CAUTION: (Continued)
3. If you have a four-wheel-drive vehicle,
be sure the transfer case is in a drive
gear – not in NEUTRAL.
4. Turn off the engine and do not restart
while the vehicle is raised.
5. Do not allow passengers to remain in
the vehicle.
To be even more certain the vehicle will
not move, put blocks at the front and rear
of the tire farthest away from the one
being changed. That would be the tire on
the other side, at the opposite end of the
vehicle.
When your vehicle has a at tire, use the following
example as a guide to assist you in the placement
of the wheel blocks.The following information will tell you next how to
use the jack and change a tire.
581

Removing the Spare Tire and Tools
A. Wing Nut
Retaining
Tool Kit
B. Tool Kit
C. Wheel BlocksD. Jack
E. Wing Nut
Retaining Wheel
BlocksA. Tool Cover
B. Wing Nut
Retaining Wheel
BlocksC. Wheel Blocks
D. Tool Kit
E. Jack
F. Knob
Crew Cab
Regular Cab
582

A. Wing Nut
Retaining
Tool Kit
B. Tool KitC. Wheel Blocks
D. Jack
E. KnobFor regular cab models, the equipment you will
need is behind the passenger’s seat. For extended
and crew cab models, the equipment is on the
shelf behind the passenger’s side second
row seat.
1. If there is a cover, move the seats forward
and turn the wing nut on the cover
counterclockwise to remove it. For crew cab
models, pull up the second row seat with
the loop at the base of the seat cushion to
access the tools.
2. Turn the knob on the jack counterclockwise to
lower the jack head to release the jack from
its holder.
3. Remove the wheel blocks and the wheel
block retainer by turning the wing nut
counterclockwise.
4. Remove the wing nut used to retain the
storage bag and tools by turning it
counterclockwise.
You will use the jack handle extensions and the
wheel wrench to remove the underbody-mounted
spare tire.
Extended Cab
583

A. Spare Tire
(Valve Stem
Pointed Down)
B. Hoist Assembly
C. Hoist Cable
D. Tire/Wheel
Retainer
E. Hoist Shaft
F. Hoist End of
Extension ToolG. Hoist Shaft
Access Hole
H. Wheel Wrench
I. Jack Handle
Extensions
J. Spare Tire Lock
(If equipped)1. Open the spare tire lock cover on the bumper
and use the ignition key to remove the spare
tire lock (J). To remove the spare tire lock,
insert the ignition key turn and pull straight out.
2. Assemble the wheel wrench (H) and the
two jack handle extensions (I) as shown.
584

3. Insert the hoist end
(open end) (F) of the
extension through
the hole (G) in
the rear bumper.
Be sure the hoist end of the extension (F)
connects to the hoist shaft (E). The ribbed
square end of the extension is used to lower
the spare tire.
4. Turn the wheel wrench (H) counterclockwise
to lower the spare tire to the ground. Continue
to turn the wheel wrench until the spare tire
can be pulled out from under the vehicle.
If the spare tire does not lower to the ground,
the secondary latch is engaged causing
the tire not to lower. SeeSecondary Latch
System on page 592.5. Use the wheel
wrench hook which
allows you to
pull the hoist cable
towards you to
assist in reaching
the spare tire.
6. Tilt the retainer (D)
at the end of the
cable (C) when the
tire has been
lowered, so it can
be pulled up through
the wheel opening.
7. Put the spare tire near the at tire.
585

Removing the Flat Tire and
Installing the Spare Tire
Use the following pictures and instructions to
remove the at tire and raise the vehicle.
The tools you will be using include the jack (A),
the wheel blocks (B), the jack handle (C), the jack
handle extensions (D), and the wheel wrench (E).1. If your vehicle has
wheel nut caps,
loosen them
by turning the wheel
wrench
counterclockwise.
If the vehicle has a center cap with wheel nut
caps, the wheel nut caps are designed to
stay with the center cap after they are
loosened. Remove the entire center cap.
586

If the wheel has a smooth center cap, place
the chisel end of the wheel wrench in the
slot on the wheel, and gently pry it out.2. Use the wheel wrench and turn it
counterclockwise to loosen the wheel nuts. Do
not remove the wheel nuts yet.
587

3. Position the jack under the vehicle as shown.
If the at tire is on the front of the vehicle
(1500 Model vehicles), position the jack under
the bracket attached to the vehicle’s frame,
behind the at tire. If the at tire is on the front
of the vehicle (all other models), position
the jack on the frame behind the at tire.
Front Position - 1500 ModelsFront Position - All Other Models
588

If the at tire is on the rear, position the jack
under the rear axle between the spring anchor
and the shock absorber bracket.
If you have added a snow plow to the front of
your vehicle, lower the snow plow fully
before raising the vehicle.
Make sure that the jack head is positioned so
that the rear axle is resting securely between
the grooves that are on the jack head.
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it is
supported only by a jack.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall. To
help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising the
vehicle.
Rear Position – All Models
589

4. Turn the wheel wrench clockwise to raise the
vehicle. Raise the vehicle far enough off the
ground so there is enough room for the spare
tire to t under the wheel well.
5. Remove all the
wheel nuts and take
off the at tire.
{CAUTION:
Rust or dirt on the wheel, or on the parts
to which it is fastened, can make the
wheel nuts become loose after time. The
CAUTION: (Continued)
CAUTION: (Continued)
wheel could come off and cause an
accident. When changing a wheel, remove
any rust or dirt from the places where the
wheel attaches to the vehicle. In an
emergency, a cloth or a paper towel can
be used to do this; but be sure to use a
scraper or wire brush later, if needed, to
get all the rust or dirt off.
6. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces, and spare
wheel.
7. Install the spare tire.
590
