CHRYSLER PT CRUISER 2005 1.G Owners Manual
Manufacturer: CHRYSLER, Model Year: 2005, Model line: PT CRUISER, Model: CHRYSLER PT CRUISER 2005 1.GPages: 360, PDF Size: 11.21 MB
Page 311 of 360
Miles 3,000 6,000 9,000 12,000 15,000 18,000
(Kilometers) (5 000) (10 000) (14 000) (19 000) (24 000) (29 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Rotate tires. X X X
Inspect the brake linings. X
Inspect theengine air cleaner filter,replace as
necessary.*X
Inspect theMake-up air filter,replace as nec-
essary.X
SCHEDULE“B”—ALL ENGINES 311
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 312 of 360
Miles 21,000 24,000 27,000 30,000 33,000 36,000
(Kilometers) (34 000) (38 000) (43 000) (48 000) (53 000) (58 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Rotate tires. X X X
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace as neces-
sary.*X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
312 SCHEDULE“B”—ALL ENGINES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 313 of 360
Miles 39,000 42,000 45,000 48,000 51,000 54,000
( Kilometers) (62 000) (67 000) (72 000) (77 000) (82 000) (86 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Rotate tires. X X X
Inspect the brake linings. X
Change the brake fluid. If vehicle is used for
trailer towing.X
Inspect theengine air cleaner filter,replace as
necessary.*X
Change the manual transaxle fluid.†X
Inspect theMake-up air filter.Replace as nec-
essary.X
SCHEDULE“B”—ALL ENGINES 313
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 314 of 360
Miles 57,000 60,000 63,000 66,000 69,000 72,000
( Kilometers) (91 000) (96 000) (101 000) (106 000) (111 000) (115 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Rotate tires. X X X
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if neces-
sary. Not required if previously changed. *‡X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
Change the automatic transaxle fluid and fil-
ter.X
Flush and replace engine coolant at 60
months, if not done at 102,000 miles.X
314 SCHEDULE“B”—ALL ENGINES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 315 of 360
Miles 75,000 78,000 81,000 84,000 87,000 90,000
(Kilometers) (120 000) (125 000) (130 000) (135 000) (130 000) (144 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX X
Rotate tires. X X X
Inspect the brake linings. X
Inspect theengine air cleaner filterand replace
as necessary.*X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary.
Not required if previously changed. *‡X
Replace theengine timing belt.*X
Inspect theMake-up air filter,replace as necessary. X
Adjust the generator drive belt tension. X
Replace theMake-up air filter.X
SCHEDULE“B”—ALL ENGINES 315
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 316 of 360
Miles 93,000 96,000 99,000 102,000 105,000
(Kilometers) (150 000) (154 000) (159 000) (164 000) (168 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Rotate tires. X X
Inspect the brake linings. X
Change the brake fluid. If vehicle is used for trailer
towing.X
Inspect theengine air cleaner filterand replace as
necessary.*X
Change the manual transaxle fluid.†X
Flush and replace the engine coolant, if not replaced
at 60 months.X
Inspect theMake-up air filter,replace as necessary. X
316 SCHEDULE“B”—ALL ENGINES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 317 of 360
Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (173 000) (178 000) (183 000) (188 000) (193 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Rotate tires. X X X
Inspect the brake linings. X
Replace theengine air cleaner filter.*X
Inspect the tie rod ends and boot seals. X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
Change automatic transaxle fluid and filter.X
Inspect thePCV valve and replace if necessary.*‡X
Flush and replace the engine coolant at 120 months,
if not replaced at 102,000 miles.X
Replace thespark plugs and ignition cables.X
SCHEDULE“B”—ALL ENGINES 317
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 318 of 360
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.
†This maintenance is required only for police, taxi,
limousine type operation, or trailer towing.This maintenance is required only for police, taxi,
limousine type operation, or trailer towing.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
318 SCHEDULE“B”—ALL ENGINES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 319 of 360
SCHEDULE“A”—NON TURBO
Miles 6,000 12,000 18,000 24,000 30,000 36,000
(Kilometers ) (10 000) (19 000) (29 000) (38 000) (48 000) (58 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter. XXXXXX
Rotate tires. XXXXXX
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Replace theMake-up air filter.X
Adjust the generator drive belt tension X
SCHEDULE“A”—NON TURBO 319
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 320 of 360
Miles 42,000 48,000 54,000 60,000 66,000
(Kilometers) (67 000) (77 000) (86 000) (96 000) (106 000)
[Months] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter.XXXXX
Rotate tires.XXXXX
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace, if necessary.* X
Flush and replace the engine coolant at 60 months, if
not done at 102,000 miles.X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
