CHRYSLER PACIFICA 2005 1.G Owners Manual

Miles 93, 000 96, 000 99, 000 100, 000 102, 000 105, 000
(Kilometers) (149 000) (154 000) (158 000) (160 000) (163 000) (168 000)
Change engine oil and engine oil filter. X X X X X
Rotate Tires X X
Inspect the brake linings. X
Inspect the engine air cleaner filter, replace if
necessary. *XXXXX
Replace theengine air cleaner filter*X
Replace engine timing belt.X
Change the All Wheel Drive (AWD) power
transfer unit fluid. (See note at the end of this
chart)X
Change the All Wheel Drive (AWD) overrun-
ning clutch and rear carrier fluid. (See note at
the end of this chart)X
Inspect the serpentine drive belt, replace if
necessary. ‡X
SCHEDULE “B” 341
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93, 000 96, 000 99, 000 100, 000 102, 000 105, 000
(Kilometers) (149 000) (154 000) (158 000) (160 000) (163 000) (168 000)
Flush and replace the engine coolant at 60
months or 100,000 miles.X
Replace the air conditioning filter. X
Miles 108, 000 111, 000 114, 000 117, 000 120, 000
(Kilometers) (173 000) (178 000) (182 000) (187 000) (192 000)
Change engine oil and engine oil filter.XXXX X
Rotate Tires X X X
Inspect the brake linings. X X
Inspect the engine air cleaner filter, replace if neces-
sary. *XXXX
Replace theengine air cleaner filter.X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Inspect thePCV valveand replace as necessary.* X
342 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108, 000 111, 000 114, 000 117, 000 120, 000
(Kilometers) (173 000) (178 000) (182 000) (187 000) (192 000)
Inspect the serpentine drive belt, replace if neces-
sary. ‡X
Change the automatic transmission fluid and filter. X
Change the All Wheel Drive (AWD) power transfer
unit fluid. (See note at the end of this chart)X
Replace the air conditioning filter. X X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.NOTE:The AWD power transfer unit fluid and the
AWD overrunning clutch/ rear carrier fluid must be
changed at the more frequent intervals shown in sched-
ule B if the vehicle is operated under any of the condi-
tions noted by a diamond () at the beginning of the
schedule.
SCHEDULE “B” 343
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE “A”
Miles 6, 000 12, 000 18, 000 24, 000 30, 000 36, 000
(Kilometers) (10 000) (19 000) (29 000) (38 000 ) (48 000) (58 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter. XXXXXX
Rotate Tires XXXXXX
Inspect the brake linings. X X
Inspect the engine air cleaner filter, replace if
necessary. *X XXX X
Replace theengine air cleaner filter.X
Inspect the tie rod ends and boot seals. (Front
& Rear)X
Replace the air conditioning filter. X X X
344 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 42, 000 48, 000 54, 000 60, 000 66, 000 72, 000
(Kilometers) (67 000) (77 000) (86 000) (96 000) (106 000) (115 000)
[Months] [42] [48] [54] [60] [66] [72]
Change engine oil and engine oil filter. X XXXXX
Rotate Tires X XXXXX
Inspect the brake linings. X X
Inspect the engine air cleaner filter, replace if
necessary. *XXX XX
Replace theengine air cleaner filter.X
Inspect the tie rod ends and boot seals. (Front
& Rear)X
Check thePCV valve
and replace, if
necessary.*X
Inspect the serpentine drive belt, replace if
necessary. ‡XX
Flush and replace the engine coolant at 60
months, regardless of mileage.X
Replace the air conditioning filter. X X X
SCHEDULE “A” 345
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78, 000 84, 000 90, 000 96, 000 100, 000
(Kilometers) (125 000) (134 000) (144 000) (154 000) (160 000)
[Months] [78] [84] [90] [96]
Change engine oil and engine oil filter. X X X X
Rotate Tires X X X X
Inspect the brake linings. X
Inspect the engine air cleaner filter, replace if
necessary. *XX XX
Replace theengine air cleaner filter.X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Check and replace thePCV valve
, if necessary.*X
Inspect the serpentine drive belt, replace if
necessary. ‡X
Replace thespark plugs
3.5 liter engines.X
Flush and replace the engine coolant at 100,000
miles, if not done at 60 months.X
Replace the air conditioning filter. X X
346 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 102, 000 108, 000 114, 000 120, 000
(Kilometers) (163 000) (173 000) (182 000) (192 000)
[Months] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X X
Rotate Tires X X X X
Inspect the brake linings. X
Inspect the engine air cleaner filter, replace if necessary. * X X X
Replace theengine air cleaner filter.X
Replace engine timing belt. X
Inspect the tie rod ends and boot seals. (Front & Rear) X
Check thePCV valve
and replace, if necessary.*X
Inspect the serpentine drive belt, replace if necessary. ‡ X X
Flush and replace the engine coolant at 120 months, if not
done at 100,000 miles (160 000 km).X
Replace the air conditioning filter. X X
SCHEDULE “A” 347
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
348 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For Your
Vehicle..............................350
▫Prepare For The Appointment............350
▫Prepare A List........................350
▫Be Reasonable With Requests.............350

If You Need Assistance...................350

Warranty Information....................353

MoparParts.........................355
Reporting Safety Defects..................355
▫In Canada..........................355

Publication Order Forms..................356

Department Of Transportation Uniform Tire
Quality Grades........................357
▫Treadwear..........................357
▫Traction Grades......................357
▫Temperature Grades...................358
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Your selling dealer is best equipped and most anxious to
provide prompt resolution for any warranty issue or
related matter that you may experience. The manufactur-
er’s dealers have the facilities, factory-trained techni-
cians, special tools, and the latest information to assure
your vehicle is fixed correctly and in a timely manner.
