160
Removing a wheel
F Remove  the   label   from   the   middle   of   the  s
pare   wheel   (indicating   that   a   wheel   needs
r

epair),   and   fix   it   inside   the   vehicle,   where
t

he   driver   can   see   it.
F

R
emove   the   wheel   trim   using   the   end   of   the
w

heelbrace.
F

S
lacken   the   wheel   bolts   using   the
w

heelbrace 1 . F
 P osition   the   foot   of   the   jack   2   on   the   ground  a
nd   ensure   that   it   is   directly   below   one
o

f   the   jacking   points   A or B   located   on
t

he   underbody,   closest   to   the   wheel   to   be
c

hanged.
Ensure
  that   the   jack   is   stable.   If   the   ground   is   slippery   or   loose,   the   jack   may   slip   or   drop   -
R

isk   of   injury!
Ensure
  that   the   jack   is   positioned   only   at   one   of   the   jacking   points   A or B under   the   vehicle,
m

aking   sure   that   the   vehicle's   contact   area   is   centred   on   the   head   of   the   jack.   Other wise
t

here   is   a   risk   of   damage   to   the   vehicle   and/or   of   the   jack   dropping   -   Risk   of   injury!
F
 E xtend   the   jack   2   until   its   head   is   in   contact
w

ith   the   jacking   point   A or B   used.   The
c

ontact area A or B   on   the   vehicle   used
m

ust   engage   correctly   with   the   middle   of
t

he   head   of   the   jack.
In the event of a breakdown
