Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet could be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.
Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.
ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the engine in
your new vehicle.
Drive moderately during the first 300 miles (500 km).
After the initial 60 miles (100 km), speeds up to 50 or 55
mph (80 or 90 km/h) are desirable.
While cruising, brief full-throttle acceleration, within the
limits of local traffic laws, contributes to a good break-in.
Wide open throttle acceleration in low gear can be
detrimental and should be avoided.The engine oil installed in the engine at the factory is a
high quality energy conserving type lubricant. Oil
changes should be consistent with anticipated climate
conditions under which vehicle operations will occur.
The recommended viscosity and quality grades are
shown in Section 7 of this manual. NON-DETERGENT
OR STRAIGHT MINERAL OILS MUST NEVER BE
USED.
A new engine may consume some oil during its first few
thousand miles (kilometers) of operation. This should be
considered as a normal part of the break-in and not
interpreted as an indication of difficulty.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61
2

SAFETY TIPS
Exhaust Gas
WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow the safety tips below.
Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in or
out of the area.
If it is necessary to sit in a parked vehicle with the engine
running, adjust your heating or cooling controls to force
outside air into the vehicle. Set the blower at high speed.
WARNING!
If you are required to drive with the liftgate open,
make sure that all windows are closed, and the
climate control blower switch is set at high speed.
DO NOT use the recirculation mode.
Safety Checks You Should Make Inside The
Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Front seat belt assemblies must be replaced after a
collision. Rear seat belt assemblies must be replaced after
a collision if they have been damaged (bent retractor, torn
webbing, etc. If there is any question regarding belt or
retractor condition, replace the belt.
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Airbag Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned ON. If the LED is not lit during starting, have it
checked. If the light stays on or comes on while driving,
have the system checked by an authorized dealer.
Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield.
Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect tread and sidewall for cuts or
cracks. Check wheel nuts for tightness, and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil or other fluid leaks. Also, if gasoline
fumes are detected or fuel, power steering fluid or brake
fluid leaks are suspected, the cause should be located and
corrected immediately.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63
2

UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
mMirrors...............................69
NInside Day/Night Mirror.................69
NAutomatic Dimming Mirror Ð If Equipped....70
NDriver's Side Outside Mirror Auto Dimmer Ð If
Equipped............................70
NExterior Mirrors Folding Feature...........70
NOutside Mirror Ð Driver's Side............71
NOutside Mirror Ð Passenger's Side..........71
NPower Remote-Control Mirrors.............72NHeated Remote Control Mirrors............72
NIlluminated Vanity Mirrors................73
mHands±Free Communication (UConnectŸ) Ð If
Equipped.............................73
NOperation............................75
NPhone Call Features....................79
NAdvanced Phone Connectivity.............81
NUConnectŸ System Features..............82
3

mSeats.................................85
N10±Way Driver's Power Seat Ð If Equipped . . .85
N8±Way Driver's Power Seat Ð If Equipped....85
N4±Way Passenger's Power Seat.............85
NAdjustable Head Restraints...............86
NHeated Seats Ð If Equipped..............86
NMemory Seat Ð If Equipped..............88
NSecond Row Manual Seat Recliner..........91
NSecond Row Manual Seat Adjuster..........92
NSecond Row Fold & Tumble Seats...........93
NThird Row Easy Exit....................94
NThird Row Seating Flexibility..............96
NLoad Floor...........................97NPlastic Grocery Bag Retainer..............98
mAdjustable Pedals Ð If Equipped............99
mTo Open And Close The Hood.............100
mLights...............................102
NOverhead Console Map/Reading Lights.....102
NInterior Lights.......................103
NMulti-Function Lever...................103
NHeadlights, Parking Lights, Instrument Panel
Lights.............................103
NAutomatic Headlights..................105
NDaytime Running Lights (Canada Only).....105
NLights-On Reminder...................105
NHeadlight Time Delay..................105
66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NFog Lights Ð If Equipped...............106
NTurn Signals.........................106
NHighbeam/Lowbeam Select Switch.........107
NPassing Light........................107
mWindshield Wipers And Washers...........107
NWindshield Washers...................107
NMist Feature.........................108
NWindshield Wiper Operation.............108
NIntermittent Wiper System...............108
NRear Window Wiper/Washer.............108
mTilt Steering Column....................110
mTraction Control Switch Ð If Equipped.......110
mElectronic Speed Control..................111NTo Activate..........................112
NTo Set At A Desired Speed...............112
NTo Deactivate........................112
NTo Resume Speed.....................113
NTo Vary The Speed Setting...............113
NTo Accelerate For Passing...............113
mOverhead Console Ð If Equipped...........114
NCourtesy/Reading Lights................114
NSunglasses Storage....................115
mGarage Door Opener Ð If Equipped.........115
NProgramming Homelink................116
NCanadian Programming/Gate Programming . . 118
NUsing Homelink......................119
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
3

NErasing Homelink Buttons...............119
NReprogramming a Single Homelink Button . . . 120
NSecurity............................120
mPower Sunroof Ð If Equipped.............121
NExpress Open Feature..................122
NWind Buffeting.......................123
NSunroof Maintenance...................123
mElectrical Power Outlets..................124
NElectrical Outlet Use With Engine Off.......125
mCupholders...........................126NFront Seat Cupholders..................126
NSecond Row Seat Cupholders.............126
NThird Row Seat Cupholders..............126
mStorage..............................126
NConsole Features......................126
NRear Cargo Storage Bin.................127
NRetractable Cargo Area Cover Ð If Equipped . 127
NCargo Tie-Down Hooks.................128
mRoof Luggage Rack Ð If Equipped..........130
mLoad Leveling System...................132
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Inside Day/Night Mirror
Adjust the mirror to center on the view through the rear
window. A two point pivot system allows for horizontal
and vertical adjustment of the mirror.Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 69
3

Automatic Dimming Mirror Ð If Equipped
If the switch is in the ªAutoº position the mirror will
automatically adjust for annoying headlight glare from
vehicles behind you. You can turn the feature on or off by
pressing the button at the base of the mirror. A light in the
mirror will illuminate to indicate when this feature is on.CAUTION!
To avoid damage to the mirror during cleaning,
never spray any cleaning solution directly onto the
mirror. Apply the solution onto a clean cloth and
wipe the mirror clean.
Driver's Side Outside Mirror Auto Dimmer Ð If
Equipped
This mirror automatically adjusts for annoying headlight
glare from vehicles behind you. You can turn this feature
on or off by pressing the button at the base of the
Rearview Mirror.
Exterior Mirrors Folding Feature
All exterior mirrors are hinged and may be moved either
forward or rearward to resist damage. The hinges have
three detent positions; full forward, full rearward, and
normal.
