Page 321 of 360
Miles 72,000 78,000 84,000 90,000 96,000 102,000
(Kilometers) (115 000) (125
000)(134
000)(144
000)(154 000) (164
000)
[Months] [72] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X X X X X X
Rotate tires. X X X X X X
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary. Not
required if previously changed. *‡X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
Flush and replace the engine coolant, if not re-
placed at 60 months.X
SCHEDULE“A”—NON TURBO 321
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 322 of 360
Miles108,000 114,000 120,000
(Kilometers) (173 000) (182 000) (192 000)
[Months] [108] [114] [120]
Change engine oil and engine oil filter. X X X
Rotate tires. X X X
Inspect thePCV valveand replace if necessary. *‡X
Replace theair cleaner filter.X
Replace theengine timing belt.*X
Flush and replace the engine coolant at 120 months, if not done at
102,000 miles.X
Replace thespark plugs and ignition cables.X
Replace theMake-up air filter.X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
322 SCHEDULE“A”—NON TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 323 of 360
SCHEDULE“A”—TURBO
Miles 5,000 10,000 15,000 20,000 25,000 30,000
(Kilometers) (8 000) (16 000) (24 000) (32 000) (40 000) (48 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter. XXXXXX
Rotate tires. XXXXXX
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
SCHEDULE“A”—TURBO 323
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 324 of 360
Miles 35,000 40,000 45,000 50,000 55,000
(Kilometers) (56 000) (64 000) (72 000) (80 000) (88 000)
[Months] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter.XXXXX
Rotate tires.XXXXX
Inspect the brake linings. X
Flush and replace engine coolant at 60 months, if not
replaced at 100,000 miles.X
324 SCHEDULE“A”—TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 325 of 360
Miles 60,000 65,000 70,000 75,000 80,000 85,000
(Kilometers) (96 000) (104
000)(112
000)(120
000)(128
000)(136 000)
[Months] [72] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. XXXXX X
Rotate tires. XXXXX X
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary. Not
required if previously changed. *‡X
Replace theMake-up air filter.X
Adjust the generator drive belt tension. X
SCHEDULE“A”—TURBO 325
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 326 of 360
Miles 90,000 95,000 100,000 105,000
(Kilometers) (144 000) (156 000) (160 000) (168 000)
[Months] [108] [114] [120] [126]
Change engine oil and engine oil filter. X X X X
Rotate tires. X X X X
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Adjust the generator drive belt tension. X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary. Not required if
previously changed. *‡X
Flush and replace the engine coolant if not done at 60 months. X
Replace theMake-up air filter.X
Replace theengine timing belt.X
326 SCHEDULE“A”—TURBO
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 327 of 360
Miles 110,000 115,000 120,000
(Kilometers) (177 000) (185 000) (193 000)
[Month] [132] [138] [144]
Change engine oil and engine oil filter. X X X
Rotate tires. X X X
Inspect thePCV Valveand replace if necessary. * X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
SCHEDULE“A”—TURBO 327
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S
Page 328 of 360
Page 329 of 360
IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
Suggestions For Obtaining Service For Your
Vehicle..............................330
▫Prepare For The Appointment............330
▫Prepare A List........................330
▫Be Reasonable With Requests.............330
If You Need Assistance...................331
Warranty Information....................333
MoparParts.........................335Reporting Safety Defects..................335
▫In Canada..........................335
Publication Order Forms..................336
Department Of Transportation Uniform Tire
Quality Grades........................337
▫Treadwear..........................337
▫Traction Grades......................337
▫Temperature Grades...................338
9
Page 330 of 360
SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
330 IF YOU NEED CONSUMER ASSISTANCE
