CAUTION!
²Never use a fuse with a capacity larger than that
specified or any substitute, such as wire, foil, etc.
Doing so will cause the circuit wiring to heat up
and could cause a fire.
²If the newly inserted fuse blows again after a
short time, have the electrical system checked by
an authorized dealer to find and correct the cause.
REPLACEMENT OF LIGHT BULBS
Before replacing a bulb, be sure the light is off. Do not
touch the glass part of the new bulb with your bare
fingers; the skin oil left on the glass will evaporate when
the bulb gets hot and the vapor will condense on the
reflector and dim the surface.
Bulb capacity
A bulb should only be replaced with a new bulb of the
same rating and type. The designation can be found on
the base of the bulb.
Outside
DescriptionWattage or
Candela PowerANSI Trade No.
or Bulb type
1 - Headlight (Type 1) 60W 9005 X/S
(HB3A)
2 - Headlight (Type 2) 51W 9006 X/S
(HB4A)
3-
Front side marker light1.5cp 194NA
4 - Front turn signal and
parking light2.2cp 3157 NAk
5 - Front fog light 37.5W 896
N10B2800
EMERGENCIES 291
8

DescriptionWattage or
Candela PowerANSI Trade No.
or Bulb type
6 - High-mounted stop
light18W 921
7 - Stop and tail light 32/3cp 1157
8 - Back up light 18W 921
9 - Rear turn signal light 32cp 1156NA
10 - Rear side marker light 3cp 168
11 - License plate light 3cp 168
Inside
DescriptionWattage or
Candela Power
Dome Light 10W
Rear personal light 8W
Trunk light 5W
Reading light 4W
Headlights (Type 1)
1. Turn the light socket counterclockwise and pull it out
and remove the light bulb.
N10B2810
N10C1910
292 EMERGENCIES

2. Pull the clip (A) and remove the light bulb from the
socket.Headlights (Type 2)
1. Loosen the bolt (A), move the horn (B) (left side only).
N10C1920N10C1760
EMERGENCIES 293
8

2. Turn the light socket counterclockwise and pull it out
and remove the light bulb.3. Pull the clip (A) and remove the light bulb from the
socket.
N10C1930N10C1940
294 EMERGENCIES

CAUTION!
²Never hold the halogen light bulb with a bare
hand, dirty glove, etc. The oil from your hand
could cause the bulb to break the next time the
headlights are operated.
If the glass surface is dirty, it should be cleaned
with alcohol and installed after drying thor-
oughly.
Adjustment of headlight aim
The alignment of the headlights should be checked by an
authorized dealer.
Front turn signal and parking lights
Turn the light socket counterclockwise and pull it out and
remove the light bulb.
N10C1840
N10F0760
EMERGENCIES 295
8

Front side marker lights
Turn the light socket counterclockwise and pull it out and
remove the light bulb.
Front fog lights
1. Turn the front turn signal light socket counterclock-
wise.
N10D0170
N10F0760
296 EMERGENCIES

2. Turn the light socket counterclockwise and pull it out. 3. Pull both clips away from the center as shown and
remove the bulb from the socket by pulling out.
N10X1650
N10C1700
EMERGENCIES 297
8

CAUTION!
²Never hold the halogen light bulb with a bare
hand, dirty glove, etc. The oil from your hand
could cause the bulb to break the next time the fog
lights are operated.
If the glass surface is dirty, it should be cleaned
with alcohol and installed after drying thor-
oughly.
Rear combination lights
1. Turn the trim cover clip (A) counterclockwise and
remove the trim cover clip. Partially remove the trim
cover in the trunk.
N10C1840
N20I0170
298 EMERGENCIES

2. Remove the light case mounting nuts. Disconnect the
connector.
3. Slide the light unit outward to remove it. Remove each
bulb socket assembly by turning it counterclockwise.Remove the bulb from the socket by turning it counter-
clockwise while pressing it inward.
N20I0160N20I0100
A - Stop and tail light
B - Rear turn signal light
C - Back up light
D - Rear side marker light
EMERGENCIES 299
8

High-mounted stop light
Remove the socket assembly and bulb together by turn-
ing it counterclockwise.
Remove the bulb from the socket by pulling out.
License plate light
Remove the lens mounting screws, remove the socket
assembly and the bulb together by turning it counter-
clockwise. And remove the bulb by pulling out.
N10V0700N10J0310
