a soft, natural bristle scrub brush, and a mild soap
solution such as liquid dish washing soap. Do not use
detergent.
CAUTION!
Never use an abrasive type cleaner or bleaches.
Cleaners should not contain silicones, organic sol-
vents, petroleum distillates or plasticizers. always
wait until the top is thoroughly dry before lowering
it into the storage area.
Scrub in all directions, covering an area of about two
square feet at a time. Avoid heavy scrubbing. Rinse the
entire vehicle with water to remove all soap and dirt from
the top fabric and to prevent streaking on painted and
chrome surfaces. Allow the top to dry before lowering.
Vacuuming the top with a wet/dry shop vacuum will
decrease the top’s drying time, ensure removal of all dirt,and delete streaks in the material. Multiple cleanings
may be necessary to remove stubborn stains. If stains
persist, contact your local dealership for further sugges-
tions.
Cloth Top Additional Cleaning Procedure
For additional cleaning assistance in removing stubborn
stains, apply Mopar Convertible Cloth Top Cleaner #
4883061 to the complete stain, extending 2 inches (50
mm) beyond the stain. With a soft bristle brush, scrub in
all directions over the stain. Avoid heavy scrubbing.
Rinse the area with warm water. If the stain is still
apparent, repeat the cleaning procedure. When the stain
is no longer showing, rinse the complete top with warm
water. Let the top dry before lowering it.
MAINTAINING YOUR VEHICLE 291
7

Cloth Top Protection
For appearance purposes, you may wish to protect your
Twillfast™(cloth) top periodically. A fabric protectant
such as Scotchguardis suggested. The top should be
clean and dry before application of the protectant.
CAUTION!
Avoid getting Scotchguardon the surrounding
weather strips, moldings, paint, or glass. Damage to
these items might occur.
Weather Strip Care
Lubricate all top and door glass weather strips periodi-
cally with Mopar Weather Strip Lubricant (part number
4773427), to keep them soft and pliable.
FUSES
Underhood Fuses (Power Distribution Center)
A Power Distribution Center is located in the engine
compartment; next to the air cleaner filter. A label iden-
tifying the components and circuits is located on the
underside of the cover.
Power Distribution Center Location
292 MAINTAINING YOUR VEHICLE

Power Distribution Center
MAINTAINING YOUR VEHICLE 293
7

FUSE Amp/Color Items Fused
1 30 Amp/Pink Ignition Start
2 40 Amp/
GreenAnti-Lock Brake (ABS)
Pump
3 40 Amp/
GreenIgnition Run
4 30 Amp/Blue Heated Seats
5 40 Amp/
GreenRadiator Fan (Low Speed
Turbo only)
6 50 Amp/Red High Speed Radiator Fan
(Turbo Only)
7 30 Amp/Blue Anti-Lock Brake (ABS)
Solenoid
8 40 Amp/
GreenElectric Back Light (EBL)
9 40 Amp/
GreenPower Top10 40 Amp/
GreenIP Fuse Block
11 10 Amp/Red Air Conditioning (A/C)
12 15 Amp/Lt.
BlueStop Lights
13 20 Amp/
YellowFuel Pump/Auto Shut
Down (ASD)
14 15 Amp/Lt.
BlueHorn
15 20 Amp/
YellowElectronic Automatic
Transaxle (ETAX)
16
17 15 Amp/Lt.
BlueHi Beam
18 30 Amp/Blue Ignition Off Draw (IOD)
19 15 Amp/Lt.
BlueHazard Flasher
294 MAINTAINING YOUR VEHICLE

20 20 Amp/
YellowPower Outlets
21 Spare
22 20 Amp/
YellowFog Lamps (Export Only)
Interior Fuses
The fuse access panel is on the left side of the instrument
panel next to the steering column. To remove the panel,
pull it out, as shown. A label identifying the components
and circuits is located on the inside of the cover.
Interior Fuse Panel
MAINTAINING YOUR VEHICLE 295
7

FUSE Amp/Color Items Fused
1 25 Amp/
NaturalHeadlamp Switch
2 15 Amp/Lt.
BluePark Lamps
3 20 Amp/
YellowRKE/Door Locks
4 20 Amp/
YellowPower Height Adjust
5 10 Amp/Red Airbag Run Only
6 10 Amp/Red B/U Electric Back Light
(EBL) NEU SAF
7 25 Amp/
NaturalHVAC Blower
8 15 Amp/Lt.
BlueFog Lamp (Non BUX)
9 10 Amp/Red Airbag Run-ST10 10 Amp/Red Cluster/RKE/SKIM
11 10 Amp/Red Engine Module/ABS-
TRAC
12 10 Amp/Red PDC Relays/LDP
13 10 Amp/Red Interior Lighting
14 20 Amp/
YellowOverhead Console/Radio
15 20 Amp/
YellowWipers/Comb. FLS
16 10 Amp/Red Auto Stick/Ignition
17 15 Amp/Lt.
BlueHeated Seats
18 10 Amp/Red Heated Mirrors
19 10 Amp/Red Rt Headlamp
20 10 Amp/Red Lt Headlamp
296 MAINTAINING YOUR VEHICLE

CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it shows a
problem in the circuit that must be corrected.
VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
•Disengage the mini fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
•Or, disconnect the negative cable from the battery.
REPLACEMENT BULBS
LIGHT BULBS—Inside Bulb No.
ABS Indicator.......................... LED
Airbag Indicator........................ LED
Brake System Warning Indicator............. LED
Center Console Floor Lamp................. T37
Climate Controls......................6233137
Console Gear Selector...................PC194
Cruise Indicator....................... VFD*
Deck Lid Ajar Indicator................... LED
Dome Light (Sport Bar Lights)..............T904
Door Ajar Indicator..................... VFD*
Front Fog Indicator...................... LED
High Beam Indicator....................... 74
Instrument Cluster Illumination.............. 74
Low Fuel Indicator....................... LED
Low Oil Pressure Indicator................. LED
Overhead Reading Light (Rearview Mirror).....T192
MAINTAINING YOUR VEHICLE 297
7

Rear Cargo............................T906
Seat Belt Indicator....................... LED
Security Alarm Indicator................... LED
Malfunction Indicator Light................ LED
Temperature Indicator.................... LED
Trac (Active) Indicator................... VFD*
TRAC OFF Indicator..................... LED
Trip Indicator......................... VFD*
Turn Signal Indicator...................... 103
Visor Vanity............................. 74
Voltage Indicator........................ LED
NOTE:* Vacuum Fluorescent Display
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.LIGHTS BULBS—Outside Bulb No.
Low Beam Headlight...................9006XS
High Beam Headlight...................9005XS
Front Park/Turn Signal/Side Marker Light. 4157NAKX
Front Fog Light.........................9006
Center High Mounted Stop Light
(CHMSL).........................921–W16W
Rear Tail/Stop/Turn Signal Light......3157–P27/7W
Backup Light.....................3157-P27/7W
License Light........................... 168
298 MAINTAINING YOUR VEHICLE

BULB REPLACEMENT
Headlight Bulb Replacement
CAUTION!
Do not touch the new headlight bulb with your
fingers. Oil contamination will severely shorten
bulb life.
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Disconnect the electrical connector.3. Rotate the socket to the left one quarter turn and
replace the bulb.
MAINTAINING YOUR VEHICLE 299
7

Front Park/Turn Signal/Side Marker Lights
1. Remove the headlight access cover splash shield,
located in the front wheel well opening.
2. Rotate the socket to the left one quarter turn to replace
and replace the bulb.
Front Fog Lights—If Equipped
1. Remove the fasteners attaching the lower splash
shield to gain access to the fog light.
2. Twist and remove the bulb from the fog light housing.
3. Disconnect the electrical connector and replace bulb.
Tail/Stop, and Rear Turn Signal Lights
1. Remove the screw attaching the tail light housing and
remove the housing from the vehicle.
