8W-40 INSTRUMENT CLUSTER
Component Page
Airbag Control Module................ 8W-40-2
Body Control Module....... 8W-40-2, 3, 4, 5, 6, 7,
8, 9, 10, 11
Brake Fluid Level Switch.............. 8W-40-9
Clockspring......................... 8W-40-9
Diagnostic Junction Port...... 8W-40-2, 3, 4, 5, 6,
7, 8, 9, 12
Engine Control Module........... 8W-40-8, 9, 12
Engine Coolant Temp Sensor......... 8W-40-7, 8
Engine Oil Pressure Sensor........... 8W-40-12
Engine Oil Pressure Switch........... 8W-40-12
Front Control Module................. 8W-40-9
Fuel Pump Module................... 8W-40-2
Fuse 24............................ 8W-40-2
G200..................... 8W-40-2, 10, 11, 12
G300.............................. 8W-40-9
Instrument Cluster....... 8W-40-2, 3, 4, 5, 6, 7, 8,
9, 10, 11, 12
Integrated Power Module............ 8W-40-2, 9
Left Front Door Ajar Switch............ 8W-40-3
Left Front Door Lock Motor/Ajar Switch . . . 8W-40-3
Left Sliding Door Control Module........ 8W-40-4
Left Sliding Door Latch Sensing Switch . . . 8W-40-4Component Page
Left Sliding Door Lock Motor/Ajar
Switch........................... 8W-40-4
Left Speed Control Switch............. 8W-40-9
Liftgate Ajar Switch.................. 8W-40-3
Liftgate Cinch/Release Motor........... 8W-40-3
Message Center................... 8W-40-6, 12
Multi- Function Switch................ 8W-40-6
Parking Brake Switch............. 8W-40-10, 11
Powertrain Control Module........ 8W-40-7, 9, 12
Right Front Door Ajar Switch........... 8W-40-3
Right Front Door Lock Motor/Ajar
Switch........................... 8W-40-3
Right Sliding Door Control Module....... 8W-40-5
Right Sliding Door Latch Sensing
Switch........................... 8W-40-5
Right Sliding Door Lock Motor/Ajar
Switch........................... 8W-40-5
Right Speed Control Switch............ 8W-40-9
Traction Control Switch............. 8W-40-7, 8
Transmission Control Module........... 8W-40-7
Vehicle Speed Sensor............... 8W-40-7, 8
Washer Fluid Level Switch............. 8W-40-9
RS8W-40 INSTRUMENT CLUSTER8W-40-1
