Page 221 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual Wet Cleaning
Wash with clear water or with a mild detergent and an
ample supply of luke warm water by wiping with a
soft-bristled brush or sponge from front to rear. Then
rinse thoroughly with clear w

Page 222 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical s

Page 223 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual Underhood Accessory Fuse Block Fuses
Cavity Fuse Circuits
1 5 Amp
BeigeGarage Door Opening Signal,
TPM and Seat Heater
2 5 Amp
BeigeOccupant Restraint Controller
Passenger Airbag Off
3 5 Amp
BeigeIndi

Page 224 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual Cavity Fuse Circuits
8 15 Amp
BlueRadio
9 10 Amp
RedRoof Light, Horn, Anti-Theft
Alarm, Cargo Lamp and Tire
Pressure Control
10 5 Amp
BeigeSpeed Control
11 15 Amp
BlueIgnition Coil 6 Cyl.
12 10 Amp
Re

Page 225 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual Cavity Fuse Circuits
31 15 Amp
BlueCigar Lighter, Glove Compart-
ment Light
32 15 Amp
BlueWiper, Washer Pump, Headlight
Flasher
33 5 Amp
BeigeClimate Control
34 Spare (Coupe)
34 30 Amp
GreenClimate Co

Page 226 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual Relay Control Module Fuses
Cavity Fuse Circuits
1 15 Amp Blue Traction System
2 15 Amp Blue Engine Control 2
3 15 Amp Blue Engine Control 1
4 40 Amp
OrangeAir Pump
5 15 Amp Blue Fuel Pump
6 15 Amp Blu

Page 227 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual Interior Fuses
Cavity Fuse Circuits
1 Not Assigned
2 15 Amp Blue Brake Lamp/Speed Control
3 7.5 Amp
BrownRight High Beam, High Beam
Indicator Light
4 15 Amp Blue Reverse/Turn signal Light
Cavity Fuse

Page 228 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual REPLACEMENT BULBS
Interior Light Bulbs
For lighted switches and interior lights, see your autho-
rized dealer for servicing requirements.
Exterior Light Bulbs
Bulb Bulb No.
Headlight - High and Low Be

Page 229 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual 3. Release the spring clamps holding the bulb in place,
and pull out the bulb. Replace the bulb and reverse the
removal procedure exactly.
CAUTION!
Do not touch the new bulb with your fingers. Oil
con

Page 230 of 280

CHRYSLER CROSSFIRE SRT 2005 1.G Owners Manual 4. Realign the two tabs and push the light in until it
engages into the lock.
Tail, Stop, Back Up and Turn Signal Lights
1. Open the rear liftgate / decklid and remove the access
door in the trim pane
