Citroen C3 PICASSO 2012 1.G Owner's Manual
Manufacturer: CITROEN, Model Year: 2012, Model line: C3 PICASSO, Model: Citroen C3 PICASSO 2012 1.GPages: 244, PDF Size: 8.21 MB
Page 1 of 244
Page 2 of 244
YOUR HANDBOOK
ON THE INTERNET!
CITROËN lets you view your vehicle's
documentation on line, to see earlier versions
and the latest information, simply and free of
charge.
Connect to http://service.citroen.com
:
1|
Select your language and register,
click on the link in the "Private customer access" zone to consult
the vehicle documentation; a window opens providing access to all
of the handbooks,
select your vehicle, choose the body type then the date of issue of
the handbook,
fi nally, click on the heading of your choice.
2|
3 |
4 |
Page 3 of 244
Your vehicle is fi tted with only some of the
equipment described in this document,
depending on the trim level, version and the
specifi cations for the country in which it is
sold.
The fi tting of electrical equipment or
accessories which are not recommended
by CITROËN may result in a failure of your
vehicle's electronic system. Please note this
specifi c warning and contact a CITROËN
dealer to be shown the recommended
equipment and accessories.
CITROËN has a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.
We draw your attention to the following...
At the wheel of your new vehicle,
getting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.
refer to the page indicated
Key
contributes to the protection of the environment
additional information
safety warning
Page 4 of 244
2
CONTENTS
Instrument panel 22Indicator and warning lamps 23Indicators 31Adjustment buttons 34
Ventilation 47Rear screen demist/defrost 49Heating 49Manual air conditioning 49Dual-zone digital air conditioning 51Scented air freshener 53Front seats 54Rear seats 56Mirrors 58Steering wheel adjustment 59
3 - COMFORT 47 Î 59
Remote control key 60Window controls 64
Doors 66Boot 68Panoramic sunroof 69Fuel tank 70Misfuel prevention (Diesel) 72
4 - ACCESS 60 Î 72
Lighting controls 73Headlamp adjustment 76Wiper controls 77Courtesy lamps 80Boot lamp 81
5 - VISIBILITY 73 Î81
Conventional child seats 92Isofi x child seats 97Child lock 100
7 - CHILD
SAFETY 92 Î 100 FAMILIARISATION 4
Î 19
1 - MONITORIN
G22 Î 34
Screen without audio equipment 35Screen with audio equipment 37Trip computer 44
2 - MULTIFUNCTION
SCREENS 35 Î 46
Front fi ttings 82Rear fi ttings 86Boot fi ttings 89
6 - FITTINGS 82 Î91
ECO-DRIVING 20 Î21
Page 5 of 244
3
CONTENTS
Direction indicators 101Hazard warning lamps 101Horn 101Emergency or assistance call 102Braking assistance systems 102Trajectory control systems 103Front seat belts 104Airbags 108
8 - SAFETY 101 Î111
Parking brake 1126-speed manual gearbox 112Gear effi ciency indicator 1136-speed electronic gearbox system 114Hill start assist 117Stop & Start 118Speed limiter 121Cruise control 123Rear parking sensors 125
9 - DRIVING 112 Î 126
Bonnet 128Running out of fuel (Diesel) 128Petrol engines 130Diesel engines 131Checking levels 132Checks 133
10 - CHECKS 127 Î134
Temporary puncture repair kit 135Changing a wheel 140Changing a bulb 144Changing a fuse 150Battery 157Energy economy mode 159Changing a wiper blade 159Towing the vehicle 160Towing a trailer 162Fitting roof bars 163Accessories 164
11 - PRACTICAL
INFORMATION 135 Î165
Petrol engines 166Petrol weights 167LPG engines 168LPG weights 169Diesel engines 170Diesel weights 171Dimensions 172Identifi cation markings 173
12 - TECHNICAL DATA166A Î173
AUDIOandTELEMATICS174 Î 230
ALPHABETICAL INDEX 231 Î 234
Emergency or assistance 175MyWay 177Audio system 209
