engine CHRYSLER PT CRUISER 2005 1.G Owners Manual

Miles 42,000 48,000 54,000 60,000 66,000
(Kilometers) (67 000) (77 000) (86 000) (96 000) (106 000)
[Months] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter.XXXXX
Rotate tires.XXXXX
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace, if necessary.* X
Flush and replace the engine coolant at 60 months, if
not done at 102,000 miles.X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
330 SCHEDULE “A”—NON TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 72,000 78,000 84,000 90,000 96,000 102,000
(Kilometers) (115 000) (125 000) (134 000) (144 000) (154 000) (164 000)
[Months] [72] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X XXXXX
Rotate tires. X XXXXX
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary.
Not required if previously changed. * ‡X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
Flush and replace the engine coolant, if not
replaced at 60 months.X
SCHEDULE “A”—NON TURBO 331
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles108,000 114,000 120,000
(Kilometers) (173 000) (182 000) (192 000)
[Months] [108] [114] [120]
Change engine oil and engine oil filter. X X X
Rotate tires. X X X
Inspect thePCV valveand replace if necessary. * ‡ X
Replace theair cleaner filter.X
Replace theengine timing belt.*X
Flush and replace the engine coolant at 120 months, if not done at
102,000 miles.X
Replace thespark plugs and ignition cables.X
Replace theMake-up air filter.X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
332 SCHEDULE “A”—NON TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE “A”—TURBO
Miles 5,000 10,000 15,000 20,000 25,000 30,000
(Kilometers) (8 000) (16 000) (24 000) (32 000) (40 000) (48 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter. XXXXXX
Rotate tires. XXXXXX
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
SCHEDULE “A”—TURBO 333
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 35,000 40,000 45,000 50,000 55,000
(Kilometers) (56 000) (64 000) (72 000) (80 000) (88 000)
[Months] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter.XXXXX
Rotate tires.XXXXX
Inspect the brake linings. X
Flush and replace engine coolant at 60 months, if not
replaced at 100,000 miles.X
334 SCHEDULE “A”—TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 60,000 65,000 70,000 75,000 80,000 85,000
(Kilometers) (96 000) (104 000) (112 000) (120 000) (128 000) (136 000)
[Months] [72] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X XXXXX
Rotate tires. X XXXXX
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary.
Not required if previously changed. * ‡X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
SCHEDULE “A”—TURBO 335
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 90,000 95,000 100,000 105,000
(Kilometers) (144 000) (156 000) (160 000) (168 000)
[Months] [108] [114] [120] [126]
Change engine oil and engine oil filter. X X X X
Rotate tires. X X X X
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Adjust the generator drive belt tension. X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary. Not required if
previously changed. * ‡X
Flush and replace the engine coolant if not done at 60 months. X
Replace theMake-up air filter.X
Replace theengine timing belt.X
336 SCHEDULE “A”—TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 110,000 115,000 120,000
(Kilometers) (177 000) (185 000) (193 000)
[Month] [132] [138] [144]
Change engine oil and engine oil filter. X X X
Rotate tires. X X X
Inspect thePCV Valveand replace if necessary. * X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
SCHEDULE “A”—TURBO 337
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
