CHRYSLER SEBRING SEDAN 2007 3.G Owners Manual

Rear Bottle Holders
There are built-in bottle holders located in both rear door
trim panels.WARNING!
If containers of hot liquid are placed in the bottle
holder, they can spill when the door is closed,
burning the occupants. Be careful when closing the
doors to avoid injury.
Rear Bottle Holder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131
3

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instrument Panel Features...............136

Instrument Cluster—Base................137

Instrument Cluster—Premium............138

Instrument Cluster Descriptions...........139

Electronic Vehicle Information Center
(EVIC) – If Equipped
...................147
▫Electronic Vehicle Information Center
(EVIC) Displays......................147
▫EVIC Functions.......................148
▫Trip Functions.......................149
▫To Reset The Display...................150
▫Compass Display.....................150▫Telephone — If Equipped...............153
▫Navigation — If Equipped...............154
▫Personal Settings
(Customer Programmable Features)........155

Setting The Analog Clock................157

Electronic Digital Clock.................158
▫Clock Setting Procedure.................158

Radio General Information...............158
▫Radio Broadcast Signals.................158
▫Two Types Of Signals..................158
▫Electrical Disturbances..................159
▫AM Reception.......................159
4

▫FM Reception........................159

Sales Code REQ — AM/FM Stereo Radio
And 6–Disc CD/DVD Changer
(MP3/WMA Aux Jack)
..................159
▫Operating Instructions - Radio Mode.......160
▫Operation Instructions -
(Disc Mode For CD And MP3/WMA
Audio Play, DVD-Video)................166
▫Notes On Playing MP3/WMA Files........168
▫List Button
(DiscModeForMP3/WMAPlay)..........170
▫Info Button
(DiscModeForMP3/WMAPlay)..........170

Sales Code RES — AM/FM Stereo Radio
With CD Player (MP3 Aux Jack)
...........172
▫Operating Instructions - Radio Mode.......172
▫Operation Instructions - CD Mode For
CD And MP3 Audio Play...............176▫NotesOnPlayingMP3Files .............178
▫List Button (CD Mode For MP3 Play).......180
▫Info Button (CD Mode For MP3 Play).......180

Sales Code RER — AM/FM/CD/DVD
Radio With Navigation System —
If Equipped
..........................181
▫Operating Instructions — Satellite Radio.....182
▫Clock Setting Procedure.................182

Satellite Radio — If Equipped.............183
▫System Activation.....................183
▫Electronic Serial Number/Sirius Identification
Number (ENS/SID)....................183
▫Selecting Satellite Mode (RSC Radios).......184
▫Satellite Antenna......................184
▫Reception Quality.....................184
▫Operating Instructions - Satellite Mode......184
134 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Operating Instructions -
Hands Free Phone (If Equipped)..........186
▫Operating Instructions - Video Entertainment
System (VES®)(If Equipped)............186

Video Entertainment System —
If Equipped
..........................187

Radio Operation And Cellular Phones.......188

Remote Sound System Controls —
If Equipped
..........................188
▫Radio Operation......................189▫CD Player..........................189

CD/DVD Disc Maintenance..............189

Climate Controls......................190
▫Manual Air Conditioning
And Heating System...................190
▫Automatic Temperature Control (ATC)—
If Equipped.........................194
▫Operating Tips.......................199
▫Electric Rear Window Defroster...........202
UNDERSTANDING YOUR INSTRUMENT PANEL 135
4

INSTRUMENT PANEL FEATURES
Instrument Panel
136 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER—BASE
UNDERSTANDING YOUR INSTRUMENT PANEL 137
4

INSTRUMENT CLUSTER—PREMIUM
120 MPH Cluster with EVIC
138 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER DESCRIPTIONS
1. Fuel Gauge
When the ignition switch is in the ON position,
the pointer will show the level of fuel remaining
in the fuel tank.
2. Fuel Door Reminder
This is a reminder that the Fuel Filler Door is
located on the left side of the vehicle.
3. Temperature Gauge
The temperature gauge shows engine coolant
temperature. Any reading below the red area of
the gauge shows that the engine cooling system
is operating properly. The gauge pointer may show a
higher than normal temperature when driving in hot
weather, up mountain grades, in heavy stop and go
traffic, or when towing a trailer.
If the pointer rises to theH(red) mark, the instrument
cluster will sound a chime. Pull over and stop the vehicle.
Idle the vehicle with the air conditioner turned off untilthe pointer drops back into the normal range. If the
pointer remains on theH(red) mark, turn the engine off
immediately and call for service.
There are steps that you can take to slow down an
impending overheat condition. If your air conditioning is
on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
control to maximum heat, the Mode control to Floor and
the Fan control to High. This allows the heater core to act
as a supplement to the radiator and aids in removing heat
from the engine cooling system.
4. Speedometer
Indicates vehicle speed.
5. Tachometer
The white area of the scale shows the permissible engine
revolutions-per-minute (rpm x 1000) for each gear range.
Before reaching the red area, ease up on the accelerator to
prevent engine damage.
UNDERSTANDING YOUR INSTRUMENT PANEL 139
4

6. Low Fuel Light
When the fuel level drops to 2 gallons, the fuel
symbol will light and a single chime will sound.
7. Charging System Light
This light shows the status of the electrical
charging system. The light should come on
briefly when the ignition is first turned on and remain
on briefly as a bulb check. If the light stays on or
comes on while driving, turn off some of the vehicle’s
electrical devices, such as the Fog Lights or Rear
Defroster. If the Charging System Light remains on, it
means that the vehicle is experiencing a problem with
the charging system. Obtain SERVICE IMMEDI-
ATELY. See your local authorized dealer.
8. Airbag Light
The light comes on and remains on for 6 to 8
seconds as a bulb check when the ignition
switch is first turned ON. If the light does
not come on during starting, stays on, or
comes on while driving, have the system checked by
an authorized dealer.9. Theft Alarm Light — If Equipped
This light will flash rapidly for several seconds when the
alarm system is arming. The light will begin to flash
slowly indicating that the system is armed.
10. Seat Belt Reminder Light
When the ignition switch is first turned ON, this
light will come on for about six seconds. A
chime will sound if you have not pulled the
shoulder belt out of the retractor. This is a reminder to
“buckle up”. If you do not buckle up, the light will
remain on.
11. Oil Pressure Light
Shows low engine oil pressure. The light will
come on and remain on when the ignition
switch is turned from the OFF to the ON position, and
the light will turn off after the engine is started. If the
bulb does not come on during starting, have the
system checked by an authorized dealer.
If the light comes on and remains on while driving, stop
the vehicle and shut off the engine. DO NOT OPERATE
THE VEHICLE UNTIL THE CAUSE IS CORRECTED.
140 UNDERSTANDING YOUR INSTRUMENT PANEL
