Page 241 of 280
The use of Special lubricant additives is not recom-
mended. The use of such additives may affect your
warranty rights. With regard to legal stipulations con-
cerning emissions control, please note that engines have
to be serviced and adjusted in accordance with special
instructions and using special measuring equipment.
Modifications to or interference with the emissions con-
trol systems are not permissible.
All DaimlerChrysler Corporation dealers are familiar
with the relevant and applicable regulations.
EMISSION CONTROL SYSTEM MAINTENANCE
The“Scheduled”maintenance services, listed inbold
typemust be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for your Crossfire in severe
operating conditions such as dusty areas and very short
trip driving.Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the
emission control devices and systems on your vehicle
may be performed by any automotive repair establish-
ment or individual using any automotive part which has
been certified pursuant to U.S. EPA or, in the State of
California, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
requiredservice for your vehicle.
Schedule“A”typically rotates with Schedule“B.”Follow
Schedule“A”after the first service interval, Schedule“B”
after the second service interval, and so on. In some cases
where the service interval has been extended due to very
light duty driving, a Schedule“B”service may be indi-
cated following a previous Schedule“B”service. There
are additional service tasks required under Schedule“B.”
MAINTENANCE SCHEDULES 241
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 242 of 280
Your Flexible Service System (FSS)—see Understanding
Your Instrument Panel section—should give you an
exact indication of when your vehicle should be sched-
uled for service and which schedule to follow.
Additional Periodic Maintenanceitems should also be
performed beyond the items listed in the following charts
to assure the optimum performance of your Crossfire.
SCOPE OF WORK FOR“A”SCHEDULE
MAINTENANCE SERVICE
Oil Change
•Change oil and replace filter
Maintenance
•Lubricate hood hinges, latch, and secondary latch
•Reset FSS Display
Function Check
•Horn, hazard warning flashers, turn signals, and indi-
cator lamps
•Headlamps and exterior lighting
•Windshield wipers and washer system
Inspection
•Check front and rear brake pads for lining thickness
•Check tires for damage and general condition
•Check tire inflation pressures and correct if necessary
Fluid Levels
Check fluid levels for the following systems and correct if
necessary. Should there be a loss of fluid that cannot be
explained by regular use, trace and eliminate the cause.
•Engine cooling system (check corrosion inhibitor/
antifreeze)
•Hydraulic brake system
•Power steering system
•Windshield washer system
242 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 243 of 280
SCOPE OF WORK FOR“B”SCHEDULE
MAINTENANCE SERVICE
Oil Change
•Change oil and replace filter
Maintenance
•Rotate tires
•Replace dust filter
•Lubricate hood hinges, latch, and secondary latch
•Reset FSS Display
Function Check
•Horn, hazard warning flashers, turn signals, and indi-
cator lamps
•Headlamps and exterior lighting
•Windshield wipers and washer system
•Check seat belts for damage and proper function
•Test hydraulic brakes and check parking brake func-
tionInspection
•Check front and rear brake pads for lining thickness
•Check condition of front and rear brake discs
•Check tires for damage and general condition
•Check tire inflation pressures and correct if necessary
•Check major underbody components for leakage or
damage (if there are signs of leakage, determine cause
and repair)
•Check condition of front axle ball joints and rubber
boots
•Check condition of steering components and rubber
boots
•Check underhood components for leakage or damage
(if there are signs of leakage determine cause and
repair)
•Check condition of accessory drive belt
•Check headlamp aiming, adjust if necessary
•Check windshield wiper blades, replace if necessary
MAINTENANCE SCHEDULES 243
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 244 of 280
Fluid Levels
Check fluid levels for the following systems and correct if
necessary. Should there be a loss of fluid that cannot be
explained by regular use, trace and eliminate the cause.
•Engine cooling system (check corrosion inhibitor/
antifreeze)
•Hydraulic brake system
•Power steering system
•Windshield washer system
FSS SYSTEM
The Flexible Service System (FSS) permits a flexible
service schedule that is directly related to the operating
conditions of the vehicle. See the Understanding Your
Instrument Panel section for details on how to use the
FSS.The oil change interval for your Crossfire is initially set at
7,000 miles (Canada: 11,000 km). Very light duty driving
cycles (most trips more than 10 miles [16 km] at moderate
speeds in moderate temperature conditions) can extend
the service interval beyond 7,000 miles (Canada: 11,000
km). IfANYof the following apply to your driving, the
oil change interval can be reduced significantly:
Day or night temperatures are below 32°F (0°C).
Stop and go driving.
Extensive engine idling.
Driving in dusty conditions.
Short trips of less than 10 miles (16 km).
More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
244 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 245 of 280
There are two symbols which will appear in the main
odometer display field prior to the next suggested ser-
vice.
This symbol represents Service A.
This second symbol represents Service B. Ser-
vice B rotates with Service A and includes
additional service tasks.
The next service is normally calculated and
displayed next to the Service A or Service B
symbol as distance remaining before the next
service is required.
Depending on operating conditions through-
out the year, a clock symbol may appear next to
the service symbol. When this occurs, the next
service is calculated and displayed in days
remaining before the next service is required.You should have the maintenance performed within the
stated time period or distance.
Following a completed A or B service your authorized
dealer sets the counter to 7,000 miles (Canada: 11,000
km).
NOTE:When disconnecting vehicle battery for one or
more days at a time, such days will not be counted. Any
such days not counted by FSS can be added by your
authorized dealer.
The interval between services is determined by the type
of vehicle operation. Driving at extreme speeds, and cold
starts combined with short distance driving in which the
engine does not reach normal operating temperature,
reduce the interval between services.
Regardless of the service interval determined by your
FSS, the scheduled services as posted in this manual must
be followed to properly care for your vehicle.
MAINTENANCE SCHEDULES 245
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 246 of 280
REGULAR CHECK-UPS
To maintain the safe operation of your vehicle, it is
recommended that you perform the following tasks on a
regular basis (i.e., weekly or whenever the vehicle is
refueled).
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
•
Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. See the procedure de-
scribed in Checking Your Engine Oil in the Under-
standing Your Instrument Panel section or under
Engine Oil in the Maintaining Your Vehicle section.
Add oil only when the level is at or below the ADD or
MIN mark.
•Check the windshield washer solvent and add if
required.
•Inspect wiper blade condition.
•Check operation of lighting systems.
•Inspect tires for unusual wear, damage, and pressure
(at least every 14 days).
•Mechanical assemblies (e.g., engine, transmission, etc.)
- check for leaks.
Once a Month
•
Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder and power steering and add as
needed.
•Check all lights and all other electrical items for correct
operation.
246 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 247 of 280
Additional Periodic Maintenance
The following maintenance items should be performed
during the scheduled maintenance nearest the time
elapsed and/or distance shown. Follow the interval that
occurs first.
Every 2 years:
•Inspect body for paint damage.
•Check chassis and supporting body parts for damage
and corrosion.
At approximately every 50,000 miles (80,000 km) or 4
years:
•Check condition of driveshaft flex discs.
•Retighten locking bolts for steering (observe torque).
At approximately every 60,000 miles (96,000 km) or 4
years:
•Replace fuel filter.
•Replace air cleaner filter element.At approximately 80,000 miles (129,000 km):
•Change the automatic transmission fluid and filter.
Use the recommended automatic transmission fluid.
After this change it is filled for life.
At approximately every 100,000 miles (161,000 km) or 5
years:
•Replace spark plugs.
Every 100,000 miles (161,000 km) or 5 years:
•Replace engine coolant using coolant approved to MB
325.0, such as Valvoline GO5, or an equivalent ex-
tended life coolant.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
maintenance service, take your vehicle to a compe-
tent technician.
MAINTENANCE SCHEDULES 247
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 248 of 280
SPECIAL MAINTENANCE REQUIREMENTS
Coolant
Have the corrosion inhibitor/antifreeze concentration in
the coolant checked before the onset of winter (once a
year in countries with high prevailing temperatures).
Have the coolant replaced every five years or 100,000
miles (161,000 km).
Dust Filter for Heating/Ventilation Replacement
The dust filter is replaced during routine maintenance
service. The filter element must be replaced with“B”
Schedule service or every 18,500 miles (30,000 km) to
maintain effectiveness. However, if operating conditions
are dusty, these filters should be replaced more fre-
quently. A cover in the HVAC unit that can be reached
from the passenger foot well provides access to the filter
element.
ENGINE OIL CHANGE AND FILTER
REPLACEMENT
The recommended oil and filter change interval is based
on FSS or 1 year. Please refer to the heading FSS System
in this section for a full description of the use and
interpretation of symbols in the FSS system. Only use
synthetic engine oils, approved to MB 229.3 or MB 229.5,
such as Mobil 1 SAE 0W-40. The FSS may not alert for an
oil change at the proper interval if an unapproved engine
oil is used; engine damage and reduced engine life may
result. Information is available from your authorized
dealer. The oil filter should always be changed when the
oil is changed.
248 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 249 of 280
IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
Suggestions For Obtaining Service For Your
Vehicle
..............................250
▫Prepare For The Appointment............250
▫Prepare A List........................250
▫Be Reasonable With Requests.............250
If You Need Assistance..................250
Warranty Information...................252
MoparParts.........................254
Reporting Safety Defects.................254
▫In Canada..........................254
Publication Order Forms.................255
Tire Safety Information..................256
▫Tire Markings........................256
▫Tire Identification Number (TIN)..........259
▫Tire Loading And Tire Pressure...........260
9
Page 250 of 280
SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty; discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a valuable clue to
the current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with the
service advisor and list the items in order of priority. At
many dealers you may obtain a rental vehicle at a minimal
daily charge. If you need a rental, it is advisable to make
these arrangements when you call for an appointment.
IF YOU NEED ASSISTANCE
DaimlerChrysler and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Your selling dealer is best equipped and most anxious to
provide prompt resolution for any warranty issue or
related matter that you may experience. Authorized
dealers have the facilities, factory-trained technicians,
special tools, and the latest information to assure your
vehicle is fixed correctly and in a timely manner.
DaimlerChrysler has empowered its dealers to make
warranty and repair decisions that ensure you are not
inconvenienced. There is no need for you to wait for a
decision from the DaimlerChrysler Corporation. If a
special circumstance occurs that requires information
from the DaimlerChrysler Corporation, we have asked
the dealer’s service management to make the contact on
your behalf.
This is why you should always talk to your dealer’s
service manager first. Most matters can be resolved with
this process.
250 IF YOU NEED CONSUMER ASSISTANCE
