CHRYSLER SEBRING COUPE 2004 2.G Owners Manual

equipped). The transmitter operates off your vehicle's
battery and charging system; no batteries are needed.
For additional information on HomeLinky, call toll-free
for customer assistance at 1±800±355±3515, or on the
internet at www.homelink.com.
WARNING!
²A moving garage door can cause injury to people
and pets in the path of the door. People or pets
could be seriously or fatally injured. Only use this
transceiver with a garage door opener that has a
ªstop and reverseº feature as required by federal
safety standards. This includes most garage door
opener models manufactured before April 1, 1982.
Do not use a garage door opener without these
safety stop and reverse features it could cause
injury or death. Call toll-free for customer assis-
tance at 1±800±355±3515, or on the internet at
www.homelink.jci.com for safety information or
assistance.
Training The Universal Transceiver
For best results, install a new battery in the hand held
transmitter before programming. If your garage door
opener (located in the garage) is equipped with an
antenna, make sure that the antenna is hanging straight
down.
1. Turn off the engine.
WARNING!
²Vehicle exhaust contains carbon monoxide, a dan-
gerous gas. Do not run the vehicle's exhaust while
training the transceiver. Exhaust gas can cause
serious injury or death.
²Your motorized door or gate will open and close
while you are training the universal transceiver.
Do not train the transceiver if people or pets are in
the path of the door or gate. A moving door or gate
can cause serious injury or death to people and
pets or damage to objects.
2. Erase the factory test codes by pressing the two
outside buttons (A and B) on the universal transceiver.
INSTRUMENTS AND CONTROLS 131
4

Release the buttons when the light in the indicator (D)
begins to flash after 20 seconds.
A - Universal Transceiver button 1
B - Universal Transceiver button 2
C - Universal Transceiver button 3
D - Indicator light
NOTE:
²Step 2 does not have to be followed to program
additional hand held transmitters (E).3. Choose one of the three buttons to train. Place the
hand held transmitter 1 to 3 inches from the universal
transceiver while keeping its indicator light in view.
4. Using both hands, press the hand held transmitter
button and the desired universal transceiver button. Do
not release the buttons until step 5 has been completed.
F21A0100
F21A0110
132 INSTRUMENTS AND CONTROLS

NOTE:
²Some entry gates and garage door openers may re-
quire you to replace step 4 with the procedures listed
under Canadian Programming.
5. The indicator light (D) will begin to flash, first slowly
and then rapidly. The rapid flashing indicates successful
programming. If after 90 seconds the indicator light does
not flash rapidly or goes out, return to step 1 and repeat
the procedure. To train the other buttons, repeat steps 3
and 4. Be sure to keep your hand held transmitters in case
you need to retrain the universal transceiver.
Refer to the Rolling Code Programming or the
Canadian/Gate paragraphs for additional procedures, if
necessary.
If you do not successfully program the universal trans-
ceiver to learn the signal of your hand held transmitter,
refer to the Rolling Code Paragraph, or call toll-free for
customer assistance at 1±800±355±3515, or on the internet
at www.homelink.jci.com.
Canadian Programming/Gate Programming
Canadian frequency laws, and the technology of some
entry gates, require you to press and release the hand
held transmitter button every two seconds during pro-
gramming.
Continue to press and hold the universal transceiver
button (A, B or C) while you press and release the hand
held transmitter button until the frequency signal has
been learned. The indicator light (D) will flash slowly
and then rapidly when the programming is successful.
NOTE:
²When programming such a garage door opener or
gate, unplug the device to prevent possible damage to
the garage door or gate motor.
INSTRUMENTS AND CONTROLS 133
4

Operation
Press and hold the desired button (A, B or C) on the
universal transceiver until the garage door or other
device begins to operate. The indicator light (D) shows
that the signal is being transmitted. The hand held
transmitter (E) may also be used at any time.
NOTE:
²
If you have difficulty in programming, call toll-free for
customer assistance at 1-800-355-3515, or the internet
at www.homelink.jci.com.
²If your hand held transmitter appears to program the
universal transceiver, but your garage door or other
device does not operate, and your device was manu-
factured after 1996, your garage door opener or other
device may have a ªRolling Codeº system.To check if your device is protected by a ªRolling Codeº
system:
²Check the owner's manual for the device for mention
of ªRolling Codeº.
²The hand held transmitter appears to program the
universal transceiver but the universal transceiver
does not activate the garage door.
²Press and hold the programmed button on the univer-
sal transceiver. If the indicator light (D) flashes rapidly
and then stays on after 2 seconds, the device has the
ªRolling Codeº feature.
ªRolling Codeº Programming
On garage door openers with the ªRolling Codeº feature,
the transmitter code changes after each use to prevent the
copying of your code. Set the universal transceiver by
following these steps:
NOTE:
²
The assistance of a second person may make the
following programming procedure quicker and easier.
134 INSTRUMENTS AND CONTROLS

1. Locate the training button on the garage door motor
head unit. The exact location and color of the training
button may vary by garage door opener manufacturer. If
you have difficulty in locating the training button, check
your garage door opener manual, or call toll-free for
customer assistance at 1-800-355-3515, or on the internet
at www.homelink.jci.com.
2. Press and hold the training button on the garage door
opener head unit This will activate the ªtrainingº light.
NOTE:
²
After completing step 2, you have 30 seconds to start
step 3.
3. Return to the universal transceiver in the vehicle and
firmly press and release the universal transceiver button
(A, B or C). Press and release the button a second time to
complete the training process. Some garage door openers
may require you to do this procedure a third time to
complete the training.
Your garage door opener should now recognize your
universal transceiver. You may use either your universal
transceiver or your original hand held transmitter (E) to
open you garage door.
Reprogramming A Signal Button
1. Press and hold the universal transceiver button (A, B
or C) to be reprogrammed. Do not release until step 4 has
been completed.
F21A0121
INSTRUMENTS AND CONTROLS 135
4

2. When the indicator light (D) begins to flash slowly
(after 20 seconds) position the hand held transmitter (E)
1 to 3 inches away from the universal transceiver button
to be trained.
3. Press and hold the hand held transmitter button.
4. The indicator light will begin to flash, first slowly, then
rapidly. When the indicator lights begin to flash rapidly,
release both buttons.
Security
If you sell your vehicle, be sure to erase the frequencies.
1. To erase all of the previously trained frequencies, hold
down both outside buttons (A and C) until the indicator
light (D) begins to flash after 20 seconds.
2. Release both buttons. Do not hold for longer than 30
seconds.
F21A0130
136 INSTRUMENTS AND CONTROLS

This device complies with FCC rules part 15. Operation is
subject to the following conditions:
²This device may not cause harmful interference.
²This device must accept any interference that may be
received including interference that may cause undes-
ired operation.
NOTE:
²
The transceiver has been tested and complies with
FCC and DOC/MDC rules. Changes or modifications
not expressly approved by the party responsible for
compliance could void the user's authority to operate
the device.
HomeLinktis a trademark owned by Johnson Con-
trols, Inc.
INSTRUMENTS AND CONTROLS 137
4

STARTING AND DRIVING
CONTENTS
mBreak-in recommendations................142
mFuel selection.........................142
NGasoline additives.....................143
NOctane requirement....................143
NReformulated gasoline..................143
NGasoline/Oxygenate blends..............144
NMMT in gasoline......................144
NSulfur in gasoline......................144
NMaterials added to fuel..................145
NAdding fuel..........................145
mFuel economy.........................147
mIgnition switch........................147
mKey reminder chime....................148
mTheft protection........................149
mSteering lock..........................149
mStarting..............................149
NTips for starting.......................149
NNormal conditions.....................150
NFlooded engine.......................151
NAt extremely cold ambient temperature......151
mAutomatic transaxle (if so equipped)........151
NSelector lever operation.................152
5

NGear positions........................154
NDriving speed
(Vehicles with automatic transaxle).........155
NHolding on an upgrade.................155
NTransaxle reset mode...................156
mAutomatic transaxle Autostick
(if so equipped)
........................156
NSelector lever operation.................157
NIndicator lights.......................159
NSelector positions (Main gate).............160
NSelector positions Manual gate Autostick.....161
NHolding on an upgrade.................163
NTransaxle reset mode...................164
mManual transaxle (if so equipped)..........164
NTo start.............................165
NProper shift points.....................165NRecommended downshifting speed.........167
NDriving precautions....................167
mParking brake.........................167
mBrake pedal...........................169
mPower brakes.........................170
mBrake pad wear alarm...................170
mAnti-lock braking (ABS) system
(if so equipped)
........................171
NGeneral driving hints
(standard/anti-lock brakes)...............171
mSteering wheel tilt lock lever..............173
mPower steering........................174
mInside Day/Night rearview mirrors.........175
NElectrochromic inside rearview mirror
(if so equipped).......................176
NElectrochromic mirror operation
(if so equipped).......................177
140 STARTING AND DRIVING
