CHRYSLER SEBRING SEDAN 2007 3.G Owners Manual

POWER SUNROOF — IF EQUIPPED
The sunroof controls are mounted between the sun visors
in the Dome / Reading Lamp.WARNING!
•Never leave children in a vehicle, with the keys in
the ignition switch. Occupants, particularly unat-
tended children, can become entrapped by the
power sunroof while operating the power sunroof
switch. Such entrapment may result in serious
injury or death.
•In an accident, there is greater risk of being
thrown from a vehicle with an open sunroof. You
could also be seriously injured or killed. Always
fasten your seat belt properly and make sure all
passengers are properly secured too.
•Do not allow small children to operate the sun-
roof. Never allow fingers or other body parts, or
any object to project through the sunroof opening.
Injury may result.
Power Sunroof Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121
3

Opening Sunroof - Manual
Press the switch rearward and hold, and the sunroof will
open automatically from any position. The sunroof will
open fully, then stop automatically. During this opera-
tion, any release of the sunroof switch will stop the
sunroof.
Opening Sunroof - Express
Press the switch rearward and release, and the sunroof
will open automatically from any position. The sunroof
will open fully, then stop automatically. This is called
Express Open. During Express Open operation, any
movement of the sunroof switch will stop the sunroof.
Closing Sunroof - Manual
To Close the sunroof from an open or vent position, press
andholdthe switch forward. The sunroof will close fully
and stop automatically. Release the switch to stop sun-
roof travel at any point.
Venting Sunroof - Express
Press and release theVbutton, and the sunroof will
open to the vent position. This is called Express Vent.
Closing Sunroof - Express
Press the switch forward and release, and the sunroof
will close automatically from any position. The sunroof
will close fully, then stop automatically. This is called
Express Close. During Express Close operation, any
movement of the sunroof switch will stop the sunroof.
Auto Sunroof (Express) with Anti–Pinch
Protection — If Equipped
During express closing, anytime an obstacle that restricts
glass movement is detected, the motor will stop and
reverse travel to avoid pinching the object.
WARNING!
There is no anti-pinch protection when the sunroof
is almost closed. To avoid personal injury, be sure to
clear your arms, hands, fingers and all objects from
the sunroof path before closing.
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Sunshade Operation
The sunshade can be opened manually. However, the
sunshade will open automatically as the sunroof opens.
NOTE:The sunshade cannot be closed if the sunroof is
open.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if so equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
the rear windows open, then open the front and rear
windows together to minimize the buffeting. If the
buffeting occurs with the sunroof open, adjust the sun-
roof opening to minimize the buffeting.
Sunroof Maintenance
Use only a non abrasive cleaner and a soft cloth to clean
the glass panel.
Ignition Off Operation
For vehicles not equipped with the Electronic Vehicle
Information Center (EVIC), the power sunroof switch
will remain active for 10 minutes after the ignition switch
is turned off. Opening either front door will cancel this
feature.
For vehicles equipped with the EVIC, the power sunroof
switch will remain active for up to 60 minutes after the
ignition switch is turned off. Opening either front door
will cancel this feature. The time is programmable. For
details, refer to “Delay Power Off to Accessories Until
Exit,” under “Personal Settings (Customer Program-
mable Features),” under “Electronic Vehicle Information
Center (EVIC)” in Section 4 of this manual.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123
3

ELECTRICAL POWER OUTLETS
There are two 12-volt electrical outlets on this vehicle.
Both of the outlets are protected by a fuse.
The 12-volt power outlet next to the ash receiver tray (if
equipped with an optional Smoker’s Package) has power
available only when the ignition is on. This outlet will
also operate a conventional cigar lighter unit.
NOTE:If desired, the power outlet next to the ash
receiver tray (if equipped) can be converted by your
authorized dealer to provide power with the ignition
switch in the LOCK position.
The center console outlet is powered directly from the
battery (power available at all times). Items plugged into
this outlet may discharge the battery and/or prevent
engine starting.
Instrument Panel Power Outlet
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

ELECTRICAL POWER INVERTER — IF EQUIPPED
There is a 115 VAC (150-Watts
Maximum) outlet in the cen-
ter console for added conve-
nience. This outlet can power
cell phones, electronics, and
other low power devices.
NOTE:Due to built-in overload protection, the inverter
will shut down if the power rating is exceeded.
WARNING!
To Avoid Serious Injury or Death:
•Do not use a 3-Prong Adaptor.
•Do not insert any objects into the receptacles.
•Do not touch with wet hands.
•Close the lid when not in use.
•If this outlet is mishandled, it may cause an
electric shock and failure.Console Interior
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125
3

Electrical Outlet Use With Engine Off
CAUTION!
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not
in use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
•Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.) will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
•After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.
CIGAR LIGHTER AND ASH RECEIVER
The covered ash receiver is located in the instrument
panel below the climate control knobs.
The cigar lighter is located to the right of the ash receiver.
As a child safety precaution, the lighter only operates
with the ignition switch ON. It heats when pushed in and
pops out automatically when ready for use.To preserve
the heating element, do not hold the lighter in the
heating position.
Cup Holder Ash Receiver — If Equipped
Should your vehicle not come equipped with the instru-
ment panel cigar lighter and ash receiver, an optional ash
receiver is available from your authorized dealer and will
fit in either one of the center console cup holders.
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
If your vehicle is equipped with the heated and
cooled cup holder, locate the cup holder ash receiver
in the forward cup holder.
The optional ash receiver also comes with a cigar lighter.
You may use the power outlet, located in the instrument
panel below the climate control knob, or in the bottom of
the console compartment, for this cigar lighter.
Optional Cup Holder Ash Receiver
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127
3

CONSOLE FEATURES
Console Features
The center console armrest slides forward from design
position to provide added user comfort. Two cup holders,
each of which can accommodate large sized fast food
beverage containers. A one piece cup holder insert for
both cavities can easily be removed for cleaning. The cup
holders will also accommodate large size cups and 20 oz.
bottles. (An optional removable ashtray may be located
in the one cup holder.)
Dual Storage Bins
Lifting a latch at the front of the hinged armrest provides
access to these storage areas.
•The Left Latch opens to the top storage area.
Console Features
1 — Release button for top compartment
2 — Release button for bottom compartment
3 — Top Compartment
4 — Bottom Compartment 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

•The lower bin can be accessed directly, without first
exposing the upper bin, by operating the right latch
with the armrest down.
•The first storage bin can be used to hold smaller items.
•The lower storage bin includes a molded-in coin
holder, room for CD’s, DVD’s, and a power outlet that
allows a cell phone to recharge while concealed.
NOTE:A notch in the side of the console base under the
armrest will also allow use of cell phone while still
plugged into the power outlet and with the armrest
latched down.
NOTE:The power outlet located inside the console can
also energize the cigar lighter in the available Smoker’s
Package.
Video Console — If Equipped
The optional VES™(Video Entertainment System) in-
cludes the following components:
•The screen for a rear seat DVD player is stored under
the armrest.
•Remote Control
•Audio / Video RCA Jacks
Video Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129
3

CUP HOLDERS
Heated or Cooled Cup Holder — If Equipped
With this feature the rear cavity of the cup holder can
heat or cool the beverage container it is holding. The rear
cup holder can heat from room temperature (70°F /21°C),
to 140°F (60°C) or cool it to near freezing, 0°F (–20°C).
The switch is located on the front of the center console
and has three positions: HEAT, OFF, COOL.
When the unit is on and the LED is Red, the cup holder
is being heated. When the LED is Blue, the cup holder is
being cooled.
A special mug is included with this feature and is
specially designed to work best with this system.
Cooled or Heated Cup Holder
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
