When the HIGH setting is selected, the heater will
provide a boosted heat level during the first four minutes
of operation. Then, the heat output will drop to the
normal HIGH temperature level. If the HIGH setting is
selected, the system will automatically switch to LOW
after 30 minutes of continuous operation. At that time,
the number of illuminated LEDs changes from two to
one, indicating the change. The LOW setting will turn off
automatically after 30 minutes.
NOTE:Once a heat setting is selected, heat will be felt
within two to five minutes.FOLDING REAR SEAT (SEDAN)
To provide additional storage area, each rear seatback can
be folded forward. Push and hold the buttons shown in
the picture to fold down either or both seatbacks.
Folding Rear Seat Button
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171
3

WARNING!
²It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seri-
ously injured or killed.
²Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts
²Be sure that everyone in your vehicle is in a seat
and using a seat belt properly.
NOTE:
²If the rear center lap/shoulder belt appears to be
locked into place, check to verify that the seatback is
fully latched.
²If the seatback is properly latched and the rear center
lap/shoulder belt still does not operate properly check
and see if the Automatic Locking retractor (ALR)
system is activated.
WARNING!
The rear center lap/shoulder belt is equipped with a
lock-out feature to ensure that the seatback is in the
fully upright and locked position when occupied. If
the rear seatback is not fully upright and locked and
the rear center lap/shoulder belt can be pulled out of
the retractor, the vehicle should immediately be
taken to your dealer for service. Failure to follow this
warning could result in serious or fatal injury.
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

FOLDING REAR SEAT (CONVERTIBLE)
To provide additional storage area, each rear seatback can
be folded forward. The seat back release knobs are
located in the trunk area. Pull the left side seatback
release knob to fold down the left side seatback. Pull the
right side seatback release knob to fold down the right
side seatback.
Folding Rear Seat Release Knobs
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173
3

WARNING!
²It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seri-
ously injured or killed.
²Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.
²Be sure that everyone in your vehicle is in a seat
and using a seat belt properly.NOTE:Prior to lifting either seatback to the upright
position, be sure that the seat belt is brought forward to
avoid trapping it behind the seatback.
CAUTION!
Ensure that the seat back is latched with a hard push
to engage the latch, noting the presence of seat back
rubber-overslam bumpers that need to be overcome.
Check that the seat back release knobs are pushed
fully forward in order to allow the latch to engage.
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

TUMBLING REAR SEAT (SEDAN)
To provide additional storage in the cargo area, each rear
seat can be tumbled forward.
CAUTION!
It is important that the front seats be pulled forward
to the midpoint of the seat track to avoid contact
between the rear seat and the front seatback. If the
front seat is not pulled forward the two seats will
make contact during the tumbling motion and cause
damage to the rear seat material. After the rear seat is
tumbled forward and secured the front seat can then
be repositioned to the preferred position.
²Push and hold the button on the seatback and fold
down the rear seatback.
Folding Rear Seat Button
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175
3

²Pull the release handle located on the outboard side of
the seat. Lift up the seat and tumble the seat forward.
²Attach the elastic strap, located at the base of the seat
cushion, onto the hook bar on the center trim panel to
hold the seat in place.To return the rear seat to it's upright latched position,
rotate the seat cushion rearward to latch the seat. Then
lift the seatback to its upright latched position.
NOTE:The elastic strap should be reinstalled in the clip
on the base of the seat cushion before returning the seat
to its normal position.
Tumbling Seat Release Strap
Tumbling Seat Strap
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

TUMBLING REAR SEAT (CONVERTIBLE)
To provide additional storage area, each rear seat can be
tumbled forward.
CAUTION!
It is important that the front seats be pulled forward
to the midpoint of the seat track to avoid contact
between the rear seat and the front seatback. If the
front seat is not pulled forward the two seats will
make contact during the tumbling motion and cause
damage to the rear seat material. After the rear seat is
tumbled forward and secured the front seat can then
be repositioned to the preferred position.To tumble the seat forward use the following procedure:
1. The seat back release knobs are located in the trunk
area. Pull the left side seatback release knob to fold down
the left side seatback. Pull the right side seatback release
knob to fold down the right side seatback.
Folding Rear Seat Release Knobs
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
3

2. From inside the vehicle, fold the rear seat back down
flat.
3. Pull the release strap located at the bottom of the
folded seat back and tumble the seat forward.4. Attach the cinching tether strap, located at the side of
the seat cushion, onto the hook bar on the center trim
panel and tighten by pulling the cinching strap until the
seat is secure.
Folding Rear Seat Back
Tumbling Rear Seat
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To return the tumbling rear seat to the latched (normal)
position use the following procedure:
1. Loosen the strap by pushing rearward on the cinching
tether strap buckle.2. Disconnect the cinching tether strap.
NOTE:The strap should be reinstalled in the side
pocket on the seat cushion before returning the seat to the
latched (normal) position.
Cinching Tether StrapReleasing Cinching Tether Strap
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179
3

NOTE:Prior to rotating the seat cushions rearward, be
sure that the rear seat belt buckles are secured with the
straps, so that the buckles are accessible.
3. Rotate the seat cushion rearward to latch the seat.
Then lift the seatback to its upright latched position.NOTE:Prior to lifting either seatback to the upright
position, be sure that the seat belt is brought forward to
avoid trapping it behind the seatback.
CAUTION!
Ensure that the seat back is latched with a hard push
to engage the latch, noting the presence of seat back
rubber-overslam bumpers that need to be overcome.
Check that the seat back release knobs are pushed
fully forward in order to allow the latch to engage.
WARNING!
In an accident, you or others in your vehicle could be
injured if seats are not properly latched to their
attachments. Always be sure the seats are fully
latched.
Rear Seat Belt Buckle Straps
