CHRYSLER PACIFICA 2006 1.G Owners Manual

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instruments And Controls .................165

Base Instrument Cluster ..................166

Premium Instrument Cluster ...............167

Instrument Cluster Descriptions ............168

Electronic Vehicle Information Center (EVIC) —
If Equipped ...........................176
▫ Customer Programmable Features —
If Equipped .........................179
▫ Tilt Mirrors In Reverse?
(Available With Memory Seat Only) ........183 ▫
Compass Display — If Equipped ..........183
▫ Mini-Trip Functions — If Equipped ........185

Setting The Analog Clock .................186

Electronic Digital Clock ..................186
▫ Clock Setting Procedur e.................186

Sales Code RAH—AM & FM Stereo Radio With
CD Player And CD/DVD Changer Controls ....187
▫ Radio Operation ......................187
▫ CD Player Operation ...................1914

▫CD/DVD Changer Operation .............193
▫ Notes On Playing MP3 Files .............193
▫ Operation Instructions - (CD Mode For MP3
Audio Play) .........................195

Sales Code Rev AM & FM Stereo Radio With
CD Player And CD/DVD Changer Controls ....197
▫ Radio Operation ......................197
▫ CD Player Operation ...................201
▫ CD/DVD Changer Operation .............203
▫ Notes On Playing MP3 Files .............203
▫ Operation Instructions - (CD Mode For MP3
Audio Play) .........................205

Sales Code RBP—AM & FM Stereo Radio With
Cassette Tape Player, CD Player, And Optional
CD/DVD Changer Controls ...............207 ▫
Radio Operation ......................207
▫ Tape Player Operation ..................211
▫ CD Player Operation ...................213
▫
CD/DVD Changer Operation — If Equipped. . 215

Remote Control Operating Instructions .......216
▫ Headphone Transmitter Button (1) .........218
▫ Arrow Buttons (2, 3, 15, 16) ..............218
▫ Rtn Button (4) ........................218
▫ Setup Button (5) ......................218
▫ Pause/Play Button (6) ..................219
▫ Mute Button (7) ......................219
▫ Disp Button (8) .......................219
▫ Mode Button (9) ......................219
162 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Prog Up/Down Buttons (10, 11) ...........219
▫ Slow Button (12) ......................219
▫ Stop Button (13) ......................219
▫ Menu Button (14) .....................219
▫ Next/Prev Buttons (2, 15) ...............220
▫ FF/RW Buttons (3, 16) ..................220
▫ Enter Button (17) .....................220
▫ Light Button (18) ......................220
▫ Remote Control Battery Service ...........220
▫ Operating Instructions — Video Screen ......221
▫ Operating Instructions — Headphones ......222
▫ Operating Instructions — MP3 Player, Portable
Walkman ...........................224 ▫
Operating Instructions — Video
Games/Camcorders ...................225

Satellite Radio — If Equipped ..............225
▫ System Activation .....................225
▫ Electronic Serial Number/Sirius Identification
Number (ENS/SID) ....................226
▫ Selecting Satellite Mode In RBB, Rev And RBK
Radios .............................226
▫ Selecting Satellite Mode In RBP, RBU, RAZ,
RB1 And RBQ Radios ..................227
▫ Selecting a Channel ....................227
▫ Storing And Selecting Pre-Set Channels ......228
▫ Using The PTY (Program Type) Button
(If Equipped) ........................228
▫ PTY Button Scan.....................228
UNDERSTANDING YOUR INSTRUMENT PANEL 163
4

▫PTY Button Seek.....................228
▫ Satellite Antenna ......................228
▫ Reception Quality .....................229

Remote Sound System Controls .............229
▫ Radio Operation ......................230
▫ Tape Player .........................230
▫ CD Player ..........................230

Radio General Information ................231
▫ Radio Broadcast Signals .................231
▫ Two Types Of Signals ..................231
▫ Electrical Disturbances ..................231
▫ AM Reception .......................231 ▫
FM Reception ........................231

Cassette Tape And Player Maintenance .......232

CD/DVD Disc Maintenance ...............233

Radio Operation And Cellular Phones ........233

Navigation System — If Equipped ...........233

Climate Controls .......................234
▫ Manual Air Conditioning And Heating
System .............................235
▫ Mode Control ........................236
▫ Manual Air Conditioning Operation ........240
▫ Dual-Zone Automatic Temperature Control . . . 243
▫ Electric Rear Window Defroster ...........253
164 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENTS AND CONTROLS
UNDERSTANDING YOUR INSTRUMENT PANEL 165
4

BASE INSTRUMENT CLUSTER
166 UNDERSTANDING YOUR INSTRUMENT PANEL

PREMIUM INSTRUMENT CLUSTER
UNDERSTANDING YOUR INSTRUMENT PANEL 167
4

INSTRUMENT CLUSTER DESCRIPTIONS
1. Voltage Light This light monitors the electrical system voltage.
The light should turn on momentarily as the
engine is started. If the light stays on or turns on while
driving, it indicates a problem with the charging system.
Immediate service should be obtained.
2. Temperature Gauge
The temperature gauge shows engine coolant tempera-
ture. Any reading within the normal range indicates that
the engine cooling system is operating satisfactorily.
The gauge pointer will likely indicate a higher tempera-
ture when driving in hot weather, up mountain grades,
or when towing a trailer. It should not be allowed to
exceed the upper limits of the normal operating range.
CAUTION!
Driving with a hot engine cooling system could
damage your vehicle. If temperature gauge reads (H),
Pull over in a safe area as soon as possible and stop
the vehicle. Idle the vehicle with the air conditioner
turned off until the pointer drops back into the
normal range. If the pointer remains on the “H”, and
you hear continuous chimes, turn the engine off
immediately, and call for service.
168 UNDERSTANDING YOUR INSTRUMENT PANEL

WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
3. Fuel Gauge
The pointer shows the level of fuel in the fuel tank when
the ignition switch is in the ON position.The Low Fuel Light will turn on when the fuel level
reaches approximately 2 to 4 gallons (7 to 15 liters)
this light will remain on until fuel is added. 4. Turn Signal Indicators
The arrow will flash with the exterior turn signal
when the turn signal lever is operated.
If the vehicle electronics sense that the vehicle has
traveled about one mile with the turn signals on, a chime
will sound to alert you to turn the signals off. If either
indicator flashes at a rapid rate, check for a defective
outside light bulb.
5. Speedometer
Indicates vehicle speed.
6. Anti-Lock Light This light monitors the Anti-Lock Brake Sys-
tem. The light will turn on when the ignition
switch is turned to the ON position and may
stay on for as long as four seconds.
If the ABS light remains on or turns on while driving, it
indicates that the Anti-Lock portion of the brake system
UNDERSTANDING YOUR INSTRUMENT PANEL 169
4

is not functioning and that service is required. However,
the conventional brake system will continue to operate
normally if the BRAKE warning light is not on.
If the ABS light is on, the brake system should be serviced
as soon as possible to restore the benefits of Anti-Lock
brakes. If the ABS light does not turn on when the
Ignition switch is turned to the ON position, have the
light inspected by an authorized dealer.
7. Brake System Warning Light This light monitors various brake functions,
including brake fluid level and parking brake
application. If the brake light turns on, it may
indicate that the parking brake is applied, there
is a low brake fluid level or there is a problem with the
anit-lock brake system.
The dual brake system provides a reserve braking capac-
ity in the event of a failure to a portion of the hydraulic
system. Failure of either half of the dual brake system is indicated by the Brake Warning Light which will turn on
when the brake fluid level in the master cylinder has
dropped below a specified level.
The light will remain on until the cause is corrected.
NOTE:
The light may flash momentarily during sharp
cornering maneuvers which change fluid level condi-
tions. The vehicle should have service performed.
If brake failure is indicated, immediate repair is neces-
sary.
WARNING!
Driving a vehicle with the brake light on is danger-
ous. Part of the brake system may have failed. It will
take longer to stop the vehicle. You could have an
accident. Have the vehicle checked immediately.
