8W-53 WIPERS
Component Page
A/C-Heater Control................... 8W-53-7
Accessory Relay..................... 8W-53-3
Body Control Module........... 8W-53-3, 5, 6, 7
Front Control Module........... 8W-53-2, 3, 4, 5
Front Wiper High/Low Relay........... 8W-53-2
Front Wiper On/Off Relay............. 8W-53-2
Fuse 4............................ 8W-53-2
Fuse 11............................ 8W-53-3
Fuse 30............................ 8W-53-4
G102.............................. 8W-53-4
G200............................ 8W-53-6, 7
G300.............................. 8W-53-2
G301.............................. 8W-53-5Component Page
G303.............................. 8W-53-3
Headlamp Washer Pump Motor......... 8W-53-4
Headlamp Washer Relay.............. 8W-53-4
Instrument Panel Switch Bank......... 8W-53-6
Integrated Power Module........ 8W-53-2, 3, 4, 5
Multi-Function Switch................ 8W-53-5
Rear Wiper Motor.................... 8W-53-3
Rear Wiper/Washer Indicator........... 8W-53-7
Rear Wiper/Washer Switch............. 8W-53-7
Washer Fluid Level Switch............. 8W-53-4
Washer Pump Motor.................. 8W-53-3
Wiper Module....................... 8W-53-2
RS8W-53 WIPERS8W-53-1
