CAUTION!
Damage to the top material could result if the latch
handles are not completely closed when the top is
lowered. The convertible top cover cannot be in-
stalled while the latch handles are open.
To Raise The Top:
CAUTION!
To avoid damage to the sunvisors, rotate the driver’s
and passenger’s sunvisor to the forward (against
glass) position before raising or lowering the con-
vertible top.
NOTE:To avoid damage to the convertible top or its
components, your vehicle is equipped with a feature that
prevents convertible top operation at speeds over 10 mph
(16 km/h).
NOTE:If the power convertible top system fails, raise
the top by manually pulling the top until it meets the
windshield and open both front latch handles. Pull the
top until the two pins are seated in the windshield
header. Using the center pull cup, pull down and hook
each latch hook to its striker. Latch both sides. This may
require a considerable amount of physical effort.
CAUTION!
To fully insure that no damage occurs, be sure that
the vehicle is at a complete stop with the gear
selector in the Park position before lowering or
raising the top.
1. Remove the top cover and store it in the trunk.
2. Turn the ignition to the ON position.
3. Press the Power Top Switch to raise the top. Before the
top reaches the windshield, open both front latch
handles. Press the switch again to continue raising the
top until the two pins seat themselves in the windshield
header.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 51
3

4. Use the center pull cup to pull down on the header.
Hook each latch hook to its striker. Latch both sides.
CAUTION!
Car top carriers, ski racks, etc., should not be at-
tached to the convertible top mechanism as they will
damage the top.
Top Cover Installation
With the top down and the convertible top latch handles
in the closed position, there are two ways to install the
convertible top cover. Lay the unfolded convertible top
cover across the convertible top and choose the way that
suits you best.
52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Installation From Inside The Vehicle
1. Kneel on the rear seat and tuck the rear edge and side
edges of the top cover under the black molding near the
trunk.2. Insert both tabs located on the front of the top cover in
between the seatback and seatback bracket.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 53
3

3. Snap the top cover flaps to the inner trim panel snaps.
The side of the seat back cushion hides the snap.4. Press down on the forward portion of the top cover to
engage the hook and loop fasteners.
Top Cover FlapHook and Loop Fasteners
54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Installation From Outside The Vehicle
1. Start on one side of the vehicle and tuck as much of the
top cover as possible under the black molding.2. Snap the top cover flap to the inner trim panel snap.
(The side of the seat back cushion hides the snap.)
Top Cover Flap
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 55
3

3. Tuck the top cover tab closest to you into the space
between the seatback and the seatback bracket.
4. Walk to the other side of the vehicle and finish tucking
the top cover under the black molding. Insert the remain-
ing tab between the seatback and the seatback bracket.5. Snap the remaining top cover flap to the inner trim
panel snap.
Top Cover Flap
56 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. Press down on the forward portion of the top cover to
engage the hook and loop fasteners.
Top Cover Removal
Unsnap the snaps and disengage the hook and loop
fasteners, slide the tabs from the rear seat and then from
the rear of the top storage area. Remove the top cover,
fold, and store in the trunk or a dry secure area.
CONSOLE FEATURES
The front console hastwo cup holders. An optiona l
removable ashtray may be located in the driver’s side cup
holder.Hook and Loop Fasteners
Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 57
3

The center console/armrest has a pencil /tire gage holder
and a tissue holder mounted on the underside of the
cover. The bottom of the console bin also has built in
holders for compact discs or cassette tapes. The power
outlet is also mounted inside the center console (if
equipped). There are also two cup holders for rear seat
passengers and a rear courtesy lamp located directly in
back of the center console. The center console can be
locked using the“master”key.
Two coin holders are located toward the front of the
inside of the console bin. Both can also accommodate
various combinations of different types of coins, includ-
ing some international currencies. The slot on the far left
side is not for coins, but for an optional power outlet, if so
equipped.MIRRORS
Inside Day/Night Mirror—If Equipped
Adjust the mirror to center on the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustment. If the driver’s sunvisor
interferes with the mirror, the mirror can be moved to the
right to eliminate the interference.
Rearview Mirror
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Automatic Dimming Mirror—If Equipped
This mirror will automatically adjust for annoying head-
light glare from vehicles behind you. Push in the button
on the face of the mirror to activate the dimming feature.
CAUTION!
To avoid damage to the mirror during cleaning,
never spray any cleaning solution directly onto the
mirror. Apply the solution onto a clean cloth and
wipe the mirror clean.
Automatic Dimming Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 59
3

Electric Remote-Control Mirrors
Both of the outside mirrors can be adjusted by using the
remote controls mounted on the instrument panel located
to the left of the steering wheel.
NOTE:Place the mirror selector switch in the center
(neutral) position to prevent accidental movement of the
mirrors.
Outside Mirror Adjustment—Driver’s Side
Adjust the outside mirror to center on the adjacent lane of
traffic, with a slight overlap of the view obtained on the
inside mirror.
Right Side Mirror Adjustment
Adjust the convex outside mirror so you can just see the
side of your vehicle in the part of the mirror closest to the
vehicle.
WARNING!
Vehicles and other objects seen in the right side
convex mirror will look smaller and farther away
than they really are. Relying too much on your right
side mirror could cause you to collide with another
vehicle or other object. Use your inside mirror when
judging the size or distance of a vehicle seen in this
convex mirror.
Power Mirror Controls
