BATTERY
Before disconnecting the battery, you
must  wait   for   2   minutes   after   switching
of
f   the   ignition.
Never
  disconnect   a   terminal   when   the
engine
  is   running.
Never
  charge   a   battery   without   first
disconnecting
  the   terminals.
a
fter every reconnection of the battery,
switch
  on   the   ignition   and   wait   1   minute
before starting to allow the electronic
systems
  to   be   initialised.   If   problems
remain
  after   doing   this,   please   contact
a
  CITROËN   dealer   or   a   qualified
workshop.
a
fter changing bulbs, wait
approximately
  3   minutes   before
reconnecting
  the   battery.
 It is advisable to disconnect the
battery if the vehicle is not to be
used

for

a

period

of

more

than

one month.
To charge the battery using a
battery charger
- Disconnect   the   battery.
-
Follow the instructions for use
given by the battery charger
manufacturer
.
-

Reconnect starting with the
negative
  (-)   terminal.
-

Check
   that   the   terminals   and
connectors
  are   clean.   If   they   are
covered with sulphate (white or
greenish
  deposit),   disconnect   them
and
  clean   them.
To start the vehicle from
another battery
- Connect the red cable to the
positive  (+)   terminals   of   the
two batteries.
-

Connect one end of the green
or
  black   cable   to   the   negative   (-)
terminal
  of   the   slave   battery.
-

Connect the other end of the green
or
  black   cable   to   an   earth   point   on
the
  broken   down   vehicle   as   far   as
possible
  from   the   battery.
-
 Operate
  the   starter,   let   the   engine   run.
-

W
 ait for the engine to return to idle,
then
  disconnect   the   cables.
The presence of this label
indicates the use of a 12 V
lead-acid battery with special
technology

and

specification,

for

which

the

involvement

of

a

CITROËN

dealer

or

qualified

workshop

is

required

when

replacing

or

disconnecting

the

battery.
Failure to observe this
recommendation

may

cause

premature
 wear

of

the

battery.
After

refitting

the

battery,

the

Stop &

Start

system

will

only

be

active

after

several hours depending on the
climatic

conditions

and

the

state

of

charge of the battery (up to about
8 hours).
The Stop & Start battery does not have
to

be

disconnected

for

charging.
Battery
QUICk HELP
8
Page 172 of 292

170
Berlingo-2-VP_en_Chap08_aide-rapide_ed02-2015
ECONOMY MODE
after the engine has stopped, with
the   key   in   the   ignition   position,   certain
functions (windscreen wiper
, electric
windows,
  courtesy   lamps,   audio
equipment,
  etc.)   can   only   be   used   for   a
cumulative
  duration   of   thirty   minutes,   to
prevent
  discharging   of   the   battery.
Once
  the   thirty   minutes   have   elapsed,
the active functions are put on standby
and
  the   battery   warning   lamp   flashes
accompanied
  by   a   message   in   the
screen.
T
o   resume   the   use   of   these   functions
immediately
,   start   the   engine   and   let   it
run
  for   a   few   minutes.
The
  time   available   will   then   be   double
the
  time   for   which   the   engine   was   left
running.
  However,   this   time   will   always
be
  between   five   and   thirty   minutes.
A

flat   battery   will   prevent   the
engine
  from   starting.
Battery
Page 173 of 292

171
Berlingo-2-VP_en_Chap08_aide-rapide_ed02-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed02-2015
The temporary tyre repair kit consists of  a   compressor   and   a   bottle
(containing
  a   sealant).
Using the kit
1. Tick  the   deflated   wheel   on   the  speed
  limitation   sticker   then   affix
the
  sticker   to   the   vehicle's   steering
wheel
  to   remind   you   that   a   wheel   is
in
  temporary   use.
2.

Clip the bottle
 1 on the
compressor 2.
3.

Connect the bottle
 1 to the valve of
the
  tyre   to   be   repaired.
4.

T
 ake   care   to   unwind   the
compressor
  pipe   before   connecting
it
  to   the   bottle.
5.

Connect the power lead to one of
the
  vehicle's   12V   sockets.
6.

Switch
   on   the   compressor   by
pressing button
A until the tyre
pressure
  reaches   2.0   bars.   If   this
pressure cannot be reached, the
tyre
  cannot   be   repaired.
7.

Remove
   and   store   the   compressor.
8.

Drive
   immediately,   for   a   few   miles
(kilometres),
  at   reduced   speed,
to
  fill   the   puncture.
9.

Adjust
   the   pressure   using   the
compressor
  in   accordance   with   the
recommendation

for

the

vehicle

and

check
  that   the   leak   is   filled   correctly
(no
  further   loss   of   pressure).
10.

Drive
   at   reduced   speed   (50 mph
[80
  km/h]).
The
   tyre   must   be
examined
  and   repaired   by   a
specialist
  as   soon   as   possible.
a
 fter use, the bottle can be stored in
a   plastic   bag,   supplied   in   the   kit,   to  avoid staining your vehicle with traces
of
  fluid.
Warning:
  the   bottle   of   gel   contains
ethylene-glycol, a product which
is
  harmful   if   swallowed   and   which
causes
  irritation   to   the   eyes.
Keep
  it   out   of   reach   of   children.
a
fter use, do not discard the bottle into
the
  environment,   take   it   to   a   CITROËN
dealer or to an specialised waste
disposal
  site.
Replacement
  bottles   of   sealant   are
available
  from   CITROËN   dealers.
TEMPORARY PUNCTURE
REP
AIR   KIT
The kit is located in one of the two storage   compartments   located
under
  the   front   seats.
Vehicles
  supplied   with   a   temporary
puncture
  repair   kit   do   not   have   a   spare
wheel
  or   tooling   (jack,   wheelbrace,   ...).
QUICk HELP
8
Changing a wheel
Page 174 of 292

172
Berlingo-2-VP_en_Chap08_aide-rapide_ed02-2015Berlingo-2-VP_en_Chap08_aide-rapide_ed02-2015
1. Parking the vehicle
- The  occupants   must   get   out   of   the  vehicle
  and   wait   in   a   safe   location.
-

If
   possible,   park   the   vehicle   on
level, stable and non-slippery
ground.
-

Apply
   the   parking   brake,   switch
of
f   the   ignition   and   engage   first   or
reverse
  gear. -
 Place   a   chock   under   the   wheel  diagonally opposite the one to be
changed.
CHANGING A WHEEL
2. T
ools
The tools are stowed in a storage area
closed  by   a   flap   under   a   front   seat.
-

If
   necessary,   move   the   seat   forward
to
  access   the   storage   compartment
from
  the   rear.
-

Remove
   the   flap   then   take   out   the
jack
  and   the   tool   carrier.
-

Remove
   the   tools   needed   from   the
carrier
.
1.

Jack.
2.

Wheelbrace.
3.

Chock.
4.

Spanner for the Modutop roof bars
and
  rear   lamps.
5.

Alloy
   wheel   trim   removal   tool.
6.

T
 owing   eye.
If

the

vehicle

is

fitted

with

a

towbar,

it

is

sometimes

necessary

to

raise

the

vehicle

slightly

to

make

it

easier

to

remove

the

spare

wheel

from

its

carrier
.
On

certain

types

of

ground

and/
or if considerable loads are being
transported, call a CITR
o
Ë
n
 dealer or
a

qualified

workshop.
The

jack

and

tools

are

specific

to

your

vehicle.

Do

not

use

them

for

other

purposes.
Changing a wheel
