wheel alignment CHEVROLET VENTURE 2003 1.G Owners Manual

Service............................................................5-3
Doing Your Own Service Work.........................5-3
Adding Equipment to the Outside of
Your Vehicle..............................................5-4
Fuel................................................................5-4
Gasoline Octane............................................5-4
Gasoline Speci®cations....................................5-5
California Fuel...............................................5-5
Additives.......................................................5-6
Fuels in Foreign Countries...............................5-6
Filling Your Tank............................................5-7
Filling a Portable Fuel Container.......................5-9
Checking Things Under the Hood....................5-10
Hood Release..............................................5-10
Engine Compartment Overview.......................5-12
Engine Oil...................................................5-13
Engine Air Cleaner/Filter................................5-18
Automatic Transaxle Fluid..............................5-20
Engine Coolant.............................................5-23
Radiator Pressure Cap..................................5-26
Engine Overheating.......................................5-26
Cooling System............................................5-29
Power Steering Fluid.....................................5-37
Windshield Washer Fluid................................5-38
Brakes........................................................5-40Battery........................................................5-43
Jump Starting...............................................5-44
All-Wheel Drive..............................................5-50
Bulb Replacement..........................................5-52
Halogen Bulbs..............................................5-52
Headlamps..................................................5-52
Front Turn Signal, Sidemarker and
Parking Lamps..........................................5-54
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps.........................................5-56
Replacement Bulbs.......................................5-57
Windshield Wiper Blade Replacement..............5-58
Tires..............................................................5-60
In¯ation - Tire Pressure.................................5-61
Tire Inspection and Rotation...........................5-62
When It Is Time for New Tires.......................5-63
Buying New Tires.........................................5-64
Uniform Tire Quality Grading..........................5-65
Wheel Alignment and Tire Balance..................5-66
Wheel Replacement......................................5-66
Tire Chains..................................................5-67
Accessory In¯ator.........................................5-68
If a Tire Goes Flat........................................5-70
Changing a Flat Tire.....................................5-71
Compact Spare Tire......................................5-86
Section 5 Service and Appearance Care
5-1

Tire Inspection and Rotation
Tires should be rotated every 7,500 miles (12 500 km).
Any time you notice unusual wear, rotate your tires
as soon as possible and check wheel alignment. Also
check for damaged tires or wheels. See
When It Is Time
for New Tires on page 5-63andWheel Replacement
on page 5-66for more information.
Make sure the spare tire is stored securely. Push, pull,
and then try to rotate or turn the tire, If it moves,
use the folding wrench to tighten the cable. See
Changing a Flat Tire on page 5-71.
The purpose of regular rotation is to achieve more
uniform wear for all tires on the vehicle. The ®rst rotation
is the most important. See ªPart A: Scheduled
Maintenance Services,º in Section 6, for scheduled
rotation intervals.When rotating your tires, always use the correct rotation
pattern shown here.
Don't include the compact spare tire in your tire rotation.
After the tires have been rotated, adjust the front and
rear in¯ation pressures as shown on the
Certi®cation/Tire label. Make certain that all wheel nuts
are properly tightened. See ªWheel Nut Torqueº
under
Capacities and Speci®cations on page 5-103.
{CAUTION:
Rust or dirt on a wheel, or on the parts to
which it is fastened, can make wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
places where the wheel attaches to the vehicle.
In an emergency, you can use a cloth or a
paper towel to do this; but be sure to use a
scraper or wire brush later, if you need to, to
get all the rust or dirt off. See ªChanging a Flat
Tireº in the Index.
5-62

Temperature ± A, B, C
The temperature grades are A (the highest), B, and C,
representing the tire's resistance to the generation
of heat and its ability to dissipate heat when tested
under controlled conditions on a speci®ed indoor
laboratory test wheel. Sustained high temperature can
cause the material of the tire to degenerate and
reduce tire life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to a
level of performance which all passenger car tires must
meet under the Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the
minimum required by law.
Warning: The temperature grade for this tire is
established for a tire that is properly in¯ated and not
overloaded. Excessive speed, underin¯ation, or
excessive loading, either separately or in combination,
can cause heat buildup and possible tire failure.
Wheel Alignment and Tire Balance
The wheels on your vehicle were aligned and balanced
carefully at the factory to give you the longest tire life
and best overall performance.Scheduled wheel alignment and wheel balancing are
not needed. However, if you notice unusual tire wear or
your vehicle pulling one way or the other, the alignment
may need to be reset. If you notice your vehicle
vibrating when driving on a smooth road, your wheels
may need to be rebalanced.
Wheel Replacement
Replace any wheel that is bent, cracked or badly rusted
or corroded. If wheel nuts keep coming loose, the
wheel, wheel bolts and wheel nuts should be replaced.
If the wheel leaks air, replace it (except some
aluminum wheels, which can sometimes be repaired).
See your dealer if any of these conditions exist.
Your dealer will know the kind of wheel you need.
Each new wheel should have the same load-carrying
capacity, diameter, width, offset and be mounted
the same way as the one it replaces.
If you need to replace any of your wheels, wheel bolts
or wheel nuts, replace them only with new GM
original equipment parts. This way, you will be sure to
have the right wheel, wheel bolts and wheel nuts
for your vehicle.
5-66

T
Tachometer....................................................3-39
Taillamps.......................................................5-56
Turn Signal, Stoplamps and Back-up Lamps....5-56
TCS Warning Light..........................................3-43
Theft-Deterrent, Radio....................................3-103
Theft-Deterrent Systems...................................2-27
Content Theft-Deterrent................................2-27
PASS-Key
žIII Operation..............................2-29
PASS-KeyžIII .............................................2-29
Throttle System Inspection...............................6-16
Tilt Wheel........................................................ 3-7
Tire In¯ation Check.........................................6-10
Tires.............................................................5-60
Buying New Tires........................................5-64
Chains.......................................................5-67
Changing a Flat Tire....................................5-71
Compact Spare Tire.....................................5-86
If a Tire Goes Flat.......................................5-70
In¯ation -- Tire Pressure...............................5-61
Inspection and Rotation................................5-62
Uniform Tire Quality Grading.........................5-65
Wheel Alignment and Tire Balance.................5-66
Wheel Replacement.....................................5-66
When It Is Time for New Tires......................5-63
To Use the Engine Coolant Heater....................2-34
Top Strap Anchor Location...............................1-67
Top Strap......................................................1-66
Torque Lock...................................................2-41Total Weight on Your Vehicle's Tires..................4-38
Towing..........................................................4-32
Recreational Vehicle.....................................4-32
Towing a Trailer..........................................4-36
Your Vehicle...............................................4-32
Traction.........................................................3-51
Active Message...........................................3-51
Control System (TCS).................................... 4-8
Control System Warning Light.......................3-43
Service Traction System Warning Message.....3-50
Trailer Brakes.................................................4-39
Trailer Wiring Harness.....................................4-43
Transaxle Operation, Automatic.........................2-34
Transaxle.......................................................5-20
Fluid, Automatic...........................................5-20
Transfer Case (Power Transfer Unit)..................5-50
Transmission, Transaxle, Transfer Case Unit
Repair Manual............................................7-10
Transportation Options...................................... 7-8
Trip Computer................................................3-60
Turn and Lane-Change Signals.......................... 3-8
Turn Signal/Multifunction Lever........................... 3-7
Turn Signals When Towing a Trailer..................4-41
U
Ultrasonic Rear Parking Assist (URPA)...............3-22
Underbody Flushing Service.............................6-14
Underhood Fuse Block...................................5-100
16

Understanding Radio Reception.......................3-104
Uniform Tire Quality Grading............................5-65
United States ± Customer Assistance.................. 7-4
Used Replacement Wheels..............................5-67
Using Cleaner on Fabric..................................5-88
Using HomeLink
ž...........................................2-50
Using RDS....................................3-67, 3-75, 3-84
Using Song List Mode.....................................3-90
V
Vehicle Identi®cation........................................5-95
Number (VIN).............................................5-95
Service Parts Identi®cation Label...................5-95
Vehicle Personalization....................................2-61
Arming and Disarming the Content
Theft-Deterrent System.............................2-68
Automatic Door Locks..................................2-63
Content Theft-Deterrent System.....................2-67
Delayed Illumination and Exit Lighting.............2-62
Entering Programming Mode.........................2-62
Exiting Programming Mode...........................2-70
Last Door Locking and Lockout Deterrent........2-64
Remote Driver Unlock Control.......................2-65
Remote Lock and Unlock Con®rmation...........2-66
Vehicle Storage..............................................5-44
Vehicle............................................................ 4-5
Control........................................................ 4-5
Damage Warnings........................................... ivVehicle (cont.)
Loading......................................................4-34
Symbols......................................................... iv
Ventilation Adjustment......................................3-28
Video Screen.................................................3-95
Visor Vanity Mirror..........................................2-26
Visors...........................................................2-26
W
Warm-Up Shift................................................2-37
Warning Lights, Gages and Indicators................3-35
Warnings......................................................... 3-6
Hazard Warning Flashers............................... 3-6
Other Warning Devices.................................. 3-6
Safety and Symbols......................................... iii
Vehicle Damage.............................................. iv
Washing Your Vehicle......................................5-90
Weatherstrip Lubrication...................................6-11
Weight of the Trailer Tongue.............................4-38
Weight of the Trailer........................................4-37
What Engine Coolant to Use............................5-24
What Kind of Engine Oil to Use........................5-16
What Power Steering Fluid to Use....................5-38
What to Do with Used Oil................................5-18
What Washer Fluid to Use...............................5-38
Wheels..........................................................5-66
Alignment and Tire Balance..........................5-66
Replacement...............................................5-66
17
