Page 251 of 280
•If for some reason you are still not satisfied, talk to the
general manager or owner of the dealership. They
want to know if you need assistance.
•If your dealership is unable to resolve the concern, you
may contact the DaimlerChrysler Corporation’s Cus-
tomer Center.
Any communication to the DaimlerChrysler Corpora-
tion’s Customer Center should include the following
information:
•Owner’s name and address
•Owner’s telephone number (home and office)
•Dealership name
•Vehicle identification number
•Vehicle delivery date and mileage
DaimlerChrysler Motors Corporation Customer
Center
P.O. Box 21–8004
Auburn Hills, MI 48321–8004
Phone: (800) 992-1997
DaimlerChrysler Canada Inc. Customer Center
P.O. Box 1621
Windsor, Ontario N9A 4H6
Phone: (800) 465-2001
In Mexico contact:
A.V. Prolongacion Paseo de la Reforma, 1240
Sante Fe C.P. 05109
Mexico, D.F.
In Mexico (915) 729-1248 or 729-1240
Outside Mexico (525) 729-1248 or 729-1240
Customer Assistance For The Hearing Or Speech
Impaired (TDD/TTY)
To assist customers who have hearing difficulties, the
DaimlerChrysler Corporation has installed special
TDD (Telecommunication Devices for the Deaf) equip-
ment at its Customer Center. Any hearing or speech
impaired customer who has access to a TDD or a
conventional teletypewriter (TTY) in the United States
can communicate with the DaimlerChrysler Corpora-
tion by dialing 1-800-380-CHRY.
IF YOU NEED CONSUMER ASSISTANCE 251
9
Page 252 of 280
Service Contract
You may have purchased a service contract for your
vehicle to help protect you from the high cost of
unexpected repairs after your DaimlerChrysler Corpo-
ration’s new vehicle limited warranty expires. The
DaimlerChrysler Corporation stands behind only the
DaimlerChrysler Corporation’s Service Contracts. If
you purchased a DaimlerChrysler Corporation Service
Contract, you will receive Plan Provisions and an
Owner Identification Card in the mail within three
weeks of your vehicle delivery date. If you have any
questions about your service contract, call the
DaimlerChrysler Corporation Service Contract Na-
tional Customer Hotline at 1-800-521-9922.
The DaimlerChrysler Corporation will not stand behind
any service contract that is not the DaimlerChrysler
Corporation’s Service Contract. It is not responsible for
any service contract other than the DaimlerChrysler
Corporation’s Service Contract. If you purchased a ser-
vice contract that is not a DaimlerChrysler Corporation
Service Contract, and you require service after yourDaimlerChrysler Corporation’s new vehicle limited war-
ranty expires, please refer to your contract documents,
and contact the person listed in those documents.
We appreciate that you have made a major investment
when you purchased your new Crossfire. Your dealer has
also made a major investment in facilities, tools, and
training to assure that you are absolutely delighted with
your ownership experience. You’ll be pleased with their
sincere efforts to resolve any warranty issues or related
concerns.
WARRANTY INFORMATION
See your DaimlerChrysler Corporation Warranty Infor-
mation Booklet for more information on warranty cover-
age and transfer of warranty.
252 IF YOU NEED CONSUMER ASSISTANCE
Page 253 of 280
IF YOU NEED CONSUMER ASSISTANCE 253
9
Page 254 of 280
MOPARPARTS
Moparfluids, lubricants, parts, and accessories are
available from your authorized dealer. They will help
you keep your vehicle operating at its best.
REPORTING SAFETY DEFECTS
In the 50 states of the United States and Washington,
D.C.: If you believe that your vehicle has a defect which
could cause a crash or cause injury or death, you should
immediately inform the National Highway Traffic Safety
Administration (NHTSA) in addition to notifying the
DaimlerChrysler Corporation.
If NHTSA receives similar complaints, it may open an
investigation, and if it finds that a safety defect exists in
a group of vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot become involved in
individual problems between you, your dealer, and the
DaimlerChrysler Corporation.To contact NHTSA, you may either call the Auto Safety
Hotline toll-free at 1-800-424-9393 (or 366-0123 in Wash-
ington, D.C. area) or write to: NHTSA, U.S. Dept. of
Transportation, Washington, D.C. 20590. You can also
obtain other information about motor vehicle safety from
the Hotline.In Canada:
If you believe that your vehicle has a safety defect, you
should contact the Customer Service Department imme-
diately. Canadian customers who wish to report a safety
defect to the Canadian government should write to
Transport Canada, P.O. Box 8880, Ottawa Postal Station,
Ottawa, Ontario K1G 3J2.
254 IF YOU NEED CONSUMER ASSISTANCE
Page 255 of 280
PUBLICATION ORDER FORMS
To order the following manuals, you may use either the
website or the phone numbers listed below. Visa, Mas-
tercard, American Express, and Discover orders are ac-
cepted. If you prefer mailing your payment, please call
for an order form.
NOTE:A street address is required when ordering
manuals. (No P.O. Boxes).
•Service Manuals.
These comprehensive service manuals provide the
information that students and professional technicians
need in diagnosing/troubleshooting, problem solving,
maintaining, servicing and repairing DaimlerChrysler
Corporation vehicles. A complete working knowledge
of the vehicle, system and/or components is written in
straightforward language with illustrations, diagrams
and charts.
•Owner’s Manuals.
These manuals have been prepared with the assistance
of service and engineering specialists to acquaint you
with specific Chrysler group vehicles. Included are
starting, operating, emergency and maintenance pro-
cedures as well as specifications, capabilities and
safety tips.
Call Toll Free at1–800–890–4038 (U.S.)or1–800–387–1143
(Canada)
Or
Visit us on the World Wide Web at:
www.techauthority.daimlerchrysler.comor
www.daimlerchrysler.ca/manuals
IF YOU NEED CONSUMER ASSISTANCE 255
9
Page 256 of 280
TIRE SAFETY INFORMATION
Tire Markings
Tire Sizing Chart
NOTE:
P(Passenger)-Metric tire sizing is based on U.S.
design standards. P-Metric tires have the letter“P”
molded into the sidewall preceding the size designation.
Example: P215/65R15 95H.
NOTE:European Metric tire sizing is based on Euro-
pean design standards. Tires designed to this standard
have the tire size molded into the sidewall beginning
with the section width. The letterPis absent from this
tire size designation. Example: 215/65R15 96H.
NOTE:LT(Light Truck)-Metric tire sizing is based on
U.S. design standards. The size designation for LT-Metric
tires is the same as for P-Metric tires except for the letters
“LT”that are molded into the sidewall preceding the size
designation. Example: LT235/85R16.
NOTE:Temporary Spare tires are high pressure com-
pact spares designed for temporary emergency use only.
Tires designed to this standard have the letter“T”
molded into the sidewall preceding the size designation.
Example: T145/80D18 103M.
NOTE:High Flotation tire sizing is based on U.S.
design standards and begins with the tire diameter
molded into the sidewall. Example: 31x10.5 R15 LT.
256 IF YOU NEED CONSUMER ASSISTANCE
Page 257 of 280
EXAMPLE:
Size Designation:
P= Passenger car tire size based on U.S. design standards
...blank...= Passenger car tire based on European design standards
LT= Light Truck tire based on U.S. design standards
T= Temporary Spare tire
31= Overall Diameter in Inches (in)
215= Section Width in Millimeters (mm)
65= Aspect Ratio in Percent (%)
—Ratio of section height to section width of tire.
10.5= Section Width in Inches (in)
R= Construction Code
—Rmeans Radial Construction.
—Dmeans Diagonal or Bias Construction.
15= Rim Diameter in Inches (in)
IF YOU NEED CONSUMER ASSISTANCE 257
9
Page 258 of 280
Service Description:
95= Load Index
—A numerical code associated with the maximum load a tire can carry.
H= Speed Symbol
—A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load
index under certain operating conditions.
—The maximum speed corresponding to the Speed Symbol should only be achieved under specified
operating conditions. i.e. tire pressure, vehicle loading, road conditions and posted speed limits.)
Load Identification:
...blank...= Absence of any text on sidewall of the tire indicates a Standard Load (SL) Tire
Extra Load (XL)= Extra Load (or Reinforced) Tire
Light Load= Light Load Tire
C,D,E= Load range associated with the maximum load a tire can carry at a specified pressure
Maximum Load—Maximum Load indicates the maximum load this tire is designed to carry.
Maximum Pressure—Maximum Pressure indicates the maximum permissible cold tire inflation pressure for this
tire.
258 IF YOU NEED CONSUMER ASSISTANCE
Page 259 of 280
Tire Identification Number (TIN)
The TIN may be found on one or both sides of the tire
however the date code may only be on one side. Tires
with white sidewalls will have the full TIN including
date code located on the white sidewall side of the tire.
Look for the TIN on the outboard side of black sidewall
tires as mounted on the vehicle. If the TIN is not found on
the outboard side then you will find it on the inboard side
of the tire.
EXAMPLE:
DOT MA L9 ABCD 0301
DOT= Department of Transportation
—This symbol certifies that the tire is in com-
pliance with the U.S. Department of Transportation
tire safety standards, and is approved for highway
use.
MA= Code representing the tire manufacturing loca-
tion. (2 digits)
L9= Code representing the tire size. (2 digits)
ABCD= Code used by tire manufacturer. (1 to 4 dig-
its)
03= Number representing the week in which the tire
was manufactured. (2 digits)
—03 means the 3rd week.
01= Number representing the year in which the tire
was manufactured. (2 digits)
—01 means the year 2001.
—Prior to July 2000, tire manufacturers were
only required to have 1 number to represent the year
in which the tire was manufactured. Example: 031
could represent the 3rd week of 1981 or 1991.
IF YOU NEED CONSUMER ASSISTANCE 259
9
Page 260 of 280
Tire Loading and Tire Pressure
Tire Placard Location
NOTE:
Some vehicles have a“Tire and Loading Infor-
mation”placard located on the driver’s side“B”pillar.
Tire and Loading Information Placard
This placard tells you important information about the,
1. number of people that can be carried in the vehicle
2. the total weight your vehicle can carry
3. the tire size designed for your vehicle
4. the cold tire inflation pressures for the front, rear and
spare tires.
260 IF YOU NEED CONSUMER ASSISTANCE
