Comfort
56
programme
The automatic comfor t programme
may not be sufficient to quicklydemist or defrost the windscreen
and side windows
(humidity, several
passengers, ice, etc.).
)To switch the system off, press this buttonagain or on "AUTO"
. The indicator lamp in
the button goes off and the indicator lamp in the "AUTO"
button comes on.
With Stop & Start, when demisting hasbeen activated, the STOP mode is notavailable.
)Press this button to activate the automatic
visibility programme. The indicator lamp in
the button comes on. The system automatically controls the air conditioning, the air flow and the air intake andprovides optimum distribution of the ventilation
to the windscreen and side windows. I
f you wish, you can make a different choice
from that offered by the system by changing
a setting. The other functions will still be controlled automatically.) Pressing the "AUTO"
button returns thesystem to completely automatic operation.
For maximum cooling or heating of the passenger compar tment, it is possible to exceed the minimum value 14 or the maximum value 28.)Turn control 2
or 3
to the left until "LO"
is displayed or to the right until "HI"is displayed.


Manual operation
)
Press this button to switch off
the air conditioning.

5. Air conditioning On / Off

Switching the system off could result in
discomfort (humidity, condensation).)Press this button again to return to automatic operation of the air conditioning.The indicator lamp in the "A/C"
buttoncomes on.

4
Access
67
Locating your vehicle
)Press the closed padlock to locate your locked vehicle in a car park.
This is indicated by lighting of the cour tesylamps and flashing of the direction indicators for a few seconds.
Electronic engine immobiliser
The key contains an electronic chip which has a special code. When the ignition is switched
on, this code must be recognised in order for
starting to be possible.
This electronic engine immobiliser locks the
engine management system a few minutes after the ignition is switched off and prevents
starting of the engine by anyone who does not have the key.
Anti-theft protection
In the event of a fault, you are
informed by illumination of this
warning lamp, an audible signal
and a message in the screen.

Folding the key
)First press this button to fold the key.
If you do not press the button when foldingthe key, there is a risk of damage to themechanism.

Ignition switch



- Position 1: Stop

- Position 2: Ignition

- Position 3: Starting


Starting the vehicle

)
Inser t the key in the ignition switch.
The system recognises the star ting code.) Turn the key fully towards the dashboard toposition 3 (Starting).)
When the engine starts, release the key.
In this case,
your vehicle will not start; contact a CITROËN dealer as soon as possible.
Keep safely the label attached to the keys given
to you on acquisition of the vehicle.

Driving
126





Parking brake
Applying
)Pull the parking brake lever fully up toimmobilise your vehicle.


When the vehicle is being driven, if this
warning lamp and the STOPwarning lampcome on, accompanied by an audible
signal and a message on the multifunction
screen, this indicates that the parking brake is still on or has not been properly released.
Releasing
)Pull the parking brake lever gently, press
the release button then lower the lever fully.









6-speed manual
gearbox

Engaging 5th or 6th gear
)
Move the lever fully to the right to engage 5th or 6th gear.



Engaging reverse gear
)Raise the ring under the knob and move
the gear lever to the left then for wards.

When parking on a slope, direct your wheels against the pavement, apply the parking brake and engage a gear.

Only engage reverse gear when the vehicle is stationary with the engine at idle.

As a safety precaution and to facilitate starting of the engine:


- always select neutral,

- press the clutch pedal.

9
Driving
133








Stop & Start
The Stop & Star t system puts the engine temporarily into standby - STOP mode - during stops in the traffic (red lights, traffic jams, or other...). The engine restarts automatically - START mode - as soon as you want to move off. The restar t takes place instantly, quickly and silently.
Per fect for urban use, the Stop & Star t system reduces fuel consumption and exhaust emissions as well as the noise level when stationary.


Operation


Going into engine STOP mode
The "ECO"warning lamp comes
on in the instrument panel and the
engine goes into standby:


- with the 6-speed electronic
gearbox
system, at speeds below 5 mph (8 km/h),
when you press the brake pedal or put thegear lever in position N.
A time counter calculates the sum
of the periods in STOP mode
during a journey. It rests itself
to zero every time the ignition isswitched on with the key.


Special cases: STOP mode notavailable
STOP mode is not invoked when:


- the driver's door is open,

- the driver's seat belt is not fastened,

- the vehicle has not exceeded 6 mph (10 km/h) since the last engine star t using
the key,

- the engine is needed to maintain acomfor table temperature in the passenger compartment,

- demisting is active,

- some special conditions (battery charge,
engine temperature, braking assistance,
ambient temperature...) where the engine isneeded to assure control of a system.
The "ECO"
warning lamp flashes for a few seconds then goes off.
This operation is per fectly normal
.
Never refuel with the engine in STOPmode; you must switch off the ignition with the key.
For your comfor t, during parking manoeuvres, STOP mode is not available for a few seconds after coming out of reverse gear.STOP mode does not affect the functionality of the vehicle, such as for example, braking, power steering...

Driving
134
Going into engine START mode
The "ECO"warning lamp goes
off and the engine star ts with the electronic gearboxsystem:
- gear lever in position Aor M
, when yourelease the brake pedal,
- or gear lever in position Nand the brake pedal released, when you move the gear lever to position A
or M,- or when you engage reverse gear.



Special cases: START invoked
automatically
For reasons of safety and for your comfort,START mode is invoked automatically when:


- you open the driver's door,

- you unfasten the driver's seat belt,

- the speed of the vehicle exceeds 7 mph(11 k m/h) with the electronic gearbox system,

- some special conditions (battery charge,engine temperature, braking assistance,
ambient temperature...) where the engine is
needed for control of a system.
Th
e "ECO"
warning lamp flashes for
a
few seconds, then goes off.
This operation is per fectly normal.

Deactivation
At any time, press the "ECO OFF"
switch todeactivate the system.
This is confirmed by the switch warning lampcoming on accompanied by a message in the screen.


If the system has been deactivatedin STOP mode, the engine restartsimmediately.

Checks
144











Bonnet
)
Push the exterior safety catch B
to the leftand raise the bonnet.
)
Unclip the stay C
from its housing. )
Fix the stay in the notch to hold the bonnet open.


Closing
)Take the stay out of the support notch.)Clip the stay in its housing. )Lower the bonnet and release it at the end of its travel. )Pull on the bonnet to check that it is secured correctly.
)Open the front left door.)Pull the interior bonnet release lever A , located at the bottom of the door aper ture.
Opening
Before doing anything under the bonnet,
switch off the Stop & Star t system toavoid any risk of injury resulting from anautomatic change to START mode.

The location of the interior bonnetrelease lever prevents opening of the bonnet while the front left door is closed.

Do not open the bonnet in high winds.

When the engine is hot, handle theexterior safety catch and the bonnet stay with care (risk of burns).

Checks
150
Par ticle emission filter (Diesel)
The start of saturation of theparticle filter is indicated by the
temporary illumination of this warning lamp accompanied bya message in the multi-functionscreen.
On a new vehicle, the first particlefilter regeneration operations may be accompanied by a "burning" smell, which is perfectly normal.
Following prolonged operation of the vehicle at very low speed or at idle, you may, in exceptional circumstances,notice the emission of water vapour at the exhaust on acceleration. This does
not affect the behaviour of the vehicle or the environment.







Checks
12 V battery

The battery does not require any maintenance.
However, check that the terminals are clean
and correctly tightened, par ticularly in summer and winter.
Air filter and passenger compartment filter
Refer to the ser vicing booklet for
details of the replacement inter vals for these components.
Oil filter
Replace the oil filter each time theengine oil is changed.
Refer to the servicing booklet for
details of the replacement inter val for
t
his component. Unless other wise indicated, check these components in accordance with the ser vicin
g booklet and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
When carr
ying out work on the battery, refer
to the "12 V battery" section for details of theprecautions to be taken before disconnecting
the battery and following its reconnection.
The
presence of this label, in par ticular with
the Stop & Start system, indicates the use of a specific 12 V lead-acid battery with special
technology and specification. The involvement
of a CITROËN dealer or a qualified workshop is
essential when replacing or disconnecting the battery. Dependin
g on the environment (e.g. dusty
atmosphere) and the use of the vehicle (e.g.city driving), replace them twice as often if necessary.y A clogged passenger compar tment filter may
have an adverse effect on the performance
of the air conditioning system and generateundesirable odours.
As soon as the traffic conditions permit,
regenerate the filter by driving at a speed of at
least 40 mph (60 km/h) until the warning lampgoes off.
If the warning lamp stays on, this indicates a
low additive level.

11
Practical information
177
Fuse table
Fuse N°RatingFunctions
F
120 AEngine control unit supply, cooling fan unit control,multifunction engine control main relay.
F
215 AHorn.
F
310 AFront / rear wash-wipe.
F4 20
ADaytime running lamps.
F
515 ADiesel heater (Diesel engine), fuel pump(petrol engine)
F
610 A ABS/ESP control unit, ABS/ESP cut-off relay,secondary stop switch.
F7
10 AElectric power steering.
F
825 AStarter motor control.
F9
10 ASwitching and protection unit (Diesel).
F10
30 ADiesel engine injection pump valve, injectors and ignition coils (petrol engine) .
F1140 A Air conditioning fan.

Practical information
180











Battery


Access to the battery
Starting using another
battery
)Connect the red cable to the positive
terminal (+) of the flat battery A , then to the positive terminal (+) of the slave battery B.)Connect one end of the green or blackcable to the negative terminal (-) of the slave battery B . )Connect the other end of the green or black cable to the remote negative terminal (-) of your vehicle .)Start the slave vehicle.)Operate the star ter of the broken down
vehicle and let the engine run.
)Wait until the engine returns to idle anddisconnect the cables. The batter
y is located under the bonnet.
To gain access to it:)
open the bonnet using the interior releaselever, then the exterior safety catch, )
secure the bonnet stay, )
lift the plastic cover on the (+) terminal.

The presence of this label, in particular with the Stop & Star t system, indicatesthe use of a 12 V lead-acid battery withspecial technology and specification;the involvement of a CITROËN dealer or a qualified workshop is essential when replacing or disconnecting thebattery.
Failure to observe this recommendation may cause premature wear of thebattery.


After refitting the battery by a CITROËNdealer or a qualified workshop, theStop & Start system will only beactive after a continuous period of immobilisation of the vehicle, a period which depends on the climatic conditions and the state of charge of thebattery (up to about 8 hours).

Practical information
182








Energy economy mode

These functions are reactivated automaticallythe next time the vehicle is driven. )In order to resume the use of these
functions immediately, star t the engine and
let it run for a few minutes.
The time available to you will then be double
the period for which the engine is left running. However, this period will always be betweenfive and thir ty minutes.

Switching to economy mode
Once this period has elapsed, a message
appears on the multifunction screen indicating
that the vehicle has switched to economy mode
and the active functions are put on standby.
A flat battery prevents the engine from starting (refer to the corresponding paragraph).
If the telephone is being used at the same time on the eMyWay audionavigation system, it will be interrupted after 10 minutes. S
ystem which manages the period of use of certain functions to conserve a sufficient level
of charge in the battery.
After the engine has stopped, you can still use functions such as the audioequipment, windscreen wipers, dipped
beam headlamps, cour tesy lamps, etc. for a maximum combined period of thirty minutes.
This period may be greatly reduced if the
battery is not fully charged.
