JACKING AND TIRE CHANGING
Jack Location
The scissor-type jack and tire changing tools are stowed under the load floor in the trunk.
Spare Tire Stowage
The compact spare tire is stowed under the rear load floor in the trunk.
Spare Tire Removal
Lift up the load floor cover and remove the hold down.
Hold Down
WHAT TO DO IN EMERGENCIES
168

Preparations For Jacking
1. Park the vehicle on a firm, level surface as far from the edge of the roadway as possible. Avoidicy or slippery areas.
2. Turn on the Hazard Warning flashers.
3. Set the parking brake.
4. Place the shift lever in PARK.
5. Turn OFF the ignition.
6. Chock both the front and rear of the wheel diagonally opposite of the jacking position. For example, if changing the right front tire, chock the left rear wheel.
NOTE:
Passengers should not remain in the vehicle
when the vehicle is being jacked.
Wheel Chocks
WHAT TO DO IN EMERGENCIES
169

Jacking Instructions
1. Remove spare tire, jack and tools from trunk.
2. Loosen (but do not remove) the wheel lugbolts by turning them to the left one turn
while the wheel is still on the ground.
Warning Label
Jack And Tools
WHAT TO DO IN EMERGENCIES
170

3. For the front tires, place the jack on the body flange just behind the front tire.
Front Body Flange
Front Body Flange Engaged
Front Jacking Location Engaged
WHAT TO DO IN EMERGENCIES
171

4. For the rear tires, place the jack on the body flange just in front of the rear tire.
Rear Body Flange
Rear Body Flange Engaged
Rear Jacking Location Engaged
WHAT TO DO IN EMERGENCIES
172

9. Finish tightening the lug bolts. Push down on the wrench while at the end of the handle forincreased leverage. Tighten the lug bolts in a star pattern until each nut has been tightened
twice. The correct wheel bolt tightness is 100 ft lb (135 N·m). If in doubt about the correct
tightness, have them checked with a torque wrench by your authorized dealer or at a service
station.
10. Lower the jack to its fully closed position.
11. Secure the tire, jack, and tools in their proper locations.
12. Remove chocks from wheels.
Road Tire Installation
1. Mount the road tire on the axle.
2. Install the remaining lug bolts with the threaded end of the bolt toward the wheel. Lightly tighten the lug bolts.
3. Lower the vehicle to the ground by turning the jack handle counterclockwise.
4. Finish tightening the lug bolts. Push down on the wrench while at the end of the handle for increased leverage. Tighten the lug bolts in a star pattern until each bolt has been tightened
twice. The correct tightness of each lug bolt is 100 ft/lbs (135 N·m). If in doubt about the
correct tightness, have them checked with a torque wrench by your authorized dealer or
service station.
5. After 25 miles (40 km) check the lug bolt torque with a torque wrench to ensure that all lug bolts are properly seated against the wheel.
CAUTION!
Do not attempt to raise the vehicle by jacking on locations other than those indicated in the
Jacking Instructions for this vehicle.
WHAT TO DO IN EMERGENCIES
174
