display CHEVROLET MONTE CARLO 2002 6.G Owners Manual

2-19

Remote Keyless Entry Transmitter Programming
(Available with Remote Keyless Entry)

Return to Original Factory Settings
(Available for All)

Exit Vehicle Customization Mode
Entering Programming Mode: To reset or customize
the features, you must first enter the vehicle
customization main menu. To enter the main menu, do
the following:
1. Turn the ignition to ACC or ON. The radio must
be off.
2. Press and hold the TUNE DISP button on the
radio for at least five seconds until SETTINGS
is displayed.
3. Press the SEEK PSCAN up or down arrows to scroll
through each available feature on your main menu.
4. Press the 1 PREV or 2 NEXT buttons to scroll
through the lower menu. An asterisk (*) will appear
next to the item that is the current setting.The following information shows how to reset or
customize features after entering the main menu:
SETTINGS
-- Display Current Settings
OIL LIFE (Oil Life System Reset): This feature
allows you to reset the GM Oil Life System Monitor
after an oil change. See ªEngine Oilº in the Index.
Be careful not to reset the OIL LIFE system accidentally
at any time other than when the oil has been changed.
It can't be reset accurately until the next oil change.
To clear the CHANGE ENGINE OIL light from the
instrument panel cluster and reset the oil life system,
do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until OIL LIFE appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter the
submenu. RESET will then be displayed.
3. Press the TUNE DISP button to reset. A chime will
be heard to verify the new setting and DONE will be
displayed for one second.
The CHANGE ENGINE OIL light is now reset. You
can either exit the programming mode by following the
instructions later in this section or program the next
feature available on your vehicle.

2-20
TIRE MON (Tire Inflation Monitor Reset): This
feature allows you to reset the tire pressure monitor after
checking all tire pressures. See ªTiresº in the Index. To
clear the LOW TIRE PRESSURE light from the
instrument panel cluster and reset the low tire pressure
monitor, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until TIRE MON appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter the
submenu. RESET will be displayed.
3. Press the TUNE DISP button to reset. A chime will
be heard to verify the new setting and DONE will be
displayed for one second.
The low tire pressure monitor is now reset. You can
either exit the programming mode by following the
instructions later in this section or program the next
feature available on your vehicle.LT DELAY (Delayed Headlamp Illumination):
This feature allows the vehicle's headlamps and parking
lamps to stay on for a fixed amount of time after you
exit the vehicle.
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: 30 SEC
-- 30 seconds.
Mode 3: 60 SEC
-- 60 seconds.
Before your vehicle was shipped from the factory,
it was programmed to Mode 2. The mode to which
your vehicle was programmed may have been changed
since it left the factory. To determine the mode to which
your vehicle is programmed or to program your vehicle
to a different mode, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until LT DELAY appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter
the submenu. The current selection will have an
asterisk (*) next to it. If you do not wish to
change the current mode, you can either exit the
programming mode by following the directions later
in this section or program the next feature available
on your vehicle.

2-21
3. Scroll, using the 1 PREV or 2 NEXT buttons,
through the modes to change the current mode.
4. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. The new selection will be
displayed with an asterisk for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
AUTOLOCK (Automatic Door Lock and Unlock):
With the ignition in ON and the vehicle's doors closed,
this feature allows the vehicle doors to automatically
lock and unlock when the driver shifts the vehicle's
transaxle into and out of PARK (P).
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: LCK ONLY
-- Automatic door lock
on/automatic door unlock off.
Mode 3: DRVR UNL
-- Automatic door lock
on/automatic door unlock on (driver's door only).
Mode 4: ALL UNL
-- Automatic door lock
on/automatic door unlock on.Before your vehicle was shipped from the factory,
it was programmed to Mode 4. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until AUTOLOCK appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter
the submenu. The current selection will have an
asterisk (*) next to it. If you do not wish to
change the current mode, you can either exit the
programming mode by following the directions later
in this section or program the next feature available
on your vehicle.
3. Scroll, using the 1 PREV or 2 NEXT buttons,
through the modes to change the current mode.
4. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. The new selection will be
displayed with an asterisk (*) for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-22
FOB LIGHT (Remote Visual Verification):
This feature allows the exterior lights to flash when
the remote keyless entry transmitter is used to lock
or unlock the vehicle.
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: ON
-- One flash for each remote lock/two
flashes for each remote unlock.
Before your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until FOB LIGHT appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter
the submenu. The current selection will have an
asterisk (*) next to it. If you do not wish to
change the current mode, you can either exit the
programming mode by following the directions later
in this section or program the next feature available
on your vehicle.3. Scroll, using the 1 PREV or 2 NEXT buttons,
through the modes to change the current mode.
4. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. A new selection will be
displayed with an asterisk (*) for one second.
If your vehicle has the optional content theft-deterrent
system, the first time a remote UNLOCK command is
received, three flashes will be seen and three horn chirps
heard to indicate an alarm condition has occurred since
last arming. See ªContent Theft
-Deterrent Systemº in
the Index.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-23
FOB HORN (Remote Audible Verification): This
feature allows the horn to chirp when the remote keyless
entry transmitter is used to lock or unlock the vehicle.
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: PARTIAL
-- One chirp for each remote LOCK
command/no chirp for remote UNLOCK command.
Mode 3: FULL
-- One chirp for each remote
LOCK command/two chirps for the first remote
UNLOCK command.
Before your vehicle was shipped from the factory, it was
programmed to Mode 1. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until FOB HORN appears on the display.2. Press the 1 PREV or 2 NEXT button to enter
the submenu. The current selection will have an
asterisk (*) next to it. If you do not wish to
change the current mode, you can either exit the
programming mode by following the directions later
in this section or program the next feature available
on your vehicle.
3. Scroll, using the 1 PREV or 2 NEXT buttons,
through the modes to change the current mode.
4. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. The new selection will be
displayed with an asterisk (*) for one second.
If your vehicle has the optional content theft
-deterrent
system, the first time the remote UNLOCK command
is received three chirps will be heard to indicate an
alarm condition has occurred since last arming. See
ªContent Theft
-Deterrent Systemº in the Index.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-24
ALARM (Content Theft Operation): This feature
allows the content theft
-deterrent system to be turned
on or off.
Programmable Modes
Mode 1: ALRM OFF
-- Turns feature off.
Mode 2: ALRM ON
-- Turns feature on.
Before your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until ALARM appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter
the submenu. The current selection will have an
asterisk (*) next to it. If you do not wish to
change the current mode, you can either exit the
programming mode by following the directions later
in this section or program the next feature available
on your vehicle.3. Scroll, using the 1 PREV or 2 NEXT buttons,
through the modes to change the current mode.
4. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. The new selection will be
displayed with an asterisk (*) for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
TRNKJAMB (Trunk Jamb): This feature allows the
content theft system trunk lock sensor to be disabled or
enabled.
Programmable Modes
Mode 1: TRNK OFF
-- Turns feature off.
Mode 2: TRNK ON
-- Turns feature on.
Before your vehicle was shipped from the factory, it
was programmed to Mode 2. The mode to which your
vehicle was programmed may have been changed since
it left the factory.

2-25
To determine the mode to which your vehicle is
programmed or to program your vehicle to a different
mode, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until TRNKJAMB appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter
the submenu. The current selection will have an
asterisk (*) next to it. If you do not wish to
change the current mode, you can either exit the
programming mode by following the directions later
in this section or program the next feature available
on your vehicle.
3. Scroll, using the 1 PREV or 2 NEXT buttons,
through the modes to change the current mode.
4. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. The new selection will be
displayed with an asterisk (*) for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.CHIRP (Horn Chirp Timer): This feature allows you
to choose between short or long horn chirp sounds when
the remote keyless entry transmitter is used.
Programmable Modes
Mode 1: SHORT
-- Short Chirp
Mode 2: LONG
-- Long Chirp
Before your vehicle was shipped from the factory,
it was programmed to Mode 1. The mode to which
your vehicle was programmed may have been changed
since it left the factory. To determine the mode to which
your vehicle is programmed or to program your vehicle
to a different mode, do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until CHIRP appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter
the submenu. The current selection will have an
asterisk (*) next to it. If you do not wish to
change the current mode, you can either exit the
programming mode by following the directions later
in this section or program the next feature available
on your vehicle.
3. Scroll, using the 1 PREV or 2 NEXT buttons,
through the modes to change the current mode.

2-26
4. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. The new selection will be
displayed with an asterisk (*) for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
ORIG. SET (Return to the Original Settings):
This feature allows you to return all customization
feature settings back to their original factory settings.
To reset do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until ORIG. SET appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter the
submenu. SET ALL will appear.
3. With your preference displayed, press the TUNE
DISP button to select. A chime will be heard to
verify the new setting. The new selection will be
displayed with an asterisk (*) for one second.
The original factory settings are now reset. You can
either exit the programming mode by following the
instructions later in this section or program the next
feature available on your vehicle.FOB PROG (Remote Keyless Entry Transmitter
Programming): This feature allows you to match
the remote keyless entry transmitter to your vehicle.
To match the transmitter do the following:
1. Scroll, using the SEEK PSCAN up or down arrows,
until FOB PROG appears on the display.
2. Press the 1 PREV or 2 NEXT button to enter the
submenu. BEGIN will be displayed.
3. Press the TUNE DISP button to start programming.
When the message PUSH FOB flashes, press and
hold the LOCK and UNLOCK buttons on the first
transmitter at the same time for 15 seconds. A chime
will be heard to verify the transmitter is learned.
4. Repeat Step 3 for each additional transmitter.
The transmitter is programmed now. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
EXIT (Exit Feature Customization Mode): This
feature allows you to exit the vehicle customization
programming. To exit do the following:

Scroll until EXIT appears on the display.

Press the TUNE DISP button to exit programming.
A chime will be heard to verify the exit.

2-27
Passlock
Your vehicle is equipped with the Passlock
theft
-deterrent system.
Passlock is a passive theft
-deterrent system. Passlock
enables fuel if the ignition lock cylinder is turned with a
valid key. If a correct key is not used or the ignition lock
cylinder is tampered with, fuel is disabled and the
engine will not start.
During normal operation, the SECURITY message will
be displayed after the key is turned to the ON ignition
position. See ªMessage Center, Securityº in the Index.
If the engine stalls and the SECURITY message flashes,
wait until the light stops flashing before trying to restart
the engine.
If the engine is running and the SECURITY message
comes on, you will be able to restart the engine if you turn
the engine off. However, your Passlock system is not
working properly and must be serviced by your dealer.
Your vehicle is not protected by Passlock at this time.
You may also want to check the fuse. See ªFuses and
Circuit Breakersº in the Index. See your dealer for service.
In an emergency, contact Chevrolet Roadside
Assistance. See ªRoadside Assistanceº in the Index
for more information.
New Vehicle ªBreak-Inº
NOTICE:
Your vehicle doesn't need an elaborate
ªbreak
-in.º But it will perform better in
the long run if you follow these guidelines:

Don't drive at any one speed -- fast or
slow
-- for the first 500 miles (805 km).
Don't make full
-throttle starts.

Avoid making hard stops for the first
200 miles (322 km) or so. During this time
your new brake linings aren't yet broken
in. Hard stops with new linings can mean
premature wear and earlier replacement.
Follow this breaking
-in guideline every
time you get new brake linings.

Don't tow a trailer during break
-in.
See ªTowing a Trailerº in the Index for
more information.

2-28
Ignition Positions
With the key in the ignition switch, you can turn it to
four different positions.
The ignition switch is
located on the instrument
panel, to the right of the
steering column.
With the key in the ignition switch, you can turn the
switch to four positions.
OFF: This is the only position from which you can
remove the key. Removing the key locks your ignition
and automatic transaxle.
NOTICE:
If your key seems stuck in OFF and you can't
turn it, be sure you are using the correct key;
if so, is it all the way in? Turn the key only with
your hand. Using a tool to force it could break
the key or the ignition switch. If none of this
works, then your vehicle needs service.
ACC (Accessory): This is the position in which you
can operate your electrical accessories. With the key
in this position, the ignition and automatic transaxle
will unlock.
ON: This is the position the switch returns to after you
start the engine and release the switch. The switch stays
in ON when the engine is running. But even when the
engine is not running, you can use ON to operate your
electrical accessories and to display some instrument
panel cluster messages and warning lights.
