Page 191 of 284
11
Practical information
189
"Multimedia":
semi-integral navigation systems, Bluetooth®
hands free kit, audio systems interfaced to steering mounted controls, speakers, DVD player, USB box, por table navigation systems,mapping update CD, Hi-Fi module, drivingaid assistant, Wi-Fi on board, rear multimediasupport, telephone and smartphone carriers, iPhone ®
charger, head-up display...®
or accessories which are not recommended by CITROËN may resultin a failure of your vehicle's electronicsystem and excessive electrical consumption. Please note this precaution. Youare advised to contact a CITROËNrepresentative to be shown the range of recommended equipment and
accessories.
Installation of radio communication transmitters
Before installing any after-market radio communication transmitter, you can
contact a CITROËN dealer for the specification of transmitters which canbe fitted (frequency, maximum power, aerial position, specific installationrequirements), in line with the VehicleElectromagnetic Compatibility Directive(2004/10 4/EC).
By visiting a CITROËN dealer, you canalso obtain cleaning and maintenance products (interior and exterior), including the ecological products inthe "TECHNATURE" range, productsfor topping up (screenwash fluid...), touch-up pens and paint aerosols theexact colour of your vehicle, recharges (cartridge for the temporary puncturerepair kit...), ....
Depending on the legislation in force in the country, it may be compulsoryto have a high visibility safety vest, warning triangle and spare bulbs and fuses available in the vehicle. The fitting of electrical equipment
Page 192 of 284
Practical information
190
Snow chains
In wintry conditions, snow chains improve traction as well as the behaviour of the vehicle when
braking
The snow chains must be fitted only to the front wheels. They must never be fitted to "space-saver" type sparewheels.
Take account of the legislation in forcein your country on the use of snow chains and the maximum running speed authorised.
Avoid driving on roads that have been cleared of snow, to avoid damaging your vehicle's tyres and the road surface. It is recommended that before you leave,you practise fitting the snow chains ona level and dry surface. If your vehicleis fitted with alloy wheels, check thatno par t of the chain or its fixings is in contact with the wheel rim.
All ori
ginal tyre sizes (15", 16 ", 17 ") can be fitted with chains.
Original tyresize Maximum linksize.
1
95 / 60 R15 9 mm
1
95 / 55 R16 9 mm
2
05 / 45 R17 7 mm
For more information on snow chains
, contact a
CITROËN dealer or a qualified workshop.
Advice on installation
)If you have to fit the chains during ajourney, stop the vehicle on a flat surface on the side of the road. )Apply the parking brake and position anywheel chocks to prevent movement of your
vehicle. )Fit the chains following the instructionsprovided by the manufacturer. )Move off gently and drive for a fewmoments, without exceeding 30 mph (50 km/h). )Stop your vehicle and check that the snow chains are correctly tightened. Use onl
y the chains designed to be fitted to the
type of wheel fitted to your vehicle:
Page 193 of 284
12
Technical data
191
*
For Russia only.
**
The maximum power quoted is the type approved value obtained on a test bed, under the conditions defined in European legislation (directive 1999/99/CE).
PETROL ENGINESVTi 95VTi 115*VTi 120VTi 115 *VTi 120
Model codes:SH...8FP05FJ0*5FS05FJ8/P *5FS8/P
Cubic capacity (cc)
1 397 1 598 1 598
Bore x stroke
(mm)
77 x 75
77 x 85.8
77 x 85.8
Max power: EU standard (kW) **
70
84 *
88
84 *
88
Max power en
gine speed (rpm) 6 000
5 200
*
6 000
5 200
*6 000
Max torque: EU standard (Nm)13 6160
160
Max torque en
gine speed (rpm)
4 000
4 250
4 250
Fuel Unleaded
Unleaded
Unleaded
Catal
ytic converter yesyes yes
GEARBOXE
S
Manual(5-speed)
Manual (5-speed)Electronic gearbox system (6-speed)
OIL CAPACITIES
(in litres)
Engine (with filter replacement)
4.254.25 4.25
Engines and gearboxes
Page 194 of 284
Technical data
192
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
* For Russia only. ** The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
PETROL ENGINESVTi 95VTi 115*VTi 120VTi 115 * VTi 120
GearboxesManualManualElectronic gearbox system (6-speed)
Model codes:SH...8FP05FJ0 *5FS05FJ8/P *5FS8/P
- Unladen wei
ght 1 201
1 204 1 205
- Kerb wei
ght
1 276
1 279
1 280
-
Payload
546
549
564
-
Gross vehicle weight (GVW)1747
1 753
1 769
-
Gross train weight (GTW)on a 12% gradient
2 597
2 603
2 619
- Braked trailer (within GTW limit)
on a 10% or 12% gradient 850
850850
- Braked trailer **
(with load transfer within theGTW limit)1 100
1 100
1 100
-
Unbraked trailer
635
635
640
- Recommended nose weight
54 54 54
Weights and towed loads (kg)
Page 195 of 284
12
Technical data
193
LPG ENGINEVTi 95
Model codes:SH...8FN0/GPL
Cubic capacit
y (cc)
1 397
Bore x stroke
(mm) 77 x 75
Max. power: EU standard
(kW) *
70
Max. power speed
(rpm)
6 000
Max torque: EU standard
(Nm)
13 6
Max. torque speed (rpm)
4 000
Fuel LPG / Unleaded
Catal
ytic converter
Yes
GEARBOX
Manual(5-speed)
OIL CAPACITY (in litres)
En
gine (with filter replacement)
4.25
*
The maximum power quoted is the type approved value obtained on a test bed, under the conditions defined in European legislation (directive 1999/99/CE).
Engine and gearbox
Page 196 of 284
Technical data
194
LPG ENGINEVTi 95
GearboxManual
Model codes:SH...8FN0/GPL
- Unladen wei
ght
1 301
- Kerb wei
ght
1 376
-
Payload446
- Gross vehicle weight (GVW)1747
- Gross train weight (GTW)on a 12 % slope
2 597
- Braked trailer
(within GTW limit)
on a 12 % slope 850
- Braked trailer * (with load transfer within theGTW limit)
1 100
- Unbraked trailer
650
- Recommended nose wei
ght
54
* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
Weights and towed loads (kg)
Page 197 of 284
12
Technical data
195
DIESEL ENGINESHDi 90 PEFe-HDi 90 PEFHDi 115 PEF
Model codes: SH...9HP09HP8/P/S9HD8
Cubic capacity (cc) 1 5601 560
1 560
Bore x stroke (mm)
75 x 88.3
75 x 88.375 x 88.3
Max power: EU standard
(kW) *
68
68
84
Max power en
gine speed (rpm)
4 000
4 000
3 600
Max torque: EU standard (Nm)230
230
270
Max torque engine speed (rpm)
1 750 1 750 1 750
Fuel Diesel Diesel
Diesel
Catal
ytic converter yes yesyes
P
article emission filter yes
yesyes
GEARBOXE
SManual (5-speed)
Electronic gearbox system(6-speed)Manual (6-speed)
OIL CAPACITIES
(in litres)
Engine (with filter replacement) 3.75
3.753.75
.../
S : e-HDi model fitted with Stop & Star t.
Engines and gearboxes
*
The maximum power quoted is the type approved value obtained on a test bed, under the conditions defined in European legislation (directive 1999/99/CE).
Page 198 of 284
Technical data
196
* The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
DIESEL ENGINESHDi 90 PEFe- HDi 90 PEFHDi 115 PEF
GearboxesManualElectronic gearbox systemManual
Model codes:SH...9HP09HP8/P/S9HD8
- Unladen weight 1 2771 313
1 318
- Kerb wei
ght
1 3521 388
1 393
-
Payload
502 498
489
-
Gross vehicle weight (GVW)
1 779
1 811
1 807
-
Gross train weight (GTW)
on a 12% gradient
2 979
3 011
2 757
- Braked trailer
(within GTW limit)
on a 10% or 12% gradient 1 2001 200
950
- Braked trailer * (with load transfer with the GTW limit)
1 2001 200
1 200
- Unbraked trailer
675
675
675
- Recommended nose wei
ght 54
54 54
The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit th
e towed load.
Weights and towed loads (kg)
Page 199 of 284
12
Technical data
197
Dimensions (in mm)
Page 200 of 284
Technical data
198
Identifi cation markings Various visible markings for the identification of your vehicle.
A.Vehicle Identification Number (VIN) on
the front right door pillar.This number is engraved on the bodyworknear the hinge.
For access to it, open the right-hand door.B
.VIN on the windscreen lower crossmember. The number is on a self-adhesive label
which is visible through the windscreen.
C.Manufacturer's label. This number is indicated on a self-
destroying label affixed to the centre pillar,
on the left-hand side.
The inflation pressures must be checked when the tyres are cold,at least once a month.
If the inflation pressures are too low, this increases fuel consumption.
D.Tyre/paint label. This label is affixed to the centre pillar, on the left-hand side.
It bears the followin
g information:
- the tyre inflation pressures with and withoutload,
- the wheel rim and tyre sizes,
- the brands of tyre recommended by the manufacturer,
- the inflation pressure of the spare wheel,
- the paint colour code.
