CHRYSLER SEBRING CONVERTIBLE 2008 3.G Owners Manual

MAINTAINING YOUR VEHICLE
CONTENTS
m2.4L Engine Compartment................354
m2.7L Engine Compartment................355
m3.5L Engine Compartment................356
mOnboard Diagnostic System Ð OBD II........357
NLoose Fuel Filler Cap Message............358
mEmissions Inspection And Maintenance
Programs............................358
mReplacement Parts......................360
mDealer Service.........................360mMaintenance Procedures..................361
NEngine Oil..........................361
NEngine Oil Filter......................365
NDrive Belt...........................365
NSpark Plugs.........................365
NEngine Air Cleaner Filter................365
NCatalytic Converter....................366
NMaintenance-Free Battery................367
NAir Conditioner Maintenance.............369
7

NA/C Air Filter Ð If Equipped............370
NPower Steering Ð Fluid Check............371
NFront Suspension Ball Joints..............372
NSteering Linkage......................372
NBody Lubrication.....................372
NWindshield Wiper Blades................373
NWindshield Washers...................374
NExhaust System......................374
NCooling System.......................375
NHoses And Vacuum/Vapor Harnesses.......381
NFuel System.........................381
NBrake System........................381
NAutomatic Transaxle...................384NFront And Rear Wheel Bearings...........387
NAppearance Care And Protection
From Corrosion......................387
NCleaning The Center Console Cup Holders . . . 392
mConvertible Top Care....................393
NSoft Top............................393
NWeather Strip Care Ð Soft & Hard Top......395
mFuses (Totally Integrated Power Module)......395
mVehicle Storage........................400
mReplacement Bulbs......................400
mBulb Replacement......................401
NLow Beam Headlight, High Beam Headlight . . 401
NFront Turn Signal/Park Light.............402
352 MAINTAINING YOUR VEHICLE

NFront Fog Light......................403
NTail/Stop Light, Rear Turn Signal Light,
Backup Light........................404
NLicense Plate Light....................407
NCenter High-Mounted Stop Light (CHMSL) . . . 408mFluids And Capacities...................409
mFluids, Lubricants, And Genuine Parts........410
NEngine.............................410
MAINTAINING YOUR VEHICLE 353
7

2.4L ENGINE COMPARTMENT
354 MAINTAINING YOUR VEHICLE

2.7L ENGINE COMPARTMENT
MAINTAINING YOUR VEHICLE 355
7

3.5L ENGINE COMPARTMENT
356 MAINTAINING YOUR VEHICLE

ONBOARD DIAGNOSTIC SYSTEM Ð OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transaxle control systems. When these systems are oper-
ating properly, your vehicle will provide excellent per-
formance and fuel economy, as well as engine emissions
well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the ªMalfunction Indicator Light.º It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
²Prolonged driving with the ªMalfunction Indica-
tor Lightº on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
²If the ªMalfunction Indicator Lightº is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
MAINTAINING YOUR VEHICLE 357
7

Loose Fuel Filler Cap Message
If the vehicle diagnostic system determines that the fuel
filler cap in loose, improperly installed, or damaged, a
ªgASCAPº message will display in the instrument clus-
ter. Tighten the gas cap until a ªclickingº sound is heard.
This is an indication that the gas cap is properly tight-
ened. Press the trip odometer reset button to turn off the
message. If the problem persists, the message will appear
the next time the vehicle is started. This might indicate a
fuel evaporation system error. If the problem is detected
twice in a row, the system will turn on the Malfunction
Indicator Light (MIL). Resolving the problem will turn
the MIL light off.
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle's emissions control system.
Failure to pass could prevent vehicle registration.
For states, which have an I/M (Inspection and
Maintenance) requirement, this check verifies the
following: the MIL (Malfunction Indicator Light)
is functioning and is not on when the engine is running,
and that the OBD (On Board Diagnostic) system is ready
for testing.
Normally, the OBD system will be ready. The OBD
system maynotbe ready if your vehicle was recently
serviced, if you recently had a dead battery, or a battery
replacement. If the OBD system should be determined
not ready for the I/M test, your vehicle may fail the test.
358 MAINTAINING YOUR VEHICLE

Your vehicle has a simple ignition key-actuated test,
which you can use prior to going to the test station. To
check if your vehicle's OBD system is ready, you must do
the following:
1. Insert your ignition key into the ignition switch.
2. Turn the ignition to the ON position, but do not crank
or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
4. As soon as you turn your key to the ON position, you
will see your MIL symbol come on as part of a normal
bulb check.
5. Approximately 15 seconds later, one of two things will
happen:
a. The MIL will flash for about 10 seconds and then
return to being fully illuminated until you turn off theignition key or start the engine. This means that your
vehicle's OBD system isnot readyand you shouldnot
proceed to the I/M station.
b. The MIL will not flash at all and will remain fully
illuminated until you turn OFF the ignition key or start
the engine. This means that your vehicle's OBD system
isreadyand you can proceed to the I/M station.
If your OBD system isnot ready,you should see your
authorized dealer or repair facility. If your vehicle was
recently serviced or had a battery failure or replacement,
you may need to do nothing more than drive your
vehicle as you normally would in order for your OBD
system to update. A recheck with the above test routine
may then indicate that the system is now ready.
Regardless of whether your vehicle's OBD system is
ready or not ready, if the MIL symbol is illuminated
during normal vehicle operation, you should have your
MAINTAINING YOUR VEHICLE 359
7

vehicle serviced before going to the I/M station. The I/M
station can fail your vehicle because the MIL symbol is on
with the engine running.
REPLACEMENT PARTS
Use of genuine Mopartparts for normal/scheduled
maintenance and repairs is highly recommended to en-
sure the designed performance. Damage or failures
caused by the use of non-Mopartparts for maintenance
and repairs will not be covered by the manufacturer's
warranty.
DEALER SERVICE
Your authorized dealer has the qualified service person-
nel, special tools, and equipment to perform all service
operations in an expert manner. Service Manuals are
available which include detailed service information for
your vehicle. Refer to these manuals before attempting
any procedure yourself.NOTE:Intentional tampering with emissions control
systems can result in civil penalties being assessed
against you.
WARNING!
You can be badly injured working on or around a
motor vehicle. Only do service work for which you
have the knowledge and the proper equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent
mechanic.
