Familiarisation
4
After the ignition has been switched off, the headlamps remain on briefly to make your exit from the vehicle easier when the light is poor.
ASR and ESP systems
These systems are linked to assure the
directional stability o
f the vehicle, within the
limits of the laws of physics.

Glass panoramic sunroof

This roof provides incomparable visibility and light in the passenger compartment.
Rear parking sensors / Reversing camera
These two systems warn you if an obstacle is detected behind the vehicle
when reversing.
11
7
Stop & Start
This system puts the engine
temporarily into standby
during stops in the traffic (red lights, traffic jams, etc....). The
engine restar ts automatically as soon as you want to move
off. The Stop & Start systemreduces fuel consumption, exhaust emissions and thenoise level when stationary.
Exterior
14 0 / 142
83
133

.Familiarisation
9
1. Steering lock and ignition. 2.Audio equipment steering mounted control stalk.3.Wiper / screenwash / trip computer controlstalk.4.
Central adjustable air vents.
5. Storage tray.
Scented air freshener.
6
.Sunshine sensor.
7. Passenger's air bag. 8.Side adjustable air vent.9.
Passenger's airbag deactivation switch.10.Glove box.11.
Dynamic stability control (ESP/ASR) switch
Parking sensors switch.
Central locking switch.
Hazard warning lamps switch.

Stop & Star t switch. 12. Heating / air conditioning controls.13.Audio equipment. 14.Emergency or assistance call. 15.12 V socket (100 W max).16.
USB por t / auxiliary socket.17.Cup holder. 18.Heated seat controls.19.
Parking brake.

Instruments and controls

.Familiarisation
15

Tr a n s l u c e n t d igital
instrument panel


Switch panels

If the levels are not correct, top up the levels
which are low.A.With the ignition on, the level of fuelremaining is displayed in the digitalinstrument panel B. With the ignition on, the oil level indicator should display "OIL OK"for a few seconds. Li
ghting of the indicator lamp indicates the status of the corresponding function.A.Deactivation of the ESP/ASR system. With the i
gnition on, the orange and red
warning lamps come on.
With the engine running, these warning lampsshould go off almost immediately, with theexception of the warning lamp C(passenger's front airbag activated) which goes off after
approximately one minute.
I
f warning lamps remain on, refer to the
relevant page.

Warning lamps

Monitoring
2223117
141
73
134
B. Deactivation of the rear parking sensors.
C.
Central locking.
D.Deactivation of Stop & Start.

3
Comfort
51
In order for these systems to be fully effective, follow the guidelines on operation andmaintenance below:)
If the interior temperature remains very high after the vehicle has been parked in the
sun for a considerable time, first ventilate the passenger compartment for afew minutes. Place the air flow control at a sufficient level to provide an adequate renewal of air in the passenger compartment.)
To obtain an even air distribution, take care not to obstruct the exterior air intake grilleslocated at the base of the windscreen, the nozzles, the vents and the air outlets, as well as the air extractor located in the passenger compar tment on both sides of the rear shelf. )
Do not cover the sunshine sensor, located on the dashboard (behind the instrument panel); this is used for regulation of the air conditioning system.)
Operate the air conditioning system for 5 to 10 minutes, once or twice a month to keep itin good working order. )
Ensure that the passenger compartment filter is in good condition and have the filter elements replaced regularly (refer to the "Checks" section). We recommend the use of a combined passenger compartment filter. Thanks to its second special active filter, it contributes to the purification of the air breathed by the occupants and the cleanliness of the passenger compartment (reduction of allergic symptoms, bad odours and greasy deposits).)
To ensure correct operation of the air conditioning system, you are also advised to haveit checked regularly.)
If the system does not produce cold air, do not use it and contact a CITROËN dealer or a qualified workshop.

The condensation created by the air conditioning results in a dischargeof water under the vehicle which is perfectly normal.
The air conditioning system does notcontain chlorine and does not present any danger to the ozone layer.

When towing the maximum load on a steep gradient in high temperatures, switching off theair conditioning saves engine power and so improves towing capacity.
Recommendations for ventilation and air conditioning

3
Comfort
65

Adjustment
)Adjust the mirror so that the glass is
directed correctly in the "day" position.




Manual day/night model

Da
y / night position
)Pull the lever to change to the "night" anti-dazzle position. )Push the lever to change to the normal"day" position.






Rear view mirror
Adjustable mirror providing a central rearward view.
Equipped with an anti-dazzle system, which darkens the mirror glass and reduces the nuisance to
the driver caused by the sun, headlamps from other vehicles...








Steering wheel adjustment
)When stationary, pull the control lever to yrelease the adjustment mechanism.)
Adjust the height and reach to suit your
driving position.) Push the control lever to lock theadjustment mechanism.


As a safety measure, the mirrors should be adjusted to reduce the "blind spot".


As a safety precaution, these operations should only be carried out while the vehicle is stationary.
Automatic day/night model
By means of a sensor, which measures the light from the rear of the vehicle, this system automatically and progressively changes
between the day and night uses.
In order to ensure optimum visibility during your manoeuvres, the mirror lightens automatically when reverse gear is engaged.

5
Visibility
83
Linked with the Guide-me-home lighting
Association with the automatic illumination
of headlamps provides the guide-me-home lighting with the following additional options:
- automatic activation of guide-me-home lighting when automatic illumination of
headlamps is switched on (in the vehicle
parameters of the multifunction screen configuration menu),
- selection of the duration of maintaining of
the lighting for 15, 30 or 60 seconds in the
vehicle parameters of the multifunction
screen configuration menu (except for monochrome screen Awhere this is
preset).



Operating fault

In the event of a malfunction of
the sunshine sensor, the lamps
come on, this warning lamp is
displayed in the instrument panel and/or a
message appears in the multifunction screen,
accompanied by an audible signal.
Contact a CITROËN dealer or a qualified
workshop.
In fog or snow, the sunshine sensor maydetect sufficient light. Therefore, the lamps will not come on automatically.
Do not cover the sunshine sensor,linked with the rain sensor and located in the centre of the windscreen behindthe rear view mirror; the associatedfunctions would no longer be controlled.

Automatic illumination of
headlamps
The sidelamps and dipped beam headlamps are switched
on automatically, without any action on the par t of the
driver, when a low level of external light is detected or incer tain cases of activation of the windscreen wipers.
As soon as the brightness returns to a sufficient level or
after the windscreen wipers are switched off, the lamps
are switched o
ff automatically.
Activation
)Turn ring Ato the A"AUTO"
position. The automatic
illumination of headlamps is accompanied by a message in the multifunction screen.


Deactivation
)Turn ring A
to a position other
than "AU TO "
. Deactivation is accompanied
b
y a message in the multifunction screen.

5
Visibility
89
Vertical windscreen wiper
position Automatic rain sensitive
windscreen wipers
The windscreen wipers operate automatically,
without any action on the par t of the driver, if
rain is detected (sensor behind the rear view mirror), adapting their speed to the intensity of
the rainfall.
Activation

This is controlled manually by the driver bypushing the stalk downwards to the "AU TO "position.
It is accompanied by a message in the screen. This position allows the wiper blades to be lifted
for winter parking, cleaning or replacement
without damaging the bonnet.
In the minute following switching off of the
ignition, any action on the wiper stalk positions
the wipers ver tically.
To park the wipers after this has been done,
switch on the ignition and operate the wiper stalk.


Switching off
This is controlled manually by the driver bymoving the stalk upwards then returning it to position "0".
Operating fault
If an automatic wiping malfunction occurs, the wipers will operate in intermittent mode.
Have it checked by a CITROËN dealer or aqualified workshop.
It is accompanied by a message in the screen.The automatic rain sensitive wipers must be reactivated if the ignition has been off for more than one minute, by pushing the stalk downwards.
Do not cover the rain sensor, linked withthe sunshine sensor and located in thecentre of the windscreen behind the rear view mirror. Switch off the automatic rain sensitive wipers when using an automatic car wash. In winter, to avoid damaging the wiper
blades, it is advisable to wait until thewindscreen is completely clear of icebefore activating the automatic rain sensitive wipers.

To retain the effectiveness of the "flat-
blade" wiper blades, it is advisable to:


- handle them with care,

- clean them regularly using soapywater,

- not use them to hold a sheet of cardboard against the windscreen,

- replace them at the first signs of wear.

Driving
140





Rear parking sensors System comprising four proximity sensors, located in the rear bumper.
This detects obstacles
(person, vehicle, tree, gate, etc.) behind the vehicle. However, itcannot detect obstacles located just below thebumper. Activation
The system is activated as soon as reverse gear is engaged, accompanied by an audiblesignal. The proximity information is given by:
- an audible signal, which becomes more
rapid as the vehicle approaches the
obstacle,
- a
graphic in the multifunction screen, with
blocks which become increasingly closer to
the vehicle (depending on version).
Detection zone

When the distance between the rear of thevehicle and the obstacle is less than thirtycentimetres, the audible signal becomescontinuous and the "Danger" symbol appears
in the multifunction screen.
On completion of the manoeuvre, when you exit
reverse gear, the system becomes inactive. An object, such as a stake, a roadworks cone or any other similar object may be detected at the beginning of themanoeuvre, but may no longer be detected when the vehicle comes close to it.
The parking sensors system cannot, in any circumstances, take the place of the vigilance and responsibility of thedriver.

9
Driving
141

Deactivation Reactivation

With the engine running, press button A
todeactivate the system permanently. Theindicator lamp in the button comes on.
The system will be deactivated automatically when towing a trailer or when a bicycle carrier is fitted (vehiclefitted with a towbar or bicycle carrier recommended by CITROËN).
In bad or wintry weather, ensure that the sensors are not covered with mud,frost or snow.
Press button Aagain to reactivate the system.
The indicator lamp in the button goes o
ff.
If there is an operating fault, when reverse gear is engaged, the ser vice warning lamp comes
on, accompanied by an audible signal (short
beep) and a message in the multifunction screen.
