87
Message Center
The message center is located below the tachometer
gage on the instrument panel cluster. It gives you
important safety and maintenance facts.
Modes
Service Traction System
United States Canada
If this message appears when you are driving, there is
a problem with your traction control system and your
vehicle is in need of service.
When this message is displayed, the system will not
limit wheel spin. The message will stay on for 60
seconds and then go out. Four chimes will also be heard.
Adjust your driving accordingly.When the ignition is turned off, this message will be
displayed again for three seconds to remind you that
your traction control system is not working properly.
Be sure to have your vehicle serviced right away.
Traction Active
United States Canada
This message will appear when the traction control
system is limiting wheel spin.
The message will stay on a few seconds after the
traction system stops limiting wheel spin.

2-88
Battery Life Indicator
When the vehicle is
started this message
will be displayed for
three seconds.
If the message is displayed when the engine is running,
you may have a problem with your charging system. If
there is a problem with the charging system, four chimes
will sound when the message comes on. The battery
display will also stay on while the key is in ON until the
engine is started.
If the message stays on after starting the engine it could
indicate a problem with the generator drive belt, or some
other charging system problem. Have it checked right
away. Driving with this message on could drain
your battery.
If you must drive a short distance with this message
displayed, it helps to turn off all your accessories.Hot Coolant Temperature
United States Canada
This message is displayed when the cooling
system temperature gets hot. A chime will sound
continuously, also.
Check the coolant temperature gage and the coolant
level. See ªEngine Coolant,º ªEngine Coolant
Temperature Gageº and ªEngine Overheatingº in
the Index for further information.

2-89
Low Coolant Level
United States Canada
This message is displayed when the cooling system is
low on coolant. Four chimes will also sound.
The engine may overheat. See ªEngine Coolantº in the
Index and have your vehicle serviced as soon as possible.Low Oil PressureUnited States Canada
This message is displayed when the engine oil pressure
is low. A chime will sound continuously, also. See ªOil
Pressure Indicator/Low Oil Pressure Lightº earlier in
this section.

2-90
Low Engine Oil Level
United States Canada
This message is displayed for 60 seconds at the start of
each ignition cycle when the engine oil level is low.
Four chimes will also sound.
When the ignition is turned off, this message will be
displayed again for three seconds to remind you that
your engine oil level is low. Be sure to have your vehicle
serviced right away.
See ªEngine Oilº in the Index on how to check the oil
level and for what type of oil to add.Change Engine OilUnited States Canada
This message is displayed when the engine oil
needs to be changed. It will appear for 60 seconds.
After 60 seconds, it will go out.
Once the engine oil has been changed, the CHANGE
ENGINE OIL message must be reset. Until it is reset,
the message will be displayed for 60 seconds each time
you start the engine. For more information on resetting
the system, see ªEngine Oil, When to Changeº in
the Index.

2-91
Door Ajar
United States Canada
This message will appear if the driver's door or the
passenger's door is not completely closed and the
ignition is in ON.
If you are in a forward or reverse gear position you
will also hear four chimes.Security United States Canada
This message is displayed to monitor the
Passlock

system.
If the security message is displayed continuously while
driving and stays on, there may be a problem with the
Passlock system. Your vehicle will not be protected by
Passlock, and you should see your dealer for service.

2-92
Low Fuel
United States Canada
This message is displayed when your vehicle is low on
fuel. Four chimes will also sound.
Refer to the fuel gage for a better indication of the
amount of fuel remaining in the fuel tank.Low Brake FluidUnited States Canada
This message will be displayed when your vehicle has a
brake problem. The brake system warning light will also
be illuminated.
If this message appears, the brakes aren't working
properly. You should have your vehicle serviced
immediately. See ªBrake System Warning Lightº
in the Index for more information.
