CHRYSLER PACIFICA HYBRID 2017 2.G Owners Manual

Users can select content for each screen from the radio by
choosing desired content from drop down menu.
NOTE:Use the “View Screen” function to pull content
from one screen to the other in a single press of a button.
Doing this however will disable and gray out certain
player controls on the screen viewing the other screen’s
content.
Uconnect Theater Remote Control
1. Gesture Pad — Control mouse pointer position in this
area to move and select items on the touchscreen,
functions similar to a mouse.
2. Mute Button — Mutes headphone audio.
3. Home Button — Push to access “Sources”.
4. Arrow Buttons — Push the arrow
buttons
to highlight an item or scroll through menus.
5. Fast Forward Button— Push and hold to fast
forward through the current audio track or video
chapter. Push once to skip to the next track.
6. Play/Pause Button— Begin/resume or pause
disc play.
7. Fast Rewind Button— Push and hold to fast
rewind through the current audio track or video
chapter. Push once to revert back to the previous
track.
8. OK Button — Push to select the highlighted option in a
menu.
9. Screen Selector Button — Push the screen selector to
toggle between screen 1 (Driver Side), or screen 2
(Passenger Side).
Remote Control
10
MULTIMEDIA 529

10.Back Button — Push to exit out of menus or return to
previous screen.
11 . Power Button — Turns the screen and wireless head-
phone transmitter for the selected Channel on or off.
12. Screen Indicator — Indicates which screen (1 or 2) is
being controlled by the remote control when a button is
pushed.
Replacing The Remote Control Batteries
Each remote control requires two AAA batteries for opera-
tion.
To replace the batteries:
1. Locate the battery compartment on the back of the remote, then slide the battery cover downward.
2. Remove the old batteries and follow battery recycling procedures for your area.
3. Install new batteries, making sure to orient them accord- ing to the polarity diagram shown inside the battery
compartment.
4. Replace the battery compartment cover.
Uconnect Theater Home Screen And Controls
Uconnect Theater Home Screen
1 — Search Button (Media
Search)
2 — Power Button
3 — Settings Button
4 — Toggle Button List and Icon
Vi e w5 — Source Card Page Indicator
6 — Wired Headphone Volume
7 — Climate Control Button
8 — Home Button
9 — Source Cards
530 MULTIMEDIA

You can choose sources such as HDMI, USB, Apps, or
Blu-ray. You may also view content of the opposite screen
in one step by choosing the “View Screen” source card.
NOTE:
•Source card order can be changed by pressing the
Settings button on the touchscreen and scrolling down
to Source Card Order.
• Use the “View Screen” function to pull content from one
screen to the other. Doing this however will disable and
gray out certain player controls. General Settings
To change source card order, select “Source Card Reorder”,
then press and hold source card on the touchscreen, and
drag and drop in desired order.
You can also adjust the following below and more.
•
Brightness
• Media port lighting on and off
• Clock on and off
NOTE: System information can also be displayed under
General Settings.
Remote Settings
Under this setting, you can access the following:
• Manage Remotes
• Pair Remote
• Remote sensitivity (This adjusts the speed and sensi-
tivity of cursor on screen when using gesture pad)
Source Card Selection
10
MULTIMEDIA 531

Play A DVD/Blu-ray Or USB Media File From
Uconnect System
1. Insert a Blu-ray disc or DVD disc into the disc playerwith the label facing up. Or insert a USB drive into rear
Video USB port.
NOTE: The DVD/Blu-ray Disc player and Video USB port
are both located under the radio controls in the instrument
panel.
2. Press the “Uconnect Theater” button on the radio touch- screen.
Refer to “Accessing The System From The Uconnect Ra-
dio” in this section for further information.
3. Select Disc or USB from the source controls on the desired screen (1 or 2).
NOTE: To play a DVD/Blu-ray disc on both screens
simultaneously, select disc from both screen drop downs,
or choose disc source on one screen and push “View
Screen” button on the other.
4. For DVD/Blu-ray disc – press Movie Snapshot on radio touchscreen, then press “OK” on following screen. For
USB Media Files - Press Music, Movie, or Folders, then
select media title from list(s).
DVD Blu-ray Disc Player
1 — Disc Player (Rear)
2 — Rear Video USB Port
532 MULTIMEDIA

NOTE:Control functions apply to individual screen se-
lected displayed on touchscreen.
1. Power
Press to turn “selected Screen” On/Off.
2. Mute
Mute rear headphones for selected source for the current
ignition cycle. Pressing mute again will unmute rear head-
phones.
Source Controls — Uconnect Radio
Media Control Screen
10
MULTIMEDIA 533

3.Lock
Press to enable/disable Remote Control functions and
Touchscreen Controls for the selected source.
4. View
Select this button to full screen video if vehicle is not
moving. Button is disabled when not viewing a video
source or when the vehicle is in motion.
To view a Blu-ray disc on the Uconnect radio, select the
Disc source from drop down menu, and then select the
“View” button while in the selected screen controls.
NOTE: To view video content on the radio screen, bring the
vehicle to a stop.
Blu-ray Controls – Disc Specific Functions
The four colored buttons (red, green, blue, yellow) are
designed for use with certain Blu-ray disc movie titles to
access particular features or software on the disc. See the
documentation provided with your Blu-ray disc movie to
see if these buttons can be used. The 5-way control buttons
located to the right of the four colored buttons, are used to
navigate and select items in the disc’s menu, like play
movie, scene selection, etc.
Blu-ray Controls – Disc Specific Functions
1 — Red Button
2 — Green Button
3 — Blue Button4 — Yellow Button
5 — 5-Way Control Buttons
534 MULTIMEDIA

Uconnect Theater Apps
Select the Apps source card to play pre-loaded games.
Pressing the “Help” button teaches users how to play each
game. Pick from games:
•Back Seat Bingo
• Checkers
• Hanging Fruit
• License Plate Game
• Math Flash Cards
• Solitaire
Apps Home Screen
Sudoku App Home Screen
10
MULTIMEDIA 535

•Sudoku
• Tic Tac Toe
NOTE: To exit a game, push “Exit Button” than “Back
Arrow,” or “Home Button” on the touchscreen.
Are We There Yet? — Uconnect 8.4 NAV When a navigation route has been set from the Uconnect
radio, the second row passengers can use “Are We There
Yet?” for an animated screen showing distance and time
remaining on navigation routes as well as the estimated
time of arrival with pop-up notifications. Notifications and
frequency can be set up for route information while in
other Uconnect Theater screens too.
NOTE:
Estimated time of arrival notifications will pop-up
at the bottom of the screen in the center when on any
screen.
Are We There Yet? App
1 — Decrease Timing Between Notifications Button
2 — Notifications ON/OFF Button
3 — Increase Timing Between Notifications Button 536 MULTIMEDIA

Using The Rear Video USB Port
Plug in a jump drive, iPhone, iPod or mass storage device
and play your favorite music or movies.
NOTE:To view USB media on the rear theater screens,
insert a USB jump drive into the port next to the DVD/
Blu-ray disc player. The USB jump drive port is located
under the radio controls in the instrument panel. Use the search feature to find your music faster.
Rear Video USB Port
Search Screen
10
MULTIMEDIA 537

Play Video Games
Connect the video game console to the HDMI 1 or 2 ports,
located behind the first row seat.
NOTE:Certain high-end video games will exceed the
power limit of the vehicle’s Power Inverter. Refer to
“Power Inverter” in “Getting To Know Your Vehicle” in
this guide for further information.
Headphones Operation
The headphones receive two separate channels of audio
using an infrared transmitter from the video screens.
If no audio is heard after increasing the volume control,
verify that the screen is turned on, the channel is not
muted, the headphones are on, and that the headphone
channel selector button is on the desired channel. The
channel selector button switches between the audio of
screen 1 and screen 2. If audio is still not heard, check that
two new AAA type batteries are installed in the head-
phones.
AUX/HDMI/USB
1 — AUX Jack (Headphone Output Only)
2 — HDMI Port
3 — USB Port (Charge Only) 538 MULTIMEDIA
